Installation and Operation Manual
WinLink™ 1000
Point-to-Point Wireless
Product Family
Revision 3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WinLink 1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Radwin WinLink 1000

Summary of Contents for Radwin WinLink 1000

  • Page 1 Installation and Operation Manual WinLink™ 1000 Point-to-Point Wireless Product Family Revision 3.0...
  • Page 3 RADWIN protected under international copyright law and shall be and remain solely with RADWIN. WinLink 1000 is a registered trademark of RADWIN. No right, license, or interest to such trademark is granted hereunder, and you agree that no such right, license, or interest shall be asserted by you with respect to such trademark.
  • Page 4 For further information contact RADWIN at the address below or contact your local distributor. International Headquarters RADWIN Ltd. U.S. Headquarters RADWIN Inc. 32 Habarzel Street 900 Corporate Drive Tel Aviv 69710 Israel Mahwah, NJ 07430 USA Tel: 972-3-7662900 Tel: (201) 529-1100Fax: (201) 529-...
  • Page 5 Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by the party responsible for compliance (RADWIN) could void the user’s authority to operate the equipment. It is the responsibility of the installer to ensure that when using the outdoor antenna kits in the United States (or where FCC rules apply), only those antennas certified with the product are used.

  • Page 6: Quick Start Guide

    Quick Start Guide Installation of WinLink 1000 should be carried out only by a qualified technician. If you are familiar with WinLink 1000, use this guide to prepare the units for operation. Installing WinLink 1000 Units ODU Package Contents: •...
  • Page 7 • Laptop running Windows 2000 or Windows XP • Before the installation 1. Install the WinLink 1000 software on the laptop. 2. Verify that all equipment and tools are available. Performing Installation To install the ODU: 1. At site A, route the ODU cable from the ODU location (on the roof) to the IDU location (inside the building).
  • Page 8 WinLink 1000 Installation and Operation Manual Quick Start Guide To align the ODU: 1. Connect power to the IDU. Do not stand in front of a live outdoor unit. Warning The antenna used for this transmitter must be installed to provide a...
  • Page 9 Normal Indications Upon turning on WinLink 1000, the PWR LED in the front panel lights to indicate that WinLink 1000 is on. The table below shows the correct status of the indicators after power-up.
  • Page 10 WinLink 1000 Installation and Operation Manual Quick Start Guide Troubleshooting If the WinLink 1000 is not operational, determine the cause and solution from the table below. Status Remedy For the IDU-E, check that AC adapter is connected to the IDU and the AC power outlet.

  • Page 11: Table Of Contents

    Aligning the WinLink 1000 ODUs..............Installing the Link................... 2-10 Connecting the User Equipment ..............2-18 Chapter 3. Configuration 3.1 Performing Configuration of WinLink 1000 ..........Configuring Service Parameters ..............3-10 Editing the Configuration Parameters ............. 3-13 Changing the Transmit Power.................
  • Page 12 Turning Off WinLink 1000 ................Changing the Password ..................4.3 Managing WinLink 1000 ................Resetting WinLink 1000..................Saving WinLink 1000 Configuration in a File ............. Restoring a Configuration File ................Displaying the WinLink 1000 Inventory ............. Chapter 5. Diagnostics and Troubleshooting 5.1 Error Detection and Alarms...............
  • Page 13 Table of Contents List of Figures 1-1. Typical Application ..................1-2. WinLink 1000 Units ..................2-1. Typical Installation Diagram ................2-2. IDUs connector panels..................2-3. Login Screen ....................2-4. Login vial Local Connection Screen ..............2-5. Main Menu ...................... 2-6. Beeper Sequence for ODU Alignment .............
  • Page 14 3-20. Bridge mode, no IDU Aging ................. 3-21 4-1. IDU Panels LEDs ....................4-2. Main Menu, Wireless Link is Active ..............4-3. WinLink 1000 Inventory................... 5-1. Preferences Dialog Box, Event Log Tab ............5-2. Loopbacks Dialog Box ..................5-3. Local External Loopback ..................
  • Page 15 4-2. WAN/LAN LEDs....................4-3. TDM Traffic Indicators ..................4-4. WinLink 1000 Indicators at Startup ..............5-1. WinLink 1000 Alarms and Information Messages ..........5-2. Troubleshooting with WinLink 1000 LEDs............Table A-1. ODU-IDU Cable Connector Pinout ............A-1 Table A-2. E1/T1 Connector Pinout ................A-2 Table A-3.

  • Page 16: Chapter 1. Introduction

    Chapter 1 Introduction 1.1 Overview WinLink 1000 is a carrier-class, high capacity, Point-to-Point broadband wireless transmission system. WinLink 1000 combines legacy TDM and Ethernet services over 2.4GHz, 4.9GHz, and 5.xGHz license-exempt bands and is suitable for deployment in FCC, ESTI, or CSA regulated countries.

  • Page 17: Features

    Features Wireless Link WinLink 1000 delivers up to 48 Mbps data rate for Ethernet and E1/T1 traffic. The system supports a variety of spectrum bands and can be configured to operate in any channel on the band with a carrier step resolution of 5 MHz.
  • Page 18 Various external antennae are available for the WinLink 1000 operating frequencies. For example, an optional flat panel 28 dBi external antenna increases the operation range of WinLink 1000 up to 80 km (50 miles). Overview...

  • Page 19: Physical Description

    Chapter 1 Introduction WinLink 1000 Installation and Operation Manual 1.2 Physical Description WinLink 1000 system consists of an Outdoor Unit (ODU) and an Indoor Figure 1-2 Unit (IDU). illustrates a WinLink 1000 unit assembly. Figure 1-2. WinLink 1000 Units IDU-E...
  • Page 20 WinLink 1000 Installation and Operation Manual Chapter 1 Introduction Technical Specifications Air-Interface Technology OFDM Frequency Band 2.400–2.4835 GHz FCC/ETSI 2.416–2.4835 GHz (Israel) 4.940-4.990 GHz FCC 5.250–5.350 GHz FCC 5.470–5.725 GHz FCC/ETSI 5.725–5.850 GHz FCC Range Up to 80 km (50 miles)
  • Page 21 Chapter 1 Introduction WinLink 1000 Installation and Operation Manual Line Interface AMI, B8ZS Connector RJ-45 PWR (green) Power status Indicators IDU (green) IDU status ODU (green/red) ODU-to-IDU link status AIR I/F (green/red) Air Interface status SERVICE (green/red) E1/T1 signal status...
  • Page 22 WinLink 1000 Installation and Operation Manual Chapter 1 Introduction Temperature -35°C to 60°C/-31°F to 140°F Indoor Unit (IDU-E and IDU-C) Temperature -5°C to 45°C/23°F to 113°F Humidity Up to 90%, non-condensing Antenna Characteristics 2.400- 4.940- 5.250- 5.4470- 5.725- 2.4835 GHz 4.990GHz...

  • Page 23: Chapter 2. Installation And Setup

    Always observe standard safety precautions during installation, operation, and maintenance of this product. Note WinLink 1000 has three types of products: Auto channel selection is not supported–Previous or Future release. • Auto channel selection supported–User can enable/disable auto •...

  • Page 24: Site Requirements And Prerequisites

    -48VDC, and feeds the ODU by it. The IDU does not store any configuration data. Therefore, there is no need for additional configuration of the WinLink 1000 system when replacing an IDU. 2.2 Site Requirements and Prerequisites For the IDU, allow at least 90 cm (36 in) of frontal clearance for operating and maintenance accessibility.

  • Page 25: Installation And Setup

    External antenna (if ordered) ODU/IDU Cable at length ordered (optional) 2.4 Installation and Setup Physical installation of the WinLink 1000 system installation includes the following steps: 1. Installing ODU at both sites of the link. 2. Installing ODU cable and connecting ODU to IDU at both sites.

  • Page 26: Mounting The Odu

    Figure 2-1. Typical Installation Diagram Mounting the ODU The ODU is the transmitting and receiving element of the WinLink 1000 system. The ODU can be mounted on a mast or a wall. In both installations, the supplied mounting kit is used to secure the ODU.

  • Page 27: Connecting The Odu To The Idu

    WinLink 1000 Installation and Operation Manual Chapter 2 Installation and Setup Prior to connecting cables to the ODU, the protective earth terminal (screw) of the ODU must be connected to an external protective ground conductor or to a grounded mast.

  • Page 28: Connecting The Power

    Intentional interruption is prohibited. Power is supplied to WinLink 1000 via an external AC/DC converter, which receives power from 110–240 VAC source and converts it to -24VDC or -48 VDC.

  • Page 29: Installing Winlink 1000 Management Software

    For DC power model, connect to DC supply on the rack (male • connector for the terminal block is included). Installing WinLink 1000 Management Software WinLink 1000 management application is distributed on CD-ROM as an executable file. The application has the following PC requirements: Memory: 128 MB RAM •...

  • Page 30: Login Screen

    Chapter 2 Installation and Setup WinLink 1000 Installation and Operation Manual 3. Connect the management station to the LAN. Any PC running the WinLink 1000 Management application can be used to configure WinLink 1000 units. To start WinLink manager: 1. From the Start menu, point to Programs, point to WinLInk Manager, and then click WinLink Manager.

  • Page 31: Aligning The Winlink 1000 Odus

    Aligning the WinLink 1000 ODUs Perform the WinLink 1000 ODU alignment using the Buzzers located inside the ODUs. Alignment of a WinLink 1000 link must be performed by two people simultaneously, at site A and at site B. To align the ODUs via ODU Buzzer: 1.

  • Page 32: Installing The Link

    Chapter 2 Installation and Setup WinLink 1000 Installation and Operation Manual Do not stand in front of a live radio terminal. 2. Align the site A ODU in the direction of the site B ODU. Warning 3. Align the site B ODU in the direction of the site A ODU 4.

  • Page 33: Link Installation Wizard

    WinLink 1000 Installation and Operation Manual Chapter 2 Installation and Setup Figure 2-7. Link Installation Wizard 3. Click next to proceed with the Installation procedure. Figure 2-8 The system dialog box opens (see Installation and Setup 2-11...

  • Page 34: Installation Wizard, System Dialog Box

    Chapter 2 Installation and Setup WinLink 1000 Installation and Operation Manual Figure 2-8. Installation Wizard, System dialog box 4. Enter a SSID (System ID) minimum of eight characters. The ID is initially factory set. Notes Both sites of a link must always have the same number •...

  • Page 35: Installation Wizard, Channel Select Dialog Box

    WinLink 1000 Installation and Operation Manual Chapter 2 Installation and Setup Figure 2-9. Installation Wizard, Channel Select dialog box 9. Select the required operating channel. The pull down list shows the ISM frequencies available. The Manual option allows you a User defined channel, within the system frequency band.
  • Page 36 Chapter 2 Installation and Setup WinLink 1000 Installation and Operation Manual Figure 2-10. Installation Wizard, Channel Select dialog box (Automatic Channel Select enabled) Note This feature is for the 5.4GHz ETSI version product only. DFS/TPC–Dynamic Frequency Select/Transmit Power control: according to ETSI standard for the unlicensed band that eliminates interruption of the wireless data equipment to the radar service.

  • Page 37: Installation Wizard, Channel Select Dialog Box

    WinLink 1000 Installation and Operation Manual Chapter 2 Installation and Setup Figure 2-11. Installation Wizard, Channel Select dialog box (Supporting DFS, ETSI standard requirement) 10. Click Next. Figure 2-12 The Rate Select dialog box appears (see Table 1-1 lists throughput rates and capacities.

  • Page 38: Installation Wizard, Rates Dialog Box

    Chapter 2 Installation and Setup WinLink 1000 Installation and Operation Manual Figure 2-12. Installation Wizard, Rates dialog box 11. Select a suitable air interface rate according to the services required. 12. Click Evaluate. 13. A question box pops up, asking if you want to re-evaluate the link.

  • Page 39: Installation Wizard, Services Dialog Box

    WinLink 1000 Installation and Operation Manual Chapter 2 Installation and Setup Figure 2-13. Installation Wizard, Services dialog box 15. In the Service dialog box, select one of the following: E1/T1 – Select the E1/T1 field, if you intend to transmit E1/T1 data and Ethernet data.

  • Page 40: Connecting The User Equipment

    Chapter 2 Installation and Setup WinLink 1000 Installation and Operation Manual Figure 2-14. Installation Wizard, Finish Screen 17. Click Finish to complete the installation wizard. When the wireless link is established between the site A and site B units, the Link Status indication bar of the Main menu is within the green area.
  • Page 41 WinLink 1000 Installation and Operation Manual Chapter 2 Installation and Setup To connect user equipment to the IDU: 1. Connect user E1/T1 traffic to the appropriate IDU panel RJ-45 port Appendix A designated Trunk. Refer to for the connector pinout.

  • Page 42: Chapter 3. Configuration

    This chapter describes configuration procedures that are performed after the link has been installed, synchronized, and the link configuration has been performed by wizard. WinLink 1000 has three types of products: Note Auto channel selection is not supported–Previous or Future release.

  • Page 43: Winlink Manager Main Menu

    Chapter 3 Configuration WinLink 1000 Installation and Operation Manual Installation and definition of all parameters are applied to both sides of Note the link. Figure 3-1. WinLink Manager Main Menu To change general parameters: 1. In the Main menu, click the Link Configuration button.

  • Page 44: Configuration Link Wizard

    WinLink 1000 Installation and Operation Manual Chapter 3 Configuration Figure 3-2. Configuration Link Wizard 3. Click Next. Figure 3-3 4. The Link Configuration dialog box appears (see Performing Configuration of WinLink 1000...

  • Page 45: Link Configuration, System Dialog Box

    Chapter 3 Configuration WinLink 1000 Installation and Operation Manual Figure 3-3. Link Configuration, System dialog box 5. In the System dialog box, enter the new data to for the link. All fields with a white background can be edited. 6. Click Next.

  • Page 46: Link Configuration, Channel Select Dialog Box

    WinLink 1000 Installation and Operation Manual Chapter 3 Configuration Figure 3-4. Link Configuration, Channel select dialog box Selecting the Manual option provides the capability to configure the channel in 5 MHz steps in the specified band of the product. Some of the products support the Automatic channel selection. The Note mode is activated in normal operation mode.
  • Page 47 Chapter 3 Configuration WinLink 1000 Installation and Operation Manual By reselecting channel, the radio starts scanning all the channels from Note the available channels list and looks for radio activity in each of the channels. It tries to select the optimal channels. If another channels is desired the operating channel must be removed from the available channel list.

  • Page 48: Link Configuration, Channel Select Dialog Box With Dfs

    WinLink 1000 Installation and Operation Manual Chapter 3 Configuration This feature is for the 5.4GHz ETSI version product only. Note DFS/TPC – Dynamic Frequency Select / Transmit Power control – ETSI standard for the unlicensed band that eliminates interruption of the wireless data equipment to the radar service.

  • Page 49: Reselection Process

    Chapter 3 Configuration WinLink 1000 Installation and Operation Manual Figure 3-7. Channel reselection confirmation dialog box Figure 3-8. Reselection process Reselection process can take up to few minutes. A bar with activity Note displays the progress of the reselection process.

  • Page 50: Reselection Process "Channel Not Active In List

    WinLink 1000 Installation and Operation Manual Chapter 3 Configuration Figure 3-9. Reselection process "channel not active in list" 8. Click Next. Figure 3-10 The Rate Select dialog box appears (see Table 1-1 lists throughput rates and capacities. Figure 3-10. Air Interface Rate select Dialog Box 9.

  • Page 51: Configuring Service Parameters

    Chapter 3 Configuration WinLink 1000 Installation and Operation Manual The Evaluate button becomes enabled when a new rate has been Note selected. 11. A question box pops up, asking if you want to re-evaluate the link. Click Yes to change the rate or No to keep the existing rate.

  • Page 52: Service Parameters Dialog Box, E1/T1 Interface

    WinLink 1000 Installation and Operation Manual Chapter 3 Configuration Figure 3-11. Service Parameters Dialog Box, E1/T1 Interface Performing Configuration of WinLink 1000 3-11...

  • Page 53: Service Parameters Dialog Box, Ethernet Only Interface

    Chapter 3 Configuration WinLink 1000 Installation and Operation Manual Figure 3-12. Service Parameters Dialog Box, Ethernet only Interface 2. Click Next. Figure 3-13 The Finish screen appears (see The Finish screen shows a summary of the link configuration. 3-12 Performing Configuration of WinLink 1000...

  • Page 54: Editing The Configuration Parameters

    WinLink 1000 Installation and Operation Manual Chapter 3 Configuration Figure 3-13. Configuration Link, Finish screen 3. Click Finish to complete the configuration wizard. The Main screen is displayed. Editing the Configuration Parameters The configuration parameters can be edited for each site individually without running a wizard.

  • Page 55: Configuration Dialog Box

    Chapter 3 Configuration WinLink 1000 Installation and Operation Manual Figure 3-14. Configuration Dialog Box 3. In the Configuration dialog box, edit the data to for the link: System Tab – The contact person and location details can be edited. Air Interface Tab – Used for changing the transmit power Inventory Tab –...

  • Page 56: Changing The Transmit Power

    WinLink 1000 Installation and Operation Manual Chapter 3 Configuration Changing the Transmit Power Each ODU can be configured to have a different transmit power level. To change the Transmit Power: 1. Click configuration from the main menu. 2. Select which site to configure.

  • Page 57: Configuration, Management

    Chapter 3 Configuration WinLink 1000 Installation and Operation Manual Figure 3-16 3. Click the Management Tab (see 4. Enter the IP address of the ODU in the IP address field. Note If performing configuration from the WinLink manager, the IP address...

  • Page 58: Bridge Configuration

    WinLink 1000 Installation and Operation Manual Chapter 3 Configuration The Install mode button opens the Main Window for installation mode Notes for reinstalling the link. The Backup and Restore buttons are for saving and restoring the configuration files. 3.2 Bridge Configuration Bridge configuration is required in various network topologies, such as protection (1+1) and ring application.
  • Page 59 Chapter 3 Configuration WinLink 1000 Installation and Operation Manual ODU Bridge Mode This parameter controls the ODU mode with two optional values, Bridge Mode (default) (Figure 3-17 ). In "bridge" mode the ODU • performs both learning and aging, the aging time of the ODU if fixed.

  • Page 60: Hub Mode Selected

    WinLink 1000 Installation and Operation Manual Chapter 3 Configuration Figure 3-18. Hub mode selected Bridge Configuration 3-19...

  • Page 61: Chapter 4. Operation

    IDU-C indications, performance monitoring and turn-off) 4.1 Indicators Panel Indicators The panels of WinLink 1000 include a series of LED indicators that show the operating status of the unit. Figure 4-1, below shows the front panel of the WinLink 1000 unit, Table 4-1 describes the indicators.

  • Page 62: Connector Led Indicators

    ON – Alarm detected at the remote interface ON – Local or Remote loopback ON – Alarm detected at the local interface Connector LED Indicators The IDU connectors of WinLink 1000 have LED indicators that show the Table 4-4 operating status. describes the indicators.

  • Page 63: Operating Winlink 1000

    The PWR indicator lights up and remains lit as long as the IDU is receiving power. WinLink 1000 requires no operator attention once installed, with the exception of occasional monitoring of front panel indicators and statistics data. Intervention is only required when WinLink 1000 must be configured to its operational requirements, or diagnostic tests are performed.

  • Page 64: Normal Indications

    Chapter 4 Operation WinLink 1000 Installation and Operation Manual Normal Indications Upon turning on WinLink 1000, the PWR LED in the IDU front panel Table 4-4 lights to indicate that WinLink 1000 is on. shows the correct status of the indicators at power-up.

  • Page 65: Managing Winlink 1000

    WinLink 1000 Installation and Operation Manual Chapter 4 Operation 4.3 Managing WinLink 1000 Before starting a management session, make sure that a communication link between local and remote units exists, the Link Status indication bar in the middle of the Main menu must be green;...
  • Page 66 Chapter 4 Operation WinLink 1000 Installation and Operation Manual Exiting WinLink Manager (Exit button) Menu bar • File Menu – Log off, and exit Configuration – use for link configuration, individual site configuration or link installation Tools – set preferences, event log handling, change password Maintenance –...

  • Page 67: Resetting Winlink 1000

    In order to maintain the communication link, always reset the remote WinLink 1000 first To reset WinLink 1000: 1. Click on maintenance, select the remote WinLink 1000 to reset. 2. Click on maintenance, select the local WinLink 1000 to reset. Saving WinLink 1000 Configuration in a File...

  • Page 68: Restoring A Configuration File

    Restoring a Configuration File Configuration files (*.ini) can be uploaded from the management station, if the WinLink 1000 database becomes corrupted. This can also be used to distribute verified configuration files to all other units that use the similar configuration.

  • Page 69: Winlink 1000 Inventory

    WinLink 1000 Installation and Operation Manual Chapter 4 Operation Figure 4-3. WinLink 1000 Inventory Managing WinLink 1000...

  • Page 70: Chapter 5. Diagnostics And Troubleshooting

    Diagnostic tests (local and remote loopbacks on E1 or T1 link). • 5.1 Error Detection and Alarms WinLink 1000 detects fault conditions of the radio and user links and initiates alarms to alert the user. Note To store the event log, first define the IP address, subnet mask, default...

  • Page 71: Collecting And Saving Statistics

    No ODU-to-IDU traffic was detected during the last 20 connection to the link minutes. 5.2 Collecting and Saving Statistics WinLink 1000 constantly monitors traffic over the radio link and collects the following statistics data: Site 1/Site 2 received traffic rate (in Kbps) •...

  • Page 72: Running Diagnostic Loopbacks

    5. Set the time interval for adding data to the file. Figure 5-1. Preferences Dialog Box, Event Log Tab 5.3 Running Diagnostic Loopbacks WinLink 1000 supports activation of the internal and external loopbacks on the local and remote units. To activate a loopback: 1.

  • Page 73: Local External Loopback

    Figure 5-2. Loopbacks Dialog Box Local External Loopback Local WinLink 1000 can be set to an external loopback to test the local E1/T1 port and its connection to the local side user equipment. In this mode, data coming from the local user equipment is looped back to it...

  • Page 74: Remote Internal Loopback

    Figure 5-4. Remote Internal Loopback Remote External Loopback Remote WinLink 1000 can be set to an external loopback to test the remote E1/T1 port and its connection to the remote side user equipment. In this mode, data coming from the remote user equipment...

  • Page 75: Local Internal Loopback

    Figure 5-5. Remote External Loopback Local Internal Loopback Local WinLink 1000 can be set to close an internal loopback to test connection between the local and remote units, remote E1/T1 port and its connection to the remote side user equipment. In this mode, data...

  • Page 76: Troubleshooting With Winlink 1000 Leds

    WinLink 1000 Installation and Operation Manual Chapter 5 Diagnostics and Troubleshooting Table 5-2. Troubleshooting with WinLink 1000 LEDs Status Remedy Check that AC adapter is connected to the IDU and the AC power outlet. Orange Check that the IDU/ODU cable is properly wired and connected.

  • Page 77: Frequently Asked Questions

    Q: When using the WinLink 1000, what is the potential for interference between our system and other cellular or wireless Networks devices? A: The WinLink 1000 is a robust system. However, since it operates in unlicensed band, there maybe some interference. Nevertheless, the fact that we can manually set the frequency gives us the flexibility to find a clear channel.

  • Page 78: Management

    5.735 MHz. Q: Can I use the WinLink 1000 with any vendor external antenna? A: Yes. RADWin supplies the WinLink 1000 external ODU with an N- type typical connector. Any vendor external antenna that can be cascaded to our external unit can be use without problem.

  • Page 79: Services

    The WinLink 1000 is a symmetrical system Q: Does WinLink 1000 withhold any MAC Addresses? A: The WinLink 1000 is a layer 2 Bridge (VLAN transparent). The built in switch contains a MAC Address table up to 2047. Q: What are the BER values expected in the WinLink 1000 link?

  • Page 80: Technical Support

    WinLink 1000 Installation and Operation Manual Chapter 5 Diagnostics and Troubleshooting Q: What are the main advantages of the WinLink 1000 solution (e.g., wireline, wireless, etc.) over other possible alternatives? Easy and intuitive installation using audio indication Easy configuration using the management software of overall link site to site –...

  • Page 81: Table A-1. Odu-Idu Cable Connector Pinout

    Appendix A Wiring Specifications A.1 ODU-IDU Cable The ODU-IDU cable is standard CAT-5, 4 twisted-pair 24 AWG FTP. The ODU-IDU cable is terminated in RJ-45 connectors on both ends. It is covered by a cable gland on the ODU side for hermetic sealing. Table A-1 shows the connector pinout.

  • Page 82: Table A-2. E1/T1 Connector Pinout

    Appendix A Wiring Specifications WinLink 1000 Installation and Operation Manual A.2 User Port Connectors The IDU includes ports for connecting E1/T1 and 10/100BaseT Ethernet user devices. Trunk Port The Trunk (E1/T1) interface terminates in an 8-pin RJ-45 balanced Table A-2 connector, wired in accordance to Table A-2.

  • Page 83: Table A-4. Terminal Block 3-Pin -48Vdc

    WinLink 1000 Installation and Operation Manual Appendix A Wiring Specifications A.3 IDU-C connectors Table A-4. Terminal Block 3-pin -48VDC Connection ‘+’ Right Chassis Center ‘-’ Left Table A-5. Alarm Connector (Dry-Contact) Description Input #1 Positive Input #1 Negative Input #2...
  • Page 84 Appendix B Mast and Wall Installation Mounting the ODU The ODU can be mounted on a mast or a wall. ODU Mounting Kit Contents The ODU mounting kit includes the following items: One Large Clamp (see figure B-1) • One Small Clamp (see figure B-2) •...
  • Page 85 Appendix B Mast and Wall Installation WinLink 1000 Installation and Operation Manual Mounting WinLink 1000 on a Mast Mounting the ODU...
  • Page 86 WinLink 1000 Installation and Operation Manual Appendix B Mast and Wall Installation Mounting WinLink 1000 on a Wall Mounting the ODU...
  • Page 87 Appendix B Mast and Wall Installation WinLink 1000 Installation and Operation Manual Mounting an External Antenna The optional external antenna can be mounted on a mast. External Antenna Mounting Kit Contents The external antenna mounting kit includes the following items: Twelve flat washers •...
  • Page 88 Appendix C Link Budget Calculator C.1 Overview The Link Budget Calculator is a utility for calculating the expected performance of the WinLink wireless link and the possible configurations for a specific link range. The utility allows you to calculate the expected RSS of the link, and find the type of services and their effective throughput as a function of the link range and deployment conditions.
  • Page 89 Link Budget Calculator WinLink 1000 Figure C-1. Accessing the Link Budget Manager Calculator C.2 Using the Link Budget Calculator The Link Budget Calculator comprises of one table where all the link parameters are defined. Using the Link Budget Calculator...
  • Page 90 WinLink 1000 Link Budget Calculator Figure C-2. Link Budget Screen To calculate the link budget 1. Select your WinLink system product from the dropdown list of products. 2. Select the rate from the dropdown list. The rate defines the air- interface rate in Mbps.
  • Page 91 Link Budget Calculator WinLink 1000 The Tx power EIRP for the system is given in dBm and Watts. 3. Select the required link distance and units of distance, kilometers or miles. 4. Click Calculate The Expected Performance parameters are calculated and displayed in the lower part of the table.
  • Page 92 Appendix D TDM Clock Configuration Overview This appendix describes the WINLink 1000 TDM clock configuration. The following picture describes the E1 or T1 service configuration. Figure D-1. E1 or T1 service configuration External clock requirements WINLink 1000 system assumes that all external equipments connected to a single site use the same transmit clock.
  • Page 93 • Each line state change in the selected trunk re-triggers a new clock selection according the above rules. If the selected trunk is in Los of Signal state, the WINLink 1000 uses its internal clock. There are two methods to configure the user equipment.
  • Page 94 Example 2 Trunk 1 is disconnected and trunk 2 is in normal condition. WINLink 1000 shall select trunk 2 for clock timing. Since trunk 1 is disconnected it uses an internal clock as an input clock. The OUT clock of both trunks is the re-generated clock IN 2, and therefore WINLink 1000 shall display error blocks on clock 1 (represents the clock difference between the internal clock and the IN 2 clock).
  • Page 95 Index Connecting the Power, 2-6 —A— Connectors Air Interface Rate, 3-9, 2-16 IDU-C, A-3 Alarms, 4-1, 4-2, 4-4, 5-1, 5-7 user port, A-2 list of, 5-2 Contents, of package, 2-2 Aligning the ODUs, 2-9 —D— Antenna, 2-3 Default gateway, 3-16 automatic channel select, 3-5, 3-7, 2-13 DFS, 3-4, 3-6, 3-7, 2-12, 2-14 —B—...
  • Page 96 Index WinLink 1000 Installation and Operation Manual Independent mode, D-2 ODU, 2-4 wall, B-3 Indications, 5-7 Indicators, 4-1, 4-2, 4-4 —N— Information messages, 5-2 Normal Installation, 2-1, 2-3, 2-4 line state, D-2 of software, 2-7 performing, 2 —O— prerequisites, 2...
  • Page 97 WinLink 1000 Installation and Operation Manual Index —R— Temperature, operating, 2-2 Radio link status, 4-6 timing, D-2 examples, D-3 Radio signal strength, 4-6 Toolbar, 4-5 Rate, selecting, 3-9, 2-16 TPC, 3-6, 3-7, 2-14 ratio Traffic rate, 4-6 different clocks, D-3...
