Specifications; Accessory Package; Parts Included; Step 1 - Flexispot H2S Installation Manual

Specifications

Pitch Quantity
2
Max. Weight Capacity 176 Ibs (80 kg)
28.3"
-
48.4"
(720 - 1230mm)
Adjustable Height
Wide expand 43.3" - 70.9" (1100 - 1800mm)

Accessory Package

Figures shown are for reference only. Please contact customer service if there are any accessories or
tools missing.
A B C
x1 x1
5x5 4x4
G H
x24
x8
M8 x 35 mm St4.2 x 16 mm
Bolt
Screw

Parts Included

Qty
NO. Parts NO. Parts
1 2 2
3 4
1
5 1 6
7 8
1
9 10
1
02
D E F
x1
x2 x6
3x3
Square
M8 x 16 mm
M5 x 8 mm
gasket
Screw
Diagram of Components
Qty
1
1
1
1
1

Step 1

Turn the legs (2,3) upside down. Attach the feet (1) to the bottom of the legs using 8pcs M8x16mm
bolts (F) and tighten with 5x5 hex key (A).
x8
Bolt
1

Step 2

Attach the legs (2, 3) to the cross bar (4) using 4pcs of the M8x35mm bolts (G). Use the 5x5 hex key
to lock bolts firmly in place. Then, using the 4x4 hex key (B), adjust the 8 screws on the bottom of the
cross bar (4) so that they will accommodate the actual size of your work surface.
A
G
(1100 - 1800mm)
2
3
2
A
F
43.3" - 70.9"
3
Note:
Tighten those screws in case of the
cross bar sagged.
A
F
03
