X MC11 00 CPU Car d
For XMC1000 Family
CPU- 11A- V1
XMC1100 CPU Card
Boar d User ' s Manu a l
Revision 2.0, 2013-12-18
Micr ocont r ol ler

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XMC1100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Infineon Technologies XMC1100

  • Page 1 X MC11 00 CPU Car d For XMC1000 Family CPU- 11A- V1 XMC1100 CPU Card Boar d User ' s Manu a l Revision 2.0, 2013-12-18 Micr ocont r ol ler...
  • Page 2 Infineon Technologies components may be used in life-support devices or systems only with the express written approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure of that life-support device or system or to affect the safety or effectiveness of that device or system. Life support devices or systems are intended to be implanted in the human body or to support and/or maintain and sustain and/or protect human life.
  • Page 3 CPU-11A-V1 XMC1100 CPU Card Revision History Page or Item Subjects (major changes since previous revision) Revision 2.0, 2013-12-18 16,18 Change C210 to 4.7uF Trademarks of Infineon Technologies AG AURIX™, C166™, CanPAK™, CIPOS™, CIPURSE™, EconoPACK™, CoolMOS™, CoolSET™, CORECONTROL™, CROSSAVE™, DAVE™, DI-POL™, EasyPIM™, EconoBRIDGE™, EconoDUAL™, EconoPIM™, EconoPACK™, EiceDRIVER™, eupec™, FCOS™, HITFET™, HybridPACK™, I²RF™,...
  • Page 4: Table Of Contents

    CPU-11A-V1 XMC1100 CPU Card Table of Contents Overview ............................7 Key Features ..........................7 Block Diagram..........................7 Hardware Description ........................8 XMC1100 connector for ARDUINO ....................8 2.1.1 Digital IO connector ......................... 8 2.1.2 Analog input ..........................10 2.1.3 Power connector, POWER ......................10 2.1.4...
  • Page 5 Figure 7 LEDs Circuit ..........................12 Figure 8 AD_AUX and AUX connector ......................12 Figure 9 Schematic 1 of 2 XMC1100 CPU Card for Arduino ..............15 Figure 10 Schematic 2 of 2 XMC1100 CPU Card for Arduino ..............16...
  • Page 6 Signals of ICSP connector ......................11 Table 6 LEDs Signal Description ........................ 12 Table 7 Signals of connector AD_AUX ....................... 13 Table 8 Signals of connector AUX......................13 Table 9 XMC1100 CPU Card for Arduino ....................17 Board User's Manual Revision 2.0, 2013-12-18...
  • Page 7: Overview

    Overview The XMC1100 CPU Card for Arduino has two rows of pin headers which fully compatible with Arduino shield. Hence, user can buy various Arduino shield boards off-the-shelf to test the capabilities of XMC1100 Microcontroller. Key Features The XMC1100 CPU Card for ArduinoTM is equipped with the following features ®...
  • Page 8: Hardware Description

    XMC1100 CPU Card Hardware Description The following sections give a detailed description of the hardware and how it can be used. Figure 2 XMC1100 CPU Card for Arduino XMC1100 connector for ARDUINO 2.1.1 Digital IO connector XMC1100 CPU Card for Arduino have 10 pin connector mounting holes and 8 pin connector mounting holes at IOH and IOL respectively.
  • Page 9: Figure 3 Digital Io Connectors Ioh, Iol

    CPU-11A-V1 XMC1100 CPU Card Figure 3 Digital IO connectors IOH, IOL Table 1 Digital IO of connector IOH Pin No. Signal Name XMC1100 Signal Name Description Arduino P2.0 C Clock P2.1 C Data / Address AREF P2.3 Analog reference voltage...
  • Page 10: Analog Input

    DC power jack. However, the DC power jack is not mounted. The XMC1100 device can operate by power supply of 1.8V till 5.5Vdc. On this board, 5Vdc is used to power the XMC1100 device. However, if user wants to power the XMC1100 device with 3.3Vdc, then, please remove R102 and solder 0 ohm resistor R101.
  • Page 11: Icsp (In-Circuit Serial Programming) Header

    Ground Ground DC jack (not mounted), 7-12V 2.1.4 ICSP (In-Circuit Serial Programming) Header The SPI connector (not mounted) is used to program the XMC1100 microcontroller via the SPI interface. Figure 6 ICSP connector Table 5 Signals of ICSP connector Pin No.
  • Page 12: Other Connectors

    Output ‘Low’ to on LED LED108 P1.5 Other connectors board’s pinouts, those extra pins are group XMC1100 microcontroller has more pins than is required Arduino into connector AD_AUX (not mount) and AUX (not mount). Figure 8 AD_AUX and AUX connector Board User's Manual...
  • Page 13: Table 7 Signals Of Connector Ad_Aux

    CPU-11A-V1 XMC1100 CPU Card Table 7 Signals of connector AD_AUX Pin No. Signal Name Description P2.7 ADC input P2.5 ADC input ADC input Table 8 Signals of connector AUX Pin No. Signal Name Description P0.5 GPIO P0.6 GPIO P0.10 GPIO P0.11...
  • Page 14: Production Data

    CPU-11A-V1 XMC1100 CPU Card Production Data Schematics This chapter contains the schematics for the XMC1100 CPU Card for Arduino  Figure 9: CPU, Pin Headers, LED, Power Supply  Figure 10: On-board Debugger, Power Board User's Manual Revision 2.0, 2013-12-18...
  • Page 15: Figure 9 Schematic 1 Of 2 Xmc1100 Cpu Card For Arduino Tm

    CPU-11A-V1 XMC1100 CPU Card Figure 9 Schematic 1 of 2 XMC1100 CPU Card for Arduino Board User's Manual Revision 2.0, 2013-12-18...
  • Page 16: Figure 10 Schematic 2 Of 2 Xmc1100 Cpu Card For Arduino Tm

    CPU-11A-V1 XMC1100 CPU Card Figure 10 Schematic 2 of 2 XMC1100 CPU Card for Arduino Board User's Manual Revision 2.0, 2013-12-18...
  • Page 17: Layout And Geometry

    CPU-11A-V1 XMC1100 CPU Card Layout and Geometry Figure 11 XMC1100 CPU Card for Arduino layout and geometry Bill of Material Table 9 XMC1100 CPU Card for Arduino Value Device Reference Designator 100uF/16V/10%/SMC_D C101 Capacitor 100n/16/10%/0603 C102 Capacitor 22u/10V/10%/1206 C103 Capacitor...
  • Page 18 CPU-11A-V1 XMC1100 CPU Card Value Device Reference Designator 100nF/10V/10%/0402 C209 Capacitor 4.7uF/10V/10%/0805 C210 Capacitor 100nF/10V/10%/0402 C211 Capacitor 100nF/10V/10%/0402 C212 Capacitor 100nF/10V/10%/0402 C213 Capacitor 100nF/10V/10%/0402 C215 Capacitor SS13B (Multicomp) L101 Diode LMV358MM IC103 Op-Amp SN74LVC2T45DCT IC202 Resistor SN74LVC1T45DCK IC203 Resistor SN74LVC1T45DCK...
  • Page 19 CPU-11A-V1 XMC1100 CPU Card Value Device Reference Designator 10k/0402 R208 Resistor 1M/0402 R209 Resistor 5K10/1%/0603 R210 Resistor 10k/0402 R211 Resistor 5K10/1%/0603 R212 Resistor 10k/0402 R214 Resistor 10k/0402 R215 Resistor 10k/0402 R216 Resistor 10k/0402 R217 Resistor LED-GN/D/0603 V201 ChipLED LED-R/D/0603 V202...
  • Page 20 . i n f i n e o n . c o m Published by Infineon Technologies AG...
  • Page 21 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Infineon KIT_XMC11_BOOT_001...
