Summary of Contents for Iiyama ProLite TF2738MSC
-
Page 1: User Manual
USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for... -
Page 3: Ce Marking Declaration Of Conformity
IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands Model No. : PL2738M We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of diff... -
Page 4: Table Of Contents
TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS..............1 SPECIAL NOTES ON LCD MONITORS .........3 CUSTOMER SERVICE ..............3 CLEANING ..................3 BEFORE YOU OPERATE THE MONITOR ..........4 FEATURES..................4 CHECKING THE CONTENTS OF THE PACKAGE ......4 WALL MOUNTING ................5 BUILT-IN EQUIPMENT ..............5 CONTROLS AND CONNECTORS..........6 CONNECTING YOUR MONITOR ...........7 COMPUTER SETTING ..............9... -
Page 5: For Your Safety
Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fi re, electric shock or damage. - Page 6 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
-
Page 7: Special Notes On Lcd Monitors
CUSTOMER SERVICE If you have to return your unit for service and the original packaging has been NOTE discarded, please contact your dealer or iiyama service center for advice or replacement packaging. CLEANING If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center. -
Page 8: Before You Operate The Monitor
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce. -
Page 9: Wall Mounting
WALL MOUNTING WARNING When you use with the wall mounting, in consideration of thickness of the mounting stage, tighten the M4 Screw with washer which “L” length is 8mm(VESA mounting holes) or 8mm(Outer mounting holes) to fasten the monitor. Using the screw longer than this may cause electric shock or damage because it may contact with the electrical parts inside the monitor. -
Page 10: Controls And Connectors
CONTROLS AND CONNECTORS MENU ENTER <Front> <Back> Menu Button (MENU) Scroll Up / Audio Adjust Button ( Scroll Down / i-Style Color Button ( Select / Input Select Button (ENTER) Power Switch ( Speakers Power Indicator NOTE Green: Normal operation Orange: Power Management USB Connector (USB) Audio Connector (AUDIO IN) -
Page 11: Connecting Your Monitor
* DVI cable is not supplied with the monitor; you need to use a special DVI cable dedicated for this model. Please contact the iiyama Support Centre in your country if you wish to connect the monitor via the DVI input. - Page 12 [Fitting and Removal of Cable Cover] Put a piece of soft cloth on the table beforehand to prevent the monitor from being scratched. Lay the monitor fl at on a table with front face down. < Fitting > Remove the screw from the monitor as Step 1 shown in Step1.
-
Page 13: Computer Setting
COMPUTER SETTING Signal Timing Change to the desired signal timing listed on page 21: COMPLIANT TIMING. TOUCH support operation system Mouse Digitizer Gestures * Remarks Windows8/8.1/10 Windows7 For Mac OS X version 10.6 Mac OS/OS X * and above you need a driver. Works for single touch only. -
Page 14: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 21. You are also able to adjust the picture by following the button operation shown below. -
Page 15: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Picture Adjust Picture Adjust Adjustment Item Problem / Option Button to Press Too dull Contrast * Too intense Too dark 1,2,3 Brightness * Too bright Off Typical Contrast Ratio 2,3,4 Adv. Contrast * Increased Contrast Ratio Off Normal Brightness of back-light is reduced. - Page 16 Input Select Direct Input Select Adjustment Item Problem / Option Button to Press Select the DVI input. HDMI Select the HDMI input. DisplayPort Select the DisplayPort input. Input Select Search for an available input source and select Auto automatically. Input source is fi xed, not selected automatically when DVI, HDMI and DisplayPort which NOTE are selected.
-
Page 17: Color Adjust
Color Adjust * Color Adjust Adjustment Item Problem / Option Button to Press Cool Bluish white Normal Greenish white Reddish white Warm Too weak User Color Green Too strong Blue Return to a state set by color adjustment except Off i-Style Color. -
Page 18: Manual Image Adjust
Manual Image Adjust Manual Image Adjust Adjustment Item Problem / Option Button to Press 1 / 2 / 3 / 4 / 5 You can change the picture quality from 1 to 5 (soft to sharp). Sharpness Press the Button to change the picture quality in numerical order. -
Page 19: Memory Recall
5 / 15 / 30 / 60 seconds Off Retune the background of OSD. OSD Background* The background of OSD is mode transparent. iiyama Logo does not display when the monitor is Off turned on. Opening Logo* iiyama Logo displayed when the monitor is turned on. -
Page 20: Lock Mode
● Lock Mode <OSD Menu> 1. The OSD lock will be activated by pressing the front buttons for about 5 seconds. If you try to access the OSD by pressing any of the buttons , message "OSD Locked" will appear on the screen. 2. -
Page 21: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of ENERGY ® STAR and VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. -
Page 22: Trouble Shooting
MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... -
Page 23: Recycling Information
RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. Recycling information 19... -
Page 24: Appendix
APPENDIX Design and specifi cations are subject to change without prior notice. SPECIFICATIONS Touch Technology Projected capacitive 10pt touch Screen Light transmission 85% Hardness Total thickness 3.6mm Communication system Size Category 27" LCD Panel Panel Technology AMVA+ Size Diagonal: 27" (68.6cm) Pixel pitch 0.31125mm H ×... -
Page 25: Dimensions
DIMENSIONS 318.0mm/12.5” 4xM4 SCREW HOLE 648.5mm/25.5” 50.0mm/2.0” (VESA MOUNT) 599.5mm/23.6” 9.0mm/0.3” 100.0mm/3.9” 100.0mm/3.9” 8xM4 SCREW HOLE (Outer) 174.25mm/6.9” 300.0mm/11.8” 174.25mm/6.9” COMPLIANT TIMING Horizontal Vertical Dot Clock Video Mode Frequency Frequency 25,175MHz 31,469kHz 59,940Hz 37,500kHz 75,000Hz 31,500MHz 640 × 480 31,500MHz 37,861kHz 72,809Hz 35,156kHz...
