- Page 1 SPECIFI ICATIONS M MANUAL OPN-2102i Data Colle ector with h Bluetoot This m anual prov vides speci ifications fo or the OPN N-2102i Blu uetooth data c collector w with laser ba arcode sca anner.
- Page 2 Please read this manual carefully before installing or using the product. Serial Number A serial number appears on all Opticon products. This official registration number is directly related to the device purchased. Do not remove the serial number from your Opticon device. Removing the serial number voids the warranty.
- Page 3 SPECIFICATIONS MANUAL OPN-2102i Revision History Product Name : OPN-2102i Edition Date Page Section Description of Changes 2016/09 /30...
-
Page 4: Table Of Contents
SPECIFICATIONS MANUAL OPN-2102i Contents Abstract ..........................6 Overview .......................... 6 Basic Specifications ....................... 7 Detailed View ........................9 Electrical Specifications ....................10 USB ............................10 Wireless Charging ........................10 Interface Specifications ....................10 USB Interface ......................... 10 6.1.1 Connector ........................10 6.1.2... - Page 5 SPECIFICATIONS MANUAL OPN-2102i 11 RoHS ..........................20 12 Reliability ........................20 13 Precautions ........................20 13.1 Precaution against Laser Light ....................20 13.2 Handling ..........................21 13.3 Radio Law..........................21 13.4 Bluetooth ..........................22 13.5 Frequency Band ........................22 14 Product Labels ......................23 15 Packaging Specifications .....................
-
Page 6: Abstract
This manual provides specifications for the OPN-2102i compact laser data collector with built-in Bluetooth. 2 Overview The OPN-2102i is compact battery powered portable laser scanner with a build-in wireless battery charger. Below are some of the key features: • The OPN-2102i is a handy and simple to use data collector. -
Page 7: Basic Specifications
SPECIFICATIONS MANUAL OPN-2102i 3 Basic Specifications Item Specification Note 32 bit CISC / 96 MHz FROM 512 Kbyte + 32 Kbyte SRAM 96 Kbyte FROM (storage) 1 Mbyte For data area only Key type 2 key: trigger, function 2 bi-colors LEDs (red, green) and 1 blueLED... - Page 8 SPECIFICATIONS MANUAL OPN-2102i Item Specification Note Minimum PCS 0.3 or more MRD 32% or more Main battery Lithium-polymer 600 mAh (typ.) Up-time 25 hours or more Electromagnetic guidance wireless charging, Feeding system microUSB Operating (charging) voltage 4.5 ~ 5.5V Charging with USB...
-
Page 9: Detailed View
SPECIFICATIONS MANUAL OPN-2102i 4 Detailed View Figure 1: Detailed View Name Description The laser light is emitted through this window. Ensure that the lens is Scan Window not exposed to dust and dirt before scanning. USB Cap Cap for USB connector part used to make the scanner IP54 water tight. -
Page 10: Electrical Specifications
SPECIFI ICATIONS M MANUAL OPN-2102i 5 Ele ectrical S Specifica ations 5.1 U upply Voltag : 4.5-5.5V us-power (Cl lass) : 500mA m max (hi-powe urrent consu umption : Less tha an 500mA 5.2 W Wireless C harging eeding syste... -
Page 11: Bluetooth
SPECIFICATIONS MANUAL OPN-2102i 6.2 Bluetooth The specifications of the OPN-2102i Bluetooth interface are as follows: Frequency : 2402 ~ 2480 MHz Specification : Bluetooth Ver 2.1 compliant Communication distance : 10 m Output level : Class 2 (max 4 dBm) -
Page 12: Laser Scanning Standards
SPECIFICATIONS MANUAL OPN-2102i 7.2 Laser Scanning Standards 7.2.1 Laser Scanning Tilt Vertical differences between both ends of a laser scanning line: - Up to 1.2 degrees in a vertical direction from the scan origin (scanning mirror). - Up to 3.1 mm measured at 150 mm from the scan origin and with zero skew angle. -
Page 13: Technical Specifications
SPECIFICATIONS MANUAL OPN-2102i 8 Technical Specifications Ambient conditions are as follows unless otherwise specified in each section: <Conditions> Ambient Temperature and Humidity Room temperature, room humidity Ambient Light 500 ~ 900 lx Barcodes Refer to Section 8.1. Background Black Power supply voltage... -
Page 14: Scan Area And Depth Of Field
SPECIFICATIONS MANUAL OPN-2102i 8.2 Scan Area and Depth of Field The scanner is able to read in the area between the two arcs that are centered on the scan origin with a center line distance from the front of the scanner as indicated for each resolution. -
Page 15: Printed Contrast Signal (Pcs)
SPECIFICATIONS MANUAL OPN-2102i 8.3 Printed Contrast Signal (PCS) PSC 0.3 or higher (70% or higher reflectivity of space and quiet zone) Reflectance of white space – Reflectance of black bar PCS = Reflectance of white space Note: Be sure to keep the optical window clean without dirt or scratches, or it may have a detrimental effect on the reading characteristics. -
Page 16: Curvature
SPECIFICATIONS MANUAL OPN-2102i 8.6 Curvature 8-digit JAN: R ≧ 15 mm 13-digit JAN: R ≧ 20 mm <Conditions> Barcode Resolution 0.26 mm, JAN specified in Section 8.1. Distance 100 mm from the edge of the scan engine Angle Skew angle β = +15°... -
Page 17: Ambient Light Immunity
SPECIFICATIONS MANUAL OPN-2102i 9.3 Ambient Light Immunity Scanning performance is guaranteed when the illumination on a barcode surface is between zero and the following values: Incandescent light: 4,000 lx Fluorescent light: 4,000 lx (excluding high-frequency lighting) Sunlight: 80,000 lx <Conditions>... -
Page 18: Drop Impact Strength (Without Packaging)
SPECIFICATIONS MANUAL OPN-2102i 9.7 Drop Impact Strength (without packaging) There shall be no sign of malfunction after the following drop test. Drop test: Drop the scanner 18 times in total (3 times at each 6 face), from a height of 150 cm onto a concrete floor as shown below. -
Page 19: Regulatory Compliance
SPECIFICATIONS MANUAL OPN-2102i 10 Regulatory Compliance 10.1 LED Safety JIS C 6802：2011 Class 2 IEC 60825-1 Ed.2: 2007 Class 2 CDRH Class Ⅱ 10.2 Product Safety EN60950-1:2005 IEC60950-1:2006 10.3 EMC R & TTE Directive ・EN 55024:2010 ・EN 55032:2012+AC: 2013 ・EN 301 489-1 V1.9.2 ・EN 301 489-17 V2.2.1... -
Page 20: Other
SPECIFI ICATIONS M MANUAL OPN-2102i CCI Class B is is a Class B B product, to b be used in a do omestic enviro onment, based d on the Tech nical equirement of t the Voluntary Control Coun cil for Interfere... -
Page 21: Handling
SPECIFICATIONS MANUAL OPN-2102i 13.2 Handling Handle this product carefully. Do not deliberately subject it to any of the following. (1) Shock: ・ Do not drop this product from a height greater than specified in this manual. ・ Do not place this product under or between any heavy items. -
Page 22: Bluetooth
SPECIFICATIONS MANUAL OPN-2102i 13.4 Bluetooth ・This product supports Bluetooth wireless communication with other Bluetooth devices that have the same profile ・This product complies with Bluetooth standards; however, its communication performance with untested devices is not guaranteed. ・Bluetooth devices use the 2.4 GHz frequency band that is shared among other devices. It may affect the communication speed and distance between this product and the host device. -
Page 23: Product Labels
SPECIFICATIONS MANUAL OPN-2102i 14 Product Labels The product labels are affixed to the scanner as shown below. Figure 9: Product Label Position... -
Page 24: Packaging Specifications
Weight: Appro ox. 140g OPN-20 012i Place int to the box with h folded side own without ta aped. *Place w with Opticon lo ogo upward. Display for the Serial- -No. 『 『123456』 3456=Produc ct serial numbe Display y 6-digets seri al number. -
Page 25: Collective Packaging
SPECIFI ICATIONS M MANUAL OPN-2102i 15.2 C Collective P Packaging 00pcs per bo ssembled pa ackage size : Approx. 5 595 × 520 × 2 245 (WDH m Weight: Appro ox. 15kg he order of serial- Packing box: 5B 0008 (100pcs per... -
Page 26: Physical Features
SPECIFICATIONS MANUAL OPN-2102i 16 Physical Features 16.1 Dimensions 83.0 × 36.0 × 21.5 (DWH mm) 16.2 Weight Approx. 60 g (excluding accessories) 16.3 Mechanical Drawing Unit: mm Figure 12: Mechanical Drawing... -
Page 27: Supported Symbologies
SPECIFICATIONS MANUAL OPN-2102i 17 Supported Symbologies 17.1 Default Setting The scanner is set to default by reading the following menu label. Recorded contents of the NFC tag will also return to default. Function Menu label Menu code _ZZ_ _SO_ Default _ZZ_ 17.2 Supported Symbologies... -
Page 28: Gs1 Databar, Composite Code
SPECIFICATIONS MANUAL OPN-2102i 17.2.2 GS1 Databar, Composite Code Code type Default Note GS1 DataBar ・GS1 DataBar Omnidirectional ・GS1 DataBar Truncated ・GS1 DataBar Stacked ・GS1 DataBar Stacked Omnidirectional GS1 conversion (setting required) GS1 DataBar Limited GS1 DataBar Expanded ・GS1 DataBar Expanded...
