  • Page 1 SAILOR 3965 Portable UHF ATEX, Fire Fighter User manual...

  • Page 3: Important Information

    IMPORTANT INFORMATION Safe use of ATEX equipment: • Do not change the battery in wet or humid environments. • Always keep battery connectors dry and clean. • Use only with SAILOR ATEX approved accessories. Alternatively ATEX approved accessories in compliance with the accessory connector ATEX specification may be used. • Do not change accessories in wet or humid enviroments. • Do not charge the battery in hazardous area. • For charge of battery use Part no: 403505A - ATEX CH3505 Compact Charger, Part no: 403507B - ATEX CH3507 Single Position Charger or Part no: 403508B - ATEX CH3508 Dual Position Charger • Use only battery type SAILOR B3503, B3504 or B3906. • Do not use a mechanically damaged radio. • Unpacking of the radio and accessories and the removal of the protective film in front of the display window must not take place in the ATEX protected area. • To avoid electrostatic charge in the ATEX area it is important that the radio is always being worn by hand, at the body, or in a pocket in the antistatic clothes. The radio may be used with or without leather case. 99-150978-A...
  • Page 4 Manufacturer Thrane & Thrane A/S Lundtoftegårdsvej 93D, DK-2800 Kgs. Lyngby, Denmark Industrivej 30, DK-9490 Pandrup, Denmark...
  • Page 5 Thrane A/S is not responsible for the content or accuracy of any translations or reproductions, in whole or in part, of this manual from any other source. In the event of any discrepancies, the English version shall be the governing text. Thrane & Thrane A/S is trading as Cobham SATCOM. 1616...
  • Page 6 Precautions Avoid water and salt in the I/O connector and keep it clean frequently. Only use original Thrane & Thrane battery packs. Make sure they are clean and dry before attaching the transceiver. Be careful not to damage any gaskets. Only use the original Thrane &...
  • Page 7 Training information SAILOR 3965 ATEX UHF Fire is designed for to be operated safely. It must be operated by licensed personnel only. The SAILOR 3965 complies with the uncontrolled RF exposure limits. • FCC OET Bulletin 65 Supplement C, evaluating compliance with FCC guidelines for human exposure to radio frequency electromagnetic fields.
  • Page 8 Power settings Power settings are adjusted at the factory. The settings for the normal "High" power and the reduced "Low" power are saved and locked in the radio and is not accessible for the user. The user is not able to change any of the preset power settings.

  • Page 9: Table Of Contents

    Contents Chapter Introduction Your ATEX UHF Fire ..............1 Performance ................ 2 Channels ................2 Chapter Operation Controls ................5 Keys and buttons ..............5 The display .................7 Using the ATEX UHF ............8 Basic functions ..............8 Other functions ..............11 Chapter Batteries Battery level indication .............
  • Page 10 Chapter 1 Equipment and accessories External equipment ............27 List of equipment .............. 27 Connecting external equipment ........28 Impact on radio operation ..........28 Accessorie connector ............29 Accessories ............... 30 List of accessories .............30 Attaching and removing the belt clip ........ 32 Attaching the lanyard ............

  • Page 11: Your Atex Uhf Fire

     Channel read-out function for audible feedback of channel name in headset upon channel change  A lanyard and belt clip included. A huge accessory program comes with the SAILOR SP3500 series. Please find the nearest SAILOR distributor on www.cobham.com. 1616...

  • Page 12: Performance

    Introduction Performance For best performance of the transceiver keep the following in mind: • Keep clear of metal environment. • Hold the transceiver vertically and 5 cm from lips and push the PTT when transmitting. • In receive mode carry the transceiver vertically with belt clips. •...
  • Page 13 Introduction Table 2: Additional channels for 12.5 kHz equipment Channel designator Frequency Channel M 467.5375 MHz Channel N 467.5625 MHz Channel O 457.5375 MHz Channel P 457.5625 MHz Table 3: Two-frequency simplex channels for use with repeater only Channel designator Repeater RX Frequency Repeater TX Frequency Channel G...
  • Page 14 Introduction 1616...

  • Page 15: Operation

    Chapter Operation Controls Keys and buttons 1. On/off/volume 2. Light/Lock 3. Push To Talk (PTT) 4. Up key 5. Down key 6. Hi/Lo output power 7. Squelch 8. Scan 9. D/P0 quick channel select 10. Loudspeaker/microphone 1616...
  • Page 16 Operation Key presses Pressing and holding certain keys gives access to additional functions, shown in the table below. Extra long Short press Long press press (1 beep) (2 beeps) (3 beeps) Show next available Run through available Run through item in the list (up or items, or available down).

  • Page 17: The Display

    Operation The display The display holds various fields of information, explained below. 1. Current working channel. 2. “Lo”: Reduced transmitter power. Full transmitter power is not shown in display. 3. Dual watch activated. 4. Current working channel is marked for scanning. 5.

  • Page 18: Using The Atex Uhf

    Operation Using the ATEX UHF Basic functions Note Before using the radio, mount the antenna at the top of the radio. The antenna is delivered with the radio. Switching the radio on and off • To switch the radio on, turn the knob at the top of the radio clockwise.

  • Page 19: Adjusting The Volume

    Operation Activating a call To activate a call to the selected channel, press and hold the PTT button on the side of the radio. The radio transmits as long as the PTT button is pressed. A small TX sign next to the channel num- ber indicates when the radio is in transmit mode.
  • Page 20 Operation Using Dual watch (requires priority channel is programmed) • To activate Dual watch, press the SCN key. The display shows “Dual” at the top and “D” at the bottom right. The radio toggles between the selected channel and channel D (if channel D is programmed as the priority channel).

  • Page 21: Other Functions

    Operation Other functions Programming the scanning memory To add a channel to the scanning memory, select the channel and then press and hold the SCN key until the display shows MEM at the top. To remove a channel from the scanning memory, select the channel and then press and hold the SCN key until the MEM sign disappears from the display.
  • Page 22 Operation Scrambler On channels where it is allowed, you can set up voice scrambling, using configuration mode (see SCRM on page 22). Please note that if the radio is operating with scrambling on a channel, it is impossible to communicate with other radios that are not programmed with the same scrambler code.
  • Page 23 Operation Alive beep To enable “ALIVE” function do as follows: 1. Select the channel where ALIVE function is desired to be transmitted. 2. Press and hold the Hi/Lo until you see “ALIVE ON” on the radio display. It takes approx. a second. 3.
  • Page 24 Operation upon channel change (the name of the new channel will be announced in the headset). Please note that this feature is disabled as default and can be enabled either through the Portable Radio Service Tool or the menu settings in the radio (see chapter 4 for more information).

  • Page 25: Batteries

    Chapter Batteries Battery level indication When the battery level is low, you should recharge the battery. The radio display shows the battery status. When the battery symbol is empty and flashing, the battery should be recharged as soon as possible. Removing and inserting the battery pack To remove the battery pack, do as follows: 1.

  • Page 26: The Battery Chargers

    Batteries The battery chargers The chargers has two compartments. CH3505 • A compartment for recharging the battery alone or while attached to the radio. CH3507 • A rear compartment only for storing a spare battery. It does not have a charger function. •...

  • Page 27: Recharging The Battery

    Batteries When mounting the charger, make sure it is placed in a dry place and away from direct sunlight. The charger is not waterproof. Connecting to power The charger can be supplied from DC or from AC using an AC/DC converter.
  • Page 28 Batteries 1616...

  • Page 29: Configuration Mode

    Chapter Configuring the radio Configuration mode Entering and using configuration mode Note The radio is not operational in configuration mode. • To enter configuration mode, press and hold the Light/Lock button while turning on the radio. The bottom line of the display shows the current menu item/setting. •...

  • Page 30: List Of Configuration Settings

    Configuring the radio List of configuration settings The following settings are available in configuration mode. Name Values Description LIGHT Only Light/Lock button activates the backlight. All keys and buttons, except PTT and volume control, activate the backlight. BEEP Status click/beep sound on key press, long press (settings/programming saved) and battery alarm.
  • Page 31 Configuring the radio Name Values Description CONTRST 1, 2, 3, 4, 5 Contrast. 1 = lowest and 5 = highest. SHANG Off. Resumes scanning when signal disappears. 4, 6, 8, 10 Scan hang time (in seconds) on an active receiving working channel. The time is measured from signal detected - remains on channel even if signal disappears.
  • Page 32 Configuring the radio Name Values Description Remove tag “P0” for current working channel. Tag current working channel with “P0”. If another channel was previously tagged “P0”, this is overruled. • The working channel can now be selected with a long press on “D/P0”. Remove tag “P1”...
  • Page 33 Configuring the radio Name Values Description SUBC SUBC disabled. Squelch opens on all received signals. 1, 2, ..., 38 Sub-tone carrier ID. Squelch opens if the received signal contains the desired subtone. During transmission the sub-tone with the corresponding ID is generated.
  • Page 34 Configuring the radio Name Values Description SCODE No scrambler code is assigned to the channel (selecting “ON” in the SCRM setting will have no effect). 1, 2, 3, 4, A selection between 5 fixed sets of scrambler 5, CC characteristics, and a custom code (CC), can be assigned to the channel.
  • Page 35 Configuring the radio Name Values Description ADD NAME A-Z, 0-9 Makes it possible to name the channels. The name must contain a maximum of 9 characters, use only capital letters, digits and spaces. Press Light/Lock to confirm programming. Note: The name appears in the service line on the display.
  • Page 36 Configuring the radio 1616...

  • Page 37: External Equipment

    Chapter Equipment and accessories External equipment List of equipment The following equipment can be connected to the radio: Equipment Order number SAILOR 3595 Hand Microphone 403595A SAVOX C-C440AV Push-To Talk unit 403900-942 SAVOX C-C500 Remote Speaker Microphone 403500-944 SAVOX NC/400 Noise-com 403500-003 SAVOX HC-E Helmet-com 403500-004...

  • Page 38: Connecting External Equipment

    Equipment and accessories Connecting external equipment Connect the dedicated interface cable between the external equipment and the top connector on the radio. Interface cable Order number SAVOX C-C440AV - for SAVOX 403900-942 PTT unit SAVOX C-C500 - for SAVOX 403500-944 Headset SAVOX C-C500/C-C440 - for 403900-953...

  • Page 39: Accessorie Connector

    Equipment and accessories • The external accessory microphone is selected as audio input device, when the external PTT button is pressed. The transceiver microphone is used as audio input device when the transceiver PTT button is pressed. • This behaviour can be changed in the service tool. Accessorie connector Pin 1.

  • Page 40: Accessories

    Equipment and accessories Accessories List of accessories The following accessories are delivered with your radio: Accessory Order number ATEX Primary battery, B3503 (non Rechargeable Li-ion) 403503A ATEX Rechargeable battery, B3906 403906A ATEX Compact Charger, CH3505 403505A AC/DC converter, length 150cm (100-240V~ /12VDC out) 88-125538 12-24VDC Connection cable, length 150cm 37-124381...
  • Page 41 Equipment and accessories Accessories you may buy Accessory Part number ATEX Charger CH3507 403507B ATEX Dual Position Charger CH3508 403508B ATEX Leather Case 403500-207 Leather Case Warning! The display must always be kept away from the body to reduce the RF exposure when body worn.

  • Page 42: Attaching And Removing The Belt Clip

    Equipment and accessories Attaching and removing the belt clip To attach the belt clip, slide the belt clip upwards into the rails at the back of the radio until it locks. To remove the belt clip, press the projection at the top of the belt clip to release the lock and slide the belt clip downwards out of the rails.

  • Page 43: Chapter 2 Troubleshooting

    Chapter Troubleshooting Displaying errors Some errors result in an error message in the display. These error messages are listed below. Display text Problem Type Actions The battery voltage is Severe. Change/recharge below a critical level, Radio is non- the battery. EMPTY BAT where further operation functional.
  • Page 44 Troubleshooting 1616...

  • Page 45: Technical Specifications

    Appendix A Technical specifications Technical data SAILOR 3965 General Item Specification RX frequency range 440.000 - 470.000 MHz TX frequency range 440.000 - 470.000 MHz Modulation 25 kHz/12.5 kHz12.5 kHz 16K0G3E/8K50G3E 11K0G3E Power supply 7.2 VDC Li battery Current drain at 2 W TX 1.0 A Current drain at 0.4 W TX 0.7 A...

  • Page 46: Transmitter

    Technical specifications Transmitter Item Specification RF output power, landmobile 1.3 W ±1.5 dB / 0.3 W ±1.5 dB (50 ohm) FCC: 1.3 W ±0.79 dB / 0.3 W ±0.79 dB IC: 1.3 W ±1 dB / 0.3 W ±1 dB RF output power, maritime 2 W radiated / 0.4 W radiated Max deviation 25 kHz12.5 kHz...
  • Page 47 Technical specifications Item Specification Adjacent channel selectivity 25 kHz > 70 dB 12.5 kHz > 60 dB Audio output, internal 0.25 W at 10% dist. Audio output, external 0.25 W/8 ohm 1616...

  • Page 48: Battery Life Guidelines

    Technical specifications Battery life guidelines Battery (rechargeable) Note New batteries should be placed in the charger CH3505, CH3507 or CH3508 for minimum 12 hours first time. During daily use, always keep the battery fully charged and away from hot areas. Keep the battery terminals dry and clean.

  • Page 49: Dimensional Drawing, Transceiver

    Technical specifications Dimensional drawing, transceiver 1616...
  • Page 50 Technical specifications Dimensional drawing, charger CH3505 70.4 Mounting Possibillities Desktop mounting, top view Wall mounting, rear view 1616...
  • Page 51 Technical specifications CH3507 and CH3508 Mounting Possibillities Desktop mounting, top view Wall mounting, rear view 1616...

  • Page 52: Declaration Of Conformity

    Technical specifications Declaration of Conformity...

  • Page 53: Attention

    Appendix B Attention Gore-tex Membrane To keep the UHF watertight, is it very important that the Gore-Tex membrane under no circumstances must be damaged/covered or removed. That is, do not remove the Gore-Tex membrane or place any labels in the area.
  • Page 54 Attention 1616...
