Type Acceptance Test Report Multimode PCS Repeater FCC Rule Parts: 2, 15 & 24 ACS Report Number: 03-0089-24TA Manufacturer: EMS Wireless Model: Link2Cell Installation Guide 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598... - Page 2 Link2Cell™-19 SOHO Signal Enhancer Small Office – Home Office SIGNAL ENHANCER OPERATOR’S MANUAL 2850 Colonnades Court NW Norcross, GA 30071 Phone: 770-582-0555 Fax: 770-729-0075 Email: www.emswireless.com...
- Page 3 Every attempt has been made to make this material complete, accurate, and up-to-date. Users are cautioned, however, that EMS Wireless reserves the right to make changes without notice and shall not be responsible for any damages, including consequential, caused by reliance on the material presented, including, but not limited to, typographical, arithmetical, or listing errors.
- Page 4 Preliminary Document Confidential EMS Wireless WARNINGS, CAUTIONS, AND GENERAL NOTES This product conforms to FCC Part 15. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 5 WARNING until described conditions are fully understood and met. If You Need Help If you need additional copies of this manual, or have questions about system options, or need help with installation and using of the system, please contact EMS Wireless’ Sales Department. EMS Wireless Sales Dept.
- Page 6 30 days of discovery of a defect within the warranty period. This warranty is the only warranty made by EMS Wireless and is in lieu of all other warranties, expressed or implied, except as to title, and can be amended only by a written instrument signed by an officer of EMS Wireless.
- Page 7 Prior to repair, EMS Wireless Customer Service will advise the customer of EMS Wireless test results and will advise the customer of any charges for repair (usually for customer caused problems or out-of-warranty conditions).
- Page 8 Preliminary Document Confidential EMS Wireless Handling the Link2Cell™ -19 1. Use ESD precautions when dealing with the modules within the Link2Cell™ -19 so that units are not damaged. 2. Opening the unit voids warranty. 3. Disconnecting any component within the Link2Cell™-19 when powered can damage or destroy the equipment and will void the warranty.
- Page 9 Preliminary Document Confidential EMS Wireless Link2Cell™-19 Manual Description The Link2Cell™-19 SOHO, (Small Office-Home Office) Signal Enhancer, is a PCS band, bi- directional amplifier unit and was designed to provide enhanced RF coverage for wireless systems in small facilities. Usage includes providing coverage in retail stores, offices, warehouses, restaurants, homes, etc.
- Page 10 Preliminary Document Confidential EMS Wireless Red indicator. User can try recycling the power which will allow the unit to go thru its automatic set up operation but if the problem persists contact your service provider. Indicators The Link2Cell™-19 is equipped with three LED indicators on the end of the unit which...
- Page 11 Preliminary Document Confidential EMS Wireless Primary Power The Link2Cell™ Unit operates on 9 VDC input power @ 1 Amp. This is supplied with a regulated wall mount supply, which is UL, and CSA listed. These are available to operate on AC input voltage of 115 VAC.
- Page 12 Preliminary Document Confidential EMS Wireless Installation: Note 1: The user is cautioned that modification or changes to this device not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Note 2: Manufacturer’s rated composite output power, individual channel power will vary depending on the number of channels and distance from each cell site being received Note 3: This device complies with Part 15 of the FCC Rules.
-
Page 13: Package Contents
Preliminary Document Confidential EMS Wireless Getting Started: Unpack all of the boxes and insure all of the material is included for your installation requirements and undamaged in shipment. Quantity Part Description Link2Cell™ SOHO Signal Enhancer Loctite Thread locker Power Converter... -
Page 14: Optional Mounting Configurations
Preliminary Document Confidential EMS Wireless Link2Cell™-19 Unit Orientation & Installation Link2Cell™ is designed for optimum use as an in-door signal enhancer. The housing is not weather resistant and the automatic set up procedure assumes sufficient isolation between antennas. Since the Link2Cell™ has a total of 53 dB active gain and an isolation of 73 dB must be obtained between the internal donor and the server antenna. - Page 15 Preliminary Document Confidential EMS Wireless -Select the window that provides the strongest signal strength from the cell site to your portable phone by viewing the number of bars displayed on the face of the phone. - Select the location in the window that provides the strongest signal strength from the cell site to your portable phone which will indicate how to position the Link2Cell™...
- Page 16 Preliminary Document Confidential EMS Wireless Attach Mounting Base (with the open U potion in an upward ? position) to the selected position mounting surface area using the appropriate mounting hardware, (4 Wall anchors and 4 mounting screws). Slide Link2Cell Unit...
- Page 17 Preliminary Document Confidential EMS Wireless IMPORTANT: Before performing any maintenance or changing the position or location of the unit, make sure power plug is removed from the 110 AC wall socket. Once the unit is repositioned, the power should be plugged into the 110 wall socket, this will insure the unit is set to maximum gain and performance.
- Page 18 Preliminary Document Confidential EMS Wireless Trouble Shooting: The Link2Cell™-19 has no field replaceable parts; repair is limited to improper mounting location with respect to the cell site, insufficient RF signal levels, and installation or defective units. Problem Check Corrective Action...
