Summary of Contents for L3 Nova Engineering NovaRoam MH902
- Page 1 Certification Exhibit FCC ID: OOSNRMH902 IC: 9378A-NRMH902 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Report Number: 10-0346.W06.11.A Manufacturer: L3 Nova Engineering Model: MH902 Manual 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598...
- Page 2 NovaRoam MH902 User Manual...
-
Page 3: Regulatory Information
FCC Part 15 limits. The NovaRoam MH902 is specifically designed to close the longest possible links. This goal is accomplished in part by delivering the highest permissible RF output power to the antenna per the FCC Part 15 Rules. -
Page 4: Industr Y Canada Warning
Class B Digital Devices Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 5 Description Part Number +8.2 dBi omni, 60' LMR-400 cable NR-AAT-9M08MN060 +11.2 dBi Yagi, 130' LMR-400 cable NR-AAT-9M11YN130...
-
Page 6: Operation
Operation The configuration and management of a NovaRoam network is achieved using the NovaRoam Client Tool application. The Client Tool, based on the Simple Network Management Protocol (SNMP), provides a secure method for viewing or modifying NovaRoam configuration parameters. The Client Tool also provides the ability to initiate firmware updates for NovaRoams. -
Page 7: Interfaces Page
IP Routing. The IP Routing page is used to configure the routing settings for the wireless network, including the use of mesh networking or static routes. Security. The Security page is used to configure wireless network encryption and view the MAC Address Revocation list. - Page 8 • MAC ID. This read-only field displays the unique Media Access Control (MAC) address of the NovaRoam’s wireless interface. The wireless MAC ID is based on the Ethernet interface MAC address but with the second and third sets of digits replaced with “FF” •...
- Page 9 • PPP. The Point-to-Point Protocol (PPP) mode is used for emulating an Ethernet connection over a serial interface. • DNP. The Distributed Network Protocol (DNP) mode is used for transferring DNP data between the NovaRoam’s serial port and other Ethernet devices. •...
- Page 10 • Delete. To delete an entry from the DNP table, select the entry in the table and then press the Delete button. • Output Delay. This value defines the amount of time (in milliseconds) between transmitting DNP packets to the NovaRoam’s serial interface after they are received over the wireless interface. This feature has been added to accommodate legacy equipment that cannot receive data packets as quickly as the NovaRoam can deliver them.
- Page 11 The Serial Port Tab is only available when DNP is selected as the serial port mode. The Serial Port Tab is used to configure the communication parameters for the NovaRoam’s serial port. The following parameters can be configured: • Baud Rate. Determines the bit rate used for serial communications. The default value is 9600. •...
- Page 12 network communication overhead. Larger hello interval values decrease the wireless network’s responsiveness to routing changes but reduce excessive wireless traffic in the process. This value is measured in seconds and has a default value of 30 seconds. • Allowed Hello Loss. The Allowed Hello Loss value determines the number of consecutive hello messages that, when missed, constitutes a link failure.
- Page 13 • Gateway Address. The Gateway Address is the IP address of the router that the NovaRoam will use as its gateway to the corporate LAN, Internet or other routable network. • Wireless Networks. The Wireless Networks table provides a list of wireless networks that are able to utilize the NovaRoam as a gateway to other networks.
- Page 14 • Network. Destination network for the route that is being created. To enter a static route for a device with an address of 192.168.200.1 and a subnet mask of 255.255.255.0, the Network portion of the route entry should be 192.168.200.0. •...
-
Page 15: Security Page
Security Page The Security Page provides a list of tabs that can be used to view and configure the security configuration of the NovaRoam. Selecting a tab will provide a list of configurable options. Encryption Tab The Encryption Tab is used to enable or disable encryption, change encryption keysets, and upload network and security configuration files. -
Page 16: Admin Page
The MAC Filter Tab can be used to view the list of MAC addresses that have been added to the MAC Address Revocation list using the NovaRoam Security Utility. There are no configurable parameters on the MAC Filter Tab. All changes to the MAC Revocation list must be made using the NovaRoam Security Utility and uploaded to the NovaRoam as part of a new security configuration file. -
Page 17: Statistics Page
Firmware Tab The Firmware Tab is used to upgrade the firmware that is installed on the NovaRoam. The following parameters can be configured: • File. Use the Browse button to specify the location of the firmware file to be uploaded. •... - Page 18 • Receive errors. Total number of receive errors. • Received frames dropped. Total number of frames received by the NovaRoam’s Ethernet interface that were discarded. • Unknown protocol received. Total number of frames received by the NovaRoam’s Ethernet interface with unidentified protocol errors. •...
- Page 19 • Source quench messages received. Total number of source quench messages received. A source quench message is sent to request a reduction in the packet transmission rate. • Redirect messages received. Total number of redirect messages received. A redirect is sent when an alternate route for the datagram is selected.
- Page 20 • Redirect messages sent. Total number of redirect messages sent. A redirect is sent when an alternate route for the datagram is selected. • Echo request messages sent. Total number of echo requests sent. An echo request causes the receiving radio to send an echo reply message back to the originating radio. Echo requests are typically generated by a “Ping”...
- Page 21 • Default TTL. Time-to-live value used to determine how long a packet that has not reached its destination will remain on the network prior to be discarded. • Total datagrams received. Total number of IP data packets received. • Datagrams with header errors. Total number of received IP data packets that contain errors in the header (i.e., incorrect IP header length).
- Page 22 Wireless Tab The Wireless Tab provides the following statistical information regarding the wireless performance of the NovaRoam. • Bytes received. Total number of bytes successfully received by the NovaRoam’s wireless interface. • Packets received. Total number of packets successfully received by the NovaRoam’s wireless interface.
- Page 23 • Seconds since charge went off. Duration since AC power has been removed. • Get Battery Status Log. Press the Download button to save the battery status statistics as a text file. AODV Tab The AODV Tab provides statistical information regarding the link quality between all NovaRoams within wireless communication range of the local NovaRoam.
- Page 24 Cop yright © 2010 Nova Engineering, Inc., Cincinnati, Ohio, USA. All rights reserved. This manual and the software described in it are copyrighted with all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form, by any means, without the written permission of Nova Engineering, Inc.
