Table Of Contents; Product Specifications; California Proposition 65 - Porter-Cable PCB270TS Instruction Manual

SECTION
PRODUCT SPECIFICATIONS ..........................................................................................................................................
CALIFORNIA PROPOSITION 65 ......................................................................................................................................
SAFETY GUIDELINES - DEFINITIONS ............................................................................................................................
POWER TOOL SAFETY ...................................................................................................................................................
TABLE SAW SAFETY .......................................................................................................................................................
ELECTRICAL REQUIREMENTS AND SAFETY ...............................................................................................................
TOOLS NEEDED FOR ASSEMBLY .................................................................................................................................
CARTON CONTENTS ......................................................................................................................................................
KNOW YOUR TABLE SAW...............................................................................................................................................
GLOSSARY OF TERMS....................................................................................................................................................
ASSEMBLY AND ADJUSTMENTS....................................................................................................................................
OPERATION .....................................................................................................................................................................
MAINTENANCE ................................................................................................................................................................
TROUBLESHOOTING GUIDE...........................................................................................................................................
ACCESSORIES AND ATTACHMENTS ............................................................................................................................
PARTS LIST ......................................................................................................................................................................
WARRANTY ......................................................................................................................................................................
MOTOR
Type ........................................... Induction
Amps.......................................... 15 / 7.5
Voltage ....................................... 120 / 240
Hz............................................... 60
RPM (no load)............................. 3450
Overload Protection................... YES
MITER GAUGE
RIP FENCE
WARNING
!
To avoid electrical hazards, fire hazards or damage to the tool, use proper circuit protection. Use a seperate electrical
circuit for your tools. To avoid electrical hazards, fire hazards or damage to the table saw, use proper circuit protection.
This table saw is wired at the factory for 110-120/220-240 Volt operation. It must be connected to a 110-120 Volt / 15
Ampere or 220-240 Volt / 7.5 Ampere time delay fuse or circuit breaker. To avoid shock or fire, replace power cord
immediately if it is worn, cut or damaged in any way.
WARNING
!
Some dust created by power sanding, sawing, grinding, drilling and other construction activities contains
chemicals known to the state of California to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
Lead from lead-based paints,
•
Crystalline silica from bricks and cement and other masonry products, and
•
Arsenic and chromium from chemically-treated lumber.
•
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated area, and work with approved safety equipment, such
as those dust masks that are specially designed to filter out microscopic particles.
Avoid prolonged contact with dust from power sanding, sawing, grinding, drilling, and other construction
activities. Wear protective clothing and wash exposed areas with soap and water. Allowing dust to get into
your mouth, eyes, or lay on the skin may promote absorption of harmful chemicals.
Use of this tool can generate and/or disperse dust, which may cause serious and permanent
WARNING
!
respiratory or other injury. Always use NIOSH/OSHA approved respiratory protection
appropriate for the dust exposure. Direct particles away from face and body.
2009/12

TABLE OF CONTENTS

PRODUCT SPECIFICATIONS

YES
YES

CALIFORNIA PROPOSITION 65

SAW
Table Size................................... 27-1/8 in. x 20-1/8 in.
Table Extensions......................... Right & Left
Extension Fence Capacity........... 30 in. (762 mm) Right
Blade Size.................................... 10 in. (254 mm)
Blade Arbor.................................. 5/8 in. (15.9 mm)
CUTTING CAPACITY
Maximum Cut Depth @ 90°......... 3-1/2in.(88.9 mm)
Maximum Cut Depth @ 45°......... 2-1/4 in.(57.1 mm)
Maximum Dado Cut Width........... 13/16 in.(20.6 mm)
Maximum Dado Blade Diameter.. 8 in. (203.2mm)
- 2 -
PAGE
2
2
3
4
5
7
8
9
11
12
13
23
29
30
31
33
38
(688 mm x 512 mm)
Printed in Taiwan
