  • Page 1 Swegon Home Solutions CASA R3 Smart ® Installation, commissioning and maintenance instruction R3_d_EN-t...
  • Page 2: Table Of Contents

    2.1.1 Wall mounting ..............6 7.4.4 Supervision (DDC) ............25 2.1.2 Ceiling mounting ............6 7.5 Control diagram ............26 2.1.3 Swegon CASA cooker hood directly connected to the 7.6 Dimensions ..............27 ventilation unit ..............7 7.7 Weights .................27 2.1.4 Swegon CASA cooker hood separated from the 7.8 Ventilation unit codes ............27...
  • Page 3: Important Information

    NOTE! The manual’s original language is Finnish. Swegon reserves the right to alter specifications. www.swegonhomesolutions.com...
  • Page 4: General Description

    3–4 °C lower than the room temperature, so 1.2 Fans that the supply air mixes fully with the room air. The Swegon CASA R3 is equipped with energy-efficient Remember the following when setting the supply air fans with EC motors, advantageous in that their speed...
  • Page 5 The functions related to the current sen- sor in question are deactivated and the ventilation unit works as well as possible. The ventilation unit’s function returns to normal once the fault has been corrected. Swegon reserves the right to alter specifications. www.swegonhomesolutions.com...
  • Page 6: Installation

    Wall mounting bracket’s dimensions The ventilation unit can also be installed in the kitchen like a wall cabinet above the cooker and a Swegon CASA Jazz cooker hood can be mounted directly to the If the wall is composed of vertical studs and wall boards, unit, i.e.
  • Page 7: Swegon Casa Cooker Hood Directly Connected To The Ventilation Unit

    2.1.3 Swegon CASA cooker hood directly connected to the ventilation unit ∅ 125 mm The Swegon CASA Jazz cooker hood can be mounted Acoustic insulation directly against the ventilation unit, and in this case the extract air duct should be connected directly to the duct connection on the bottom of the unit.
  • Page 8: Swegon Casa Cooker Hood Separated From The Ventilation Unit

    The compatible Swegon CASA cooker hood can be mounted separately from the ventilation unit, and in The hose for removing condensed water is available that case the extract air is conveyed from the cooker as an accessory (part number 502103).
  • Page 9: Sealing Around Duct Penetration Collars

    For this reason, Swegon does not offer any rec- ommendations for insulation thickness. Most manufac- turers of insulation material offer calculation programs for the calculation of sufficient and correct insulation.
  • Page 10: Electric And Control Cables

    There is a modular cable for control on top of the ventilation unit. There is a modular cable for the cooker hood located under the cover plate at the bottom of the ventilation unit. www.swegonhomesolutions.com Swegon reserves the right to alter specifications.
  • Page 11: Installation Of The Smart Control Panel

    If several control panels are connected in chain, the middle panel’s bus termination is moved to the “Open” position. The jumpers do not need to be adjusted if only one control panel is used. Bus termination: Terminated Bus termination: Open Swegon reserves the right to alter specifications. www.swegonhomesolutions.com...
  • Page 12: Commissioning

    It is recommended in order to improve the efficiency of the ventilation to use an automatic moisture sensor or to actively use the ventilation unit’s boost speed, if there is a sauna, pool or equivalent moisture producer in the home. www.swegonhomesolutions.com Swegon reserves the right to alter specifications.
  • Page 13: Selection Of Smart Functions

    The function starts automatically when the damper in a compatible cooker hood is opened and runs until the damper is closed. Swegon reserves the right to alter specifications. www.swegonhomesolutions.com...
  • Page 14: Sensor

    Variable control occurs between the voltages 2 V - 5 V - 8 V. The ventilation then switches variably between op- erating modes Away - Home - Boost. Otherwise, control is performed according to the normal DDC control. www.swegonhomesolutions.com Swegon reserves the right to alter specifications.
  • Page 15: Damper Motors

    This menu is used to change the code to access the set- ting menu. 3.11 Use Issues with reference to the usage of the ventilation system are dealt with in the instructions for use supplied with the unit. Swegon reserves the right to alter specifications. www.swegonhomesolutions.com...
  • Page 16: Service

    The ventilation unit must not be operated without filters. should be left to a professional. Use only filters recommended by Swegon in the ventila- tion unit. This is important, as filters with exactly the same 4.6 Other servicing...
  • Page 17 R3.051016 Important The ventilation unit must not be operated without filters! Use only filters recom- mended by Swegon in the ventilation unit. Find the correct filter in the Section enti- tled: ”Technical data”. 1. Supply air filter 2. Extract air filter 3.
  • Page 18: Alarms And Troubleshooting

    (2 years), contact our network of authorised service companies on www.swegonhome- solutions.com, your real estate company’s service divi- sion or another service company that is fully conversant with ventilation repairs. www.swegonhomesolutions.com Swegon reserves the right to alter specifications.
  • Page 19 A malfunction in ventilation performance could be caused by any component of the ventilation system or by the way the sys- tem has been installed. Normal operation of the Swegon CASA ventilation unit is described in the user’s instructions supplied with the unit on delivery.
  • Page 20: List Of Components

    Inspection door cover plate (stainless steel): PR085B6R 8. Complete door with white front plate: DR85BRL1 • Swegon CASA Jazz cooker hood for location below 9. Front plate of the front cover (white): PR085B6V the ventilation unit (stainless steel, white) 9. Front plate of the front cover (stainless): PR085B6R 10.
  • Page 21: Technical Data

    Air heater, reheating 500 W Total output 250 W 750 W Cooker hood 15 W 15 W Total output, cooker hood* 265 W 765 W * Swegon CASA Jazz cooker hood connected below R3. Swegon reserves the right to alter specifications. www.swegonhomesolutions.com...
  • Page 22: Acoustic Data

    *) Equivalent to a normally insulated room. If sound power level L , dB (A) values are required, the 4 units (dB) need to be added to the table values. www.swegonhomesolutions.com Swegon reserves the right to alter specifications.
  • Page 23: Electrical Wiring Diagram

    4. Air heater, reheat, 500 W (accessory) 5. Door contact 6. Smart sensor package RH (accessory) RH + CO (accessory) RH + VOC (accessory) 7.4.2 R3, CASA Jazz cooker hood and control panel Swegon reserves the right to alter specifications. www.swegonhomesolutions.com...
  • Page 24: Control Functions With Accessories

    BUS TERMINATION 1. Fireplace switch 11. Swegon CASA Smart Modbus GW 2. Boost timer 12. Swegon CASA Smart control panel (UP1) 3. Humidity sensor 13. Swegon CASA Smart control panel (UP2) 4. Timer *) The use of the duct damper should be judged on the 5.
  • Page 25: Supervision (Ddc)

    = 10 VDC 3: Alarms – signal from the ventilation unit (earthed contact)* 2: Emergency stop/fire alarm (if contact between termi- nals 1–2 is broken, the ventilation unit will stop)* 1: 0 V (GND) Swegon reserves the right to alter specifications. www.swegonhomesolutions.com...
  • Page 26: Control Diagram

    CONTROL FUNCTIONS: The ventilation unit can be operated from a separate Smart control panel or a Swegon CASA cooker hood. When the ventilation unit is controlled from the cooker hood in the Home/Away/Boost modes and for local extraction, the time can be set to 30, 60 or 120 minutes.
  • Page 27: Dimensions

    R03VL05S00H PR085B6R • R3 Smart R 500 W RH CO R03VR05S00C • Swegon CASA Jazz cooker hood for location below R3 Smart L 500 W RH CO R03VL05S00C the ventilation unit (stainless steel, white) • R3 Smart R 500 W RH VOC...
  • Page 28: Commissioning Form

    Important The supply airflow must be 2–10 % lower than the extract airflow. Remember to explain the use of the item of optional equipment and how to service it to the user/caretaker! www.swegonhomesolutions.com Swegon reserves the right to alter specifications.
  • Page 29: Warranty Conditions

    (= written receipt of purchase). After the warranty period has expired, warranty claims, which have not been submitted in writing prior to the expiration date of the warranty period, are not valid. Swegon ILTO Oy, Asessorinkatu 10, FIN-20780 S:t Karins, www.swegonhomesolutions.com. Swegon reserves the right to alter specifications.
  • Page 30: Ec Declaration Of Conformity

    R3.051016 www.swegonhomesolutions.com Swegon reserves the right to alter specifications.
  • Page 31 R3.051016 Swegon reserves the right to alter specifications. www.swegonhomesolutions.com...
  • Page 32 Quick Guide 50 kg 230 V 10 A ≥ 100 mm 3/8” Suomenkielinen Asennus-, käyttöönotto- ja huolto-ohje löytyy osoitteesta www.swegonhomesolutions.fi (Työkalut > Etsi PDF-tiedosto “R3”) En svenskspråkig Installations-, drifttagnings- och underhållsanvisning finns på adressen www.swegonhomesolutions.se (Toolbox > Hitta PDF “R3”) En norskspråklig Installasjons-, igangkjørings- og vedlikeholdsveiledning finnes på...
