Chapter III. Unified Wire Manager (UM)
FCoE Remote Port Attributes
This module provides details about the discovered target for remote port associated with virtual
port. Details such as target‟s FC ID, WWPN and WWNN are provided so that the user can
identify the discovered target accordingly.
Figure 8.7.1.4 (c) – FCoE Remort Port Attributes module
FCoE Remote Port Lun Details
This module provides LUN information for remote port associate with virtual port. Details such
as size of the LUN, SCSI address, and LUN address are provided. For Linux, the SCSI address
is displayed in H:C:T:L (Host:Channel:Target:Lun) format and for Windows, it is displayed in
P:B:T:L(SCSI Port:Bus:Target:Lun) format.
Figure 8.7.1.4 (d) - FCoE Remote Port Lun Details module
