Quick Installation Guide
Moxa Americas:
Toll-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa Europe:
Tel:
+49-89-3 70 03 99-0
Fax:
+49-89-3 70 03 99-99
Moxa India:
Tel:
+91-80-4172-9088
Fax:
+91-80-4132-1045
AWK-1137C
Moxa AirWorks
Edition 2.0, August 2017
Technical Support Contact Information
www.moxa.com/support
 2017 Moxa Inc. All rights reserved.
Moxa China (Shanghai office):
Toll-free: 800-820-5036
Tel:
+86-21-5258-9955
Fax:
+86-21-5258-5505
Moxa Asia-Pacific:
Tel:
+886-2-8919-1230
Fax:
+886-2-8919-1231
P/N: 1802011370011
*1802011370011*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AWK-1137C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Moxa Technologies AWK-1137C

  • Page 1 AWK-1137C Quick Installation Guide Moxa AirWorks Edition 2.0, August 2017 Technical Support Contact Information www.moxa.com/support Moxa Americas: Moxa China (Shanghai office): Toll-free: 1-888-669-2872 Toll-free: 800-820-5036 Tel: 1-714-528-6777 Tel: +86-21-5258-9955 Fax: 1-714-528-6778 Fax: +86-21-5258-5505 Moxa Europe: Moxa Asia-Pacific: Tel: +49-89-3 70 03 99-0...
  • Page 2: Hardware Setup

    AWK-1137C combines two adjacent 20 MHz channels into a single 40 MHz channel to deliver a potent combination of greater reliability and more bandwidth. The AWK-1137C can operate on either the 2.4 or the 5 GHz band and is backward compatible with existing 802.11a/b/g deployments.
  • Page 3 Panel Layout of the AWK-1137C 1. System LEDs: SYS, WLAN, LAN1, LAN2, and SERIAL 2. LAN1: 10/100 BaseT(X) RJ45 port 3. LAN2: 10/100 BaseT(X) RJ45 port 4. RS-232/422/485 DB9 serial port 5. 3-pin terminal block (ground/-/+) 6. M3 screw holes for antenna bracket 7.
  • Page 4 9. 3-pin maintenance port for engineers 10. Reset button 11. Screw holes for DIN-rail mounting kit 12. Screw holes for wall-mounting - 4 -...
  • Page 5: Mounting Dimensions

    DIN-Rail Mounting The aluminum DIN-rail attachment plate comes attached to the back panel of the AWK-1137C when you take it out of the box. If you need to reattach the DIN-rail attachment plate to the AWK-1137C, make sure the stiff metal spring is situated towards the top, as shown in the figures...
  • Page 6: Wall Mounting (Optional)

    STEP 2: Mounting the AWK-1137C to a wall requires two screws. Use the AWK-1137C device, with wall-mounting plates attached, as a guide to mark the correct locations of the two screws. The heads of the screws should be less than 6.0 mm in diameter, and...
  • Page 7: Wiring Requirements

    WARNING Safety First! Be sure to disconnect the power cord before installing and/or wiring your Moxa AWK-1137C. Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes that dictate the maximum current allowed for each wire size. If the current goes above the maximum ratings, the wiring could overheat, causing serious damage to your equipment.
  • Page 8 Grounding the Moxa AWK-1137C Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run the ground connection from the ground screw to the grounding surface prior to connecting devices.
  • Page 9: Wiring The Redundant Power Inputs

    12-28 AWG (3.31-0.0804 mm²) and a torque value of 4.5 lb-in (0.51 Nm) ATTENTION If the AWK-1137C is connected to a motor or other similar type of equipment, be sure to use power isolation protection. Before connecting the AWK-1137C to the DC power inputs, make sure the DC power source voltage is stable.
  • Page 10: Communication Connections

    Installing the Antenna-Locking Clamp Use the antenna-locking clamp to secure the antennas to the AWK-1137C for added stability when you install the device in a high-vibration environment. STEP 1: STEP 2: Slide the clamps into the antenna Use screws to fix the clamps to the port.
  • Page 11: Led Indicators

    LED Indicators The front and side panel of the Moxa AWK-1137C contains several LED indicators. The function of each LED is described in the table below: Color State Description System start up complete and the system is in operation Blinking +...
  • Page 12 WLAN Interface Operating Channels (central frequency) • 2.412 to 2.462 GHz (11 channels) • 5.180 to 5.240 (4 channels) • 5.260 to 5.320 (4 channels) • 5.500 to 5.700 GHz (8 channels, excluding 5.600 to 5.640 GHz) • 5.745 to 5.825 GHz (5 channels) •...
  • Page 13 NOTE Based on regional regulations, the maximum transmission power allowed on UNII bands is restricted in the firmware, as indicate below. 2.4 GHz 26 dBm 18 dBm 18 dBm 5 GHz (UNII-1) 23 dBm 23 dBm 23 dBm 5 GHz (UNII-2) 23 dBm 23 dBm 23 dBm...
  • Page 14 Details See www.moxa.com/support/warranty.aspx ATTENTION • The AWK-1137C is NOT a portable mobile device and should be located at least 20 cm away from the human body. • The AWK-1137C is NOT designed for the general public. A well-trained technician is required to deploy AWK-1137Cs and safely establish a wireless network.
  • Page 15 NOTE For installation flexibility, you may select either antenna A or antenna B on the top panel. Make sure the antenna connection matches the antennas configured in the AWK-1137C web interface. To protect the connectors and RF module, all radio ports should be terminated by either an antenna or a terminator.
  • Page 16: Software Setup

    ATTENTION CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment Type message content here. WARNING RF exposure: This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located...
  • Page 17: First-Time Quick Configuration

    • Step 3: Set up the computer’s IP address Choose an IP address for the computer that is on the same subnet as the AWK. Since the AWK’s default IP address is 192.168.127.253, and the subnet mask is 255.255.255.0, set the IP address to 192.168.127.xxx, where xxx is a value between 1 and 252.
  • Page 18 NOTE The default SSID is MOXA. Step 3: Set the RF type and Channel for the AWK. • Go to Wireless LAN Setup  WLAN  Basic WLAN Setup. We recommend that you choose the RF type 5 GHz for a relative clean medium with minimum interference.
  • Page 19 Step 2: Link to an existing SSID. • Go to Wireless LAN Setup  WLAN  Basic WLAN Setup and click Site Survey to select an existing SSID, or directly enter an existing SSID in the text field. Step 3: Set the RF type and Channel settings for the AWK. •...
  • Page 20 Go to Wireless LAN Setup  Operation Mode, set the operation mode to Slave, and then click Submit to apply the change. Step 2: Link to an existing SSID. • Go to Wireless LAN Setup  WLAN  Basic WLAN Setup and click Site Survey to select an existing SSID, or directly enter an existing SSID in the text field...
