Summary of Contents for Kärcher BR 400
- Page 1 BR 400 www.karcher.com...
- Page 2 DEUTSCH FRANÇAIS ENGLISH 1 Deckel für Bürstenwalze 1 Couvercle de rouleau-brosse 1 Cover for brush roller 2 Schrauben 2 Vis 2 Screws 3 Arretierung für Transport-/ 3 Dispositif de blocage en 3 Catch for transport and Arbeitsstellung position de transport/de working position travail 4 Fußpedal für Saugbalken...
-
Page 3: Table Of Contents
English BR 400 Table of contents Operation ..................... 11 Attaching the push handle ................11 Transport position/working position ............. 11 Filling the detergent solution ................ 11 Normal operation ..................12 Emptying the dirty water tank ..............12 Working only with brush operation ............... 12 Polishing ...................... -
Page 4: Operation
BR 400 English 1. Operation • On unpacking the unit you will find the upper push handle folded Attaching the push handle down. • Position the lower push handle half vertically, attach the upper half and screw together using the supplied screws and nuts. -
Page 5: Normal Operation
English BR 400 Operating in normal mode • Connect the unit plug to the extension cable and hook into the cable grip on the push handle. Û • Insert the extension cable plug into the mains socket. high brush contact pressure •... -
Page 6: Polishing
BR 400 English Polishing • Polishing is carried out without water and without vacuuming. If required the tanks can be removed, facilitating polishing under furniture, etc. Caution: To avoid damaging the floor due to overheating, do not allow the unit to run in one place. -
Page 7: Care And Maintenance
English BR 400 2. Care and maintenance Caution: Switch off the unit and disconnect the mains plug before cleaning, servicing or repairing. Repair work must only be carried out by authorized customer service centres familiar with the safety regulations. Do not use a hose or high pressure water spray to clean the unit (danger of short-circuits or other damage). -
Page 8: Protection Against Freezing
BR 400 English Protection against freezing • If there is a risk of freezing, run the pump until no more water comes out. The best protection is to store the unit in a room which is above freezing point. • When restarting the unit after freezing, fill the tank with warm water and wait until any ice in the pump has melted;... -
Page 9: Technical Data
English BR 400 3. Technical data 1.926-721 1.926-281 1.926-691 1.926-521 1.926-591 1.926-121 1.926-291 Rated voltage 220 V/230 V (1~50Hz) 230 V (1~50Hz) Mains fuse (slow) 16 A* (GB: 13 A) 10 A Rated power 2.54 kW 2.1 kW – Brush motor 1.7 kW... -
Page 10: Troubleshooting
BR 400 English 4. Troubleshooting You may be able to rectify some malfunctions by yourself. Malfunction Possible cause Remedy Fresh water tank is empty Fill up No or insufficient detergent solution on floor Connection between fresh water Check connection tank and pump leaks... - Page 11 English BR 400 Further malfunctions BR 400 Insufficient suction Dirty water tank incorrectly Check and mount correctly mounted on the unit power or unsatisfactory vacuuming result on Water level in the dirty water Empty dirty water tank the floor tank too high...
- Page 12 BR 400 5.063-650 1.926-121.0 4.066-238.0 1.926-291.0 * CH 1.926-691.0 * BR 1.926-721.0 * RA 5.031-407.0 5.321-457.0 5.031-066.0 5.070-480.0 6.647-418.0 1.926-121.0 * EUR 6.647-557.0 1.926-291.0 * CH 6.647-418.0 1.926-691.0 * BR 6.648-334.0 1.926-721.0 * RA 4.692-025.0 5.390-159.0 5.028-754.0 5.585-020.0 5.762-112.0 (weiss/ white/ blanc/) 5.762-125.0 (rot/ red/ rouge)
