Page 3: Table Of Contents
CONFIGURATION MENU GROUP OPTIONS PTT MENU (SECONDARY PTT) BATTERIES 10. REMOTE ACTIVATION Defence Communications SEE MAIN OPERATOR GUIDE FOR MORE DETAILED INFORMATION INCLUDING HEALTH & SAFETY © Cobham DC Ltd. All rights reserved. This is an unpublished work created November 2007... -
Page 4: Overview
COBHAM Intercom system allowing Eagle users to communicate with crew and vehicle mounted radio systems. In addition a Manpack Combat Net Radio (CNR’s) can be connected to the Eagle radio, expanding the communications network for eagle users. -
Page 5: Eagle Radio Diagram
PAGE 2 DRAFT EAGLE RADIO DIAGRAM PCS SWITCH HEADSET CONNECTOR EAGLE NET (PRIMARY) BATTERY CNR/DATA COMPARTMENT CONNECTOR (SECONDARY) © Cobham DC Ltd. All rights reserved. This is an unpublished work created November 2007... -
Page 6: Radio On/Off And Volume
“VOLUME ADJUSTMENT” PRESS The PCS (Primary Control Switch) is the interface that allows the user to adjust the functionality of Eagle Radio. Pressing and holding the PCS switch will power the Eagle ON or OFF. The Radio has two modes: “OPERATIONAL... -
Page 7: Menu Options
4. CONFIGURATION MENU Configuration menu options, for details refer to page 6. Secondary PTT configuration Menu option, for details refer to page 8. 5. PTT © Cobham DC Ltd. All rights reserved. This is an unpublished work created November 2007... -
Page 8: Status Menu
COMMANDER. VOX STATUS Indicates the VOX status ON or OFF. If VOX is off then user must press the primary PTT to communicate. © Cobham DC Ltd. All rights reserved. This is an unpublished work created November 2007... -
Page 9: Configuration Menu Options
Configures the function of the secondary PTT. If a CNR is connected then this menu 7.CNR option is available. For details refer to page 8. © Cobham DC Ltd. All rights reserved. This is an unpublished work created November 2007... -
Page 10: Configuration Menu Group Options
3.EXPAND GROUP users to join the group. This function will open a CLOSED group indefinitely so new users can join the group as 4.OPEN GROUP required. © Cobham DC Ltd. All rights reserved. This is an unpublished work created November 2007... -
Page 11: Ptt Menu(Secondary Ptt)
“RADIO A” “RADIO B” “RADIO C” “CNR” allows Eagle users to access a CNR for long range communication. The CNR must be 1. CNR physically connected to the Eagle radio or connected to another Eagle Radio in the same group and ‘shared’ as a NETWORK CNR (see page 6). -
Page 12: Batteries
Should the Eagle be connected to an external power source via the CNR/DATA Connector then the radio will automatically switch to external power until disconnected. “BATTERY CAP” © Cobham DC Ltd. All rights reserved. This is an unpublished work created November 2007... -
Page 13: Remote Activation
The RAU can be attached to the users weapon if required with the supplied elasticated strap or cradle mount allowing attachment to a weapons MIL-STD-1913 (Picatinny) Rails. Remote Activation Unit PRIMARY PTT SECONDARY PTT © Cobham DC Ltd. All rights reserved. This is an unpublished work created November 2007... - Page 14 The Customer Support Manager COBHAM Defence Communications, Haslingden Road, Blackburn, Lancashire, BB1 2EE, Tel: +44 (0) 1254 292010 Fax: +44 (0) 1254 292035 E-mail: support@cobhamdc.com Website: www.cobhamdcweb.com © Cobham DC Ltd. All rights reserved. This is an unpublished work created November 2007...
