- Page 1 X MC13 00 CPU Car d For XMC1000 Family CPU- 13A- V1 XMC1300 CPU Card Boar d User ' s Manu a l Revision 2.0, 2013-12-18 Micr ocont r ol ler...
- Page 2 Infineon Technologies components may be used in life-support devices or systems only with the express written approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure of that life-support device or system or to affect the safety or effectiveness of that device or system. Life support devices or systems are intended to be implanted in the human body or to support and/or maintain and sustain and/or protect human life.
- Page 3 CPU-13A-V1 XMC1300 CPU Card Revision History Page or Item Subjects (major changes since previous revision) Revision 2.0, 2013-12-18 14,15 Change C210 to 4.7uF Trademarks of Infineon Technologies AG AURIX™, C166™, CanPAK™, CIPOS™, CIPURSE™, EconoPACK™, CoolMOS™, CoolSET™, CORECONTROL™, CROSSAVE™, DAVE™, DI-POL™, EasyPIM™, EconoBRIDGE™, EconoDUAL™, EconoPIM™, EconoPACK™, EiceDRIVER™, eupec™, FCOS™, HITFET™, HybridPACK™, I²RF™,...
-
Page 4: Table Of Contents
CPU-13A-V1 XMC1300 CPU Card Table of Contents Overview ............................7 Key Features ..........................7 Block Diagram..........................7 Hardware Description ........................8 Power Supply ..........................8 Reset .............................. 9 Clock Generation ..........................9 Boot Option ............................. 9 Debug Interface and virtual com port ....................9 LED .............................. - Page 5 CPU-13A-V1 XMC1300 CPU Card List of Figures Figure 1 Block Diagram of XMC1300 CPU Card.................... 7 Figure 2 XMC1300 CPU Card ........................8 Figure 3 Power Supply circuit ........................8 Figure 4 LEDs circuit ........................... 10 Figure 5 Potentiometer Circuit ........................10 Figure 6 Pinout of the 2x30 pin edge connector ...................
- Page 6 CPU-13A-V1 XMC1300 CPU Card List of Tables Table 1 Debug connector X201 ........................9 Table 2 LEDs Pinout ..........................10 Table 3 XMC1300 CPU Card ........................15 Board User's Manual Revision 2.0, 2013-12-18...
-
Page 7: Overview
Infineon’s XMC1000 Application Kits Overview The XMC1300 CPU board (CPU-13A-V1) houses the XMC1300 Microcontroller and a 2x30 pin edge for application expansion. The board along with application cards (e.g. Colour LED Card, White LED Card) demonstrates the capabilities of XMC1300. The main use case for this board is to demonstrate the generic features of XMC1300 device including tool chain. -
Page 8: Hardware Description
XMC1300 CPU Card is powered from the micro USB connector (5V); however, there is a current limit that can be drawn from the host PC through USB. If the CPU-13A-V1 board is used to drive other application board (e.g. Colour LED Card, White LED Card) and the total current required exceeds 500mA, then the board needs to be powered by external power supply connected to VDD and GND connection on board. -
Page 9: Reset
XMC1300 CPU Card has on-board debugger which supports Serial Wire Debug (SWD) and Single Pin Debug (SPD) as debug interface. SPD is a proprietary debugging protocol from Infineon Technologies and it requires only 1 pin for debug communication. The debugger also provides a virtual COM port which support UART communication via P1.3 (rx-in) and P1.2 (tx-out) of XMC1300. -
Page 10: Potentiometer
CPU-13A-V1 XMC1300 CPU Card Figure 4 LEDs circuit Table 2 LEDs Pinout XMC1300 Port Pin Description Output ‘Low’ to on LED LED101 P0.0 Output ‘Low’ to on LED LED102 P0.1 Output ‘Low’ to on LED LED103 P0.6 Output ‘Low’ to on LED LED104 P0.7... -
Page 11: Figure 6 Pinout Of The 2X30 Pin Edge Connector
CPU-13A-V1 XMC1300 CPU Card Figure 6 Pinout of the 2x30 pin edge connector Board User's Manual Revision 2.0, 2013-12-18... -
Page 12: Production Data
CPU-13A-V1 XMC1300 CPU Card Production Data Schematics This chapter contains the schematics for the XMC1300 CPU Card: Figure 7: CPU, Pin Headers, Potentiometer and LED and 60pin Edge connector Figure 8: On-board Debugger, Power Supply Board User's Manual... -
Page 13: Figure 7 Schematic 1 Of 2 Xmc1300 Cpu Card
CPU-13A-V1 XMC1300 CPU Card Figure 7 Schematic 1 of 2 XMC1300 CPU Card Board User's Manual Revision 2.0, 2013-12-18... -
Page 14: Figure 8 Schematic 2 Of 2 Xmc1300 Cpu Card
CPU-13A-V1 XMC1300 CPU Card Figure 8 Schematic 2 of 2 XMC1300 CPU Card Board User's Manual Revision 2.0, 2013-12-18... -
Page 15: Layout And Geometry
CPU-13A-V1 XMC1300 CPU Card Layout and Geometry Figure 9 XMC1300 CPU Card layout and geometry Bill of Material Table 3 XMC1300 CPU Card Value Device Reference Designator 100nF/10V/10%/0603 C101 Capacitor 220nF/10V/10%/0603 C102 Capacitor 220nF/10V/10%/0603 C103 Capacitor 22uF/10V/10%/0805 C201 Capacitor 10uF/10V/10%/0805... - Page 16 CPU-13A-V1 XMC1300 CPU Card Value Device Reference Designator 100nF/10V/10%/0402 C215 Capacitor SN74LVC2T45DCT IC202 Resistor SN74LVC1T45DCK IC203 Resistor SN74LVC1T45DCK IC204 Resistor SN74LVC2T45DCT IC205 Resistor SN74LVC1T45DCK IC206 Resistor BLM18PG600 L201 Ferrite Bead LED-RED/D/0603 LED101 Red ChipLED LED-RED/D/0603 LED102 Red ChipLED LED-RED/D/0603 LED103...
- Page 17 CPU-13A-V1 XMC1300 CPU Card Value Device Reference Designator MA04-2 X102 2x4 Header MA04-2 X202 2x4 Header LED-GN/D/0603 V201 ChipLED LED-R/D/0603 V202 ChipLED ESD8V0L2B-03L V204 Diode ZX62-AB-5PA X202 Micro-USB Microcontroller, XMC1300-T038 IC101 Infineon 3V3 regulator, IFX25001MEV33 IC201 Infineon Microcontroller, XMC4200_QFN48 U201...
- Page 18 . i n f i n e o n . c o m Published by Infineon Technologies AG...
