8.4.5 RESET TO FACTORY SETTINGS
To reset any or all changes made in menu 2 back to the factory defaults
setting:
NOTICE: Menu 3
▶ Any changes made in Menu 3 are not reset via these
actions.
1. Press and hold the
,
and
ok
seconds.
The screen will then display code 8E with the spanner symbol.
2. Press the
button and "Reset" will be displayed with the tick
reset
symbol for three seconds.
After three seconds the screen will revert to the normal operation
screen.
Eco
1.
+
2.
reset
Reset
Eco
Fig. 121 Reset sequence
8.4.6 MENU 3 - BOILER MAXIMUM & MINIMUM LIMITS
The menu shows the boiler's minimum and maximum limits. They can be
adjusted in this menu.
The boiler will revert to adjusted settings in Menu 3 following a power
interruption.
Menu 3 cannot be factory re-set.
1. Select menu 3 via the
and
2. Press and hold the
button for at least 5 seconds to enter Menu 3.
ok
To modify a setting, select desired menu option (refer to table 33) via
the
and
arrow buttons and press the OK button, the option will
flash.
Adjust the parameters using the
the OK button to confirm.
A
symbol will be displayed for three seconds to confirm the update
of the new value.
Greenstar i System Compact
ErP
- 6 720 813 280 (2015/07)
arrow button for at lest five
°C
~5 s
+
ok
°C
°F
~3 s
°C
°F
°C
°F
scroll buttons.
and
arrow buttons and press
eco
°C
reset
ok
°F
Menu 1
e
max
Menu 3
eco
°C
reset
ok
°F
Menu 3
e
max
5 s
3.1A kW
Fig. 122 Menu 3 selection
3.1B
* Maximum DHW
heating output
3.3D
Minimum boiler power
for both heating and
hot water.
* Only available when the optional integral diverter valve kit is installed.
Table 33 Menu 3 parameters
FAULT FINDING AND DIAGNOSIS
2
1
1
3
0
bar
4
1.
min
max
°C
°F
2
1
1
0
bar
4
2.
min
max
°C
°F
The maximum DHW heating output
in kW can be set here. The output
can be down rated.
This sets the minimum output, for
example 7kW.
3
67
