USER MANUAL
ENGLISH
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes
to read this comprehensive manual carefully
before installing and switching on the monitor.
Please keep this manual in a safe place for
your future reference.

Advertisement

Table of Contents
loading

Related Manuals for Iiyama ProLite TF6537UHSC-B1AG

Summary of Contents for Iiyama ProLite TF6537UHSC-B1AG

  • Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for...
  • Page 2 IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands Model No. : PL6537 We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of diff...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS..............1 SPECIAL NOTES ON LCD MONITORS .........3 CUSTOMER SERVICE ..............5 CLEANING ..................5 BEFORE YOU OPERATE THE MONITOR ..........6 FEATURES..................6 CHECKING THE CONTENTS OF THE PACKAGE ......6 UNPACKING ...................7 SPECIAL NOTES ON ..............7 CONTROLS AND CONNECTORS : MONITOR ......8 INSTALLATION ................9 CONTROLS AND CONNECTORS :...

  • Page 4: For Your Safety

    Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fi re, electric shock or damage.
  • Page 5 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.

  • Page 6: Special Notes On Lcd Monitors

    SPECIAL NOTES ON LCD MONITORS  The following symptoms are normal with LCD monitors and do not indicate a problem. NOTE - When you fi rst turn on the LCD monitor, the picture may not fi t in the display area because of the type of computer that is used.
  • Page 7 1 hour in order to clear the residual image. For all LFD products, iiyama recommends displaying moving images and utilising a moving screen saver at regular intervals whenever the screen is idle. You could also turn off the monitor when not in use to assist the prevention.

  • Page 8: Customer Service

     If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center.  For safety reasons, turn off the power switch and unplug the monitor before you CAUTION clean it.

  • Page 9: Before You Operate The Monitor

    CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce.

  • Page 10: Unpacking

    UNPACKING Before unpacking your monitor, prepare a stable, level, and clean surface near a wall outlet. Set the LCD Monitor box in an upright position and open from the top of the box before removing the top cushions. Remove the carton holders. Remove the top cushion and take the accessories box and the Monitor out.

  • Page 11: Controls And Connectors : Monitor

    CONTROLS AND CONNECTORS : MONITOR <Back> <Front> POWER LEFT RIGHT AUTO/EXIT SOURCE/OK POWER LEFT MENU RIGHT AUTO/EXIT SOURCE/OK MENU AC IN HDMI4 HDMI3 HDMI2 HDMI1 RS232 RS232 POWER Power Button LEFT Left/Volume + Button RIGHT Right/Volume - Button AUTO / EXIT Auto/Exit Button SOURCE / OK Input Select/OK Button...

  • Page 12: Installation

    INSTALLATION CAUTION  Follow the manual instructions for the type of mount you have selected. Refer all servicing to qualifi ed service personnel.  Moving the monitor requires at least two people.  Before installing, please make sure the wall is strong enough to hold the necessary weight of the display and the mount.
  • Page 13 [ROTATING THE DISPLAY] It is designed to be compatible in both landscape and portrait modes. Not Available Available Landscape Portrait 10 BEFORE YOU OPERATE THE MONITOR...

  • Page 14: Controls And Connectors : Remote Control (For Maintenance)

    CONTROLS AND CONNECTORS : REMOTE CONTROL (For maintenance) POWER MUTE MEMU AUTO PLAY EXIT STOP SELECT NOTE To use the remote control we advise you to position it at the back of the monitor (left side) where the remote sensor is located. It might not work if you use it standing in front of the monitor. POWER Turns the monitor ON and OFF.

  • Page 15: Preparing The Remote Control

    PREPARING THE REMOTE CONTROL To use the remote control, insert the button battery. CAUTION Do not use any other batteries other than those specifi ed in this manual for the Remote Control. Burst batteries or the electrolyte from these batteries may cause stains, fi re or injury. Push Lock to right and remove the battery case in the direction of the arrow.

  • Page 16: Basic Operation

    BASIC OPERATION  Turning the monitor ON The monitor is on and the Power Indicator turns Green when you press the Power Button on the monitor or the Remote Control. The monitor is off and the Power Indicator turns Orange when you press the Power Button on the monitor or the Remote Control.
  • Page 17  Move the cursor vertically Select adjustment by pressing the UP / DOWN Button on the monitor or the Button on the Remote Control while the menu page is displayed on the screen. [Monitor] [Remote Control] POWER POWER MUTE LEFT MEMU AUTO RIGHT...
  • Page 18  Adjust the volume of sound Press the UP / DOWN Button on the Monitor or the VOL Button on the Remote Control to adjust the volume of sound when the menu page is not displayed on the screen. [Monitor] [Remote Control] POWER MUTE...

  • Page 19: Connecting Your Monitor

    An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce.
  • Page 20 [ About the daisy chain ]  Monitor control connection RS-232C MONITOR1 MONITOR2 [RS-232C] [RS-232C IN] [RS-232C OUT] [RS-232C IN]  Digital video connection DisplayPort DisplayPort v1.2 multiple stream support allows daisy-chain up to 3 monitors showing diff erent content on each screen. MONITOR1 MONITOR2 MONITOR3...

  • Page 21: Computer Setting

    Change to the desired signal timing listed on page 38: COMPLIANT TIMING.  Windows XP/Vista/7/8/8.1/10 Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows XP/Vista/7/8/8.1/10 by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied.

  • Page 22: Operating The Monitor

    OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 38. You are also able to adjust the picture by following the button operation shown below.
  • Page 23  LOCK MODE: * Available for OSD key button only. Pressing and holding the MENU button and the Power Switch for about 3 seconds when the Menu is not displayed. * The OSD menu is not displayed when the OSD is locked. Pressing and holding the MENU button and the Power Switch for about 3 seconds when the Menu is not displayed.

  • Page 24: Adjustment Menu Contents

    ADJUSTMENT MENU CONTENTS Display Mode Display Mode Select Region Picture 2P LR 2P TB 2P PIP Adjustment Item Problem / Option Button to Press Set the output mode of the screen. 1 input signal 2P LR 2 input signals (Left/Right) 2P TB 2 input signals (Top/Bottom) 2P PIP...
  • Page 25 Display Function Display Mode Select Region Picture Disp Rotate Adjustment Item Problem / Option Button to Press Rotate the screen clockwise. Disp Rotate* 0 / 90 / 180 / 270 Change the left and right of the monitor ratio. LR Ratio* 0(1 : 1) - 4(Left-big : Right-small) 2,3,4 Input Swap*...
  • Page 26 Select Region Display Mode Select Region Picture Right Side Full Adjustment Item Problem / Option Button to Press You can select the confi guration screen, when you are viewing two or more screens. Only the following display settings can be adjusted: Brightness, Contrast, Sharpness, Gamma, Temperature, Color Eff...
  • Page 27 Picture Display Mode Picture Select Region Backlight Brightness Contrast Sharpness Adjustment Item Problem / Option Button to Press Backlight Brightness of back light is reduced. Too dark Brightness* Too bright Too dull Contrast* Too intense You can change the picture quality from 0 to 4 (soft to sharp).
  • Page 28 Color Color Advance Input Audio Gamma Color Temp Color Format Adjustment Item Problem / Option Button to Press You can set the Gamma. Gamma* OFF / 1.8 / 2.2 10000k More bluish white 9300k Bluish white 6500k Reddish white Temperature* Too weak GREEN USER...
  • Page 29 Advance Advance Input Adjustment Item Problem / Option Button to Press Full Full screen display. 16:10 Displays all picture in 16:10 aspect ratio. Aspect Ratio Displays all picture in 5:4 aspect ratio. Displays all picture in 4:3 aspect ratio. Activate Overscan to reduce picture noise. Over Scan Deactivate Overscan Standard...
  • Page 30 Input Color Advance Input Audio HDMI 1 HDMI 2 HDMI 3 Adjustment Item Problem / Option Button to Press Select the digital(DP) input. Select the digital(HDMI1) input. HDMI1 Select the digital(HDMI2) input. HDMI2 If Display Mode is set to 1P HDMI3 Select the digital(HDMI3) input.
  • Page 31 Audio Color Advance Input Audio Volume Mute Audio Source Adjustment Item Problem / Option Button to Press      Too soft Volume Too loud Turn off the sound temporarily. Mute Return the sound volume to the previous level. Outputs the sound of the screen which Digital Region1(LT) selected.
  • Page 32 Schedule Schedule Other Current Time Timer Set Input Select Adjustment Item Problem / Option Button to Press Schedule is turned on. Schedule On/Off Schedule is turned off . Adjust the current date and time for the internal clock. Current Time Year / Month / Day / Hour / Minute Sets a recurring schedule.
  • Page 33 Other Other Reset Reset Adjustment Item Problem / Option Button to Press Factory-preset data is restored. Reset Reset * Return to Menu. You can set the OSD display duration time Menu Time between 10 and 60 seconds. OSD is too left OSD H.
  • Page 34 Going sleep mode after 3 hours display. Auto Power Down Auto Power Down is turned off . * If you want to use a LAN or RS232C control, please contact your dealer or your iiyama service center. OPERATING THE MONITOR 31...
  • Page 35 Information Schedule Other HDMI 1 1920x1080@60.0Hz HDCP Enabled Displays information regarding the current input signal coming from the graphic card in your computer. See your graphic card user guide for more information about changing the NOTE resolution and refresh. 32 OPERATING THE MONITOR...

  • Page 36: Power Management Feature

    POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below.

  • Page 37: Trouble Shooting

    MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem Check ...

  • Page 38: Recycling Information

    RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. RECYCLING INFORMATION 35...

  • Page 39: Appendix

    APPENDIX Design and specifi cations are subject to change without prior notice. SPECIFICATIONS Technology Projected Capacitive 50points* Light transmission 80% min. Touch Hardness Screen Thickness Communication system USB serial transfer Size Category 65" Panel technology Size Diagonal: 65" (165cm) Pixel pitch 0.372mm H ×...

  • Page 40: Dimensions

    DIMENSIONS 1072.0mm/42.2” 4xM8 SCREW HOLE 1530.5mm/60.3” (VESA MOUNT) 600.0mm/23.6” POWER LEFT RIGHT AUTO/EXIT SOURCE/OK MENU AC IN HDMI4 HDMI3 HDMI2 HDMI1 RS232 RS232 APPENDIX 37...

  • Page 41: Compliant Timing

    COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 640 × 480 31.469kHz 59.940Hz 25.175MHz SVGA 800 × 600 37.879kHz 60.317Hz 40.000MHz 1024 × 768 48.363kHz 60.004Hz 65.000MHz 1280 × 768 47.776kHz 59.870Hz 79.500MHz SXGA 1280 × 1024 63.981kHz 60.020Hz 108.000MHz VESA...
