Step 3; Step 4; Step 5 - Flexispot H2S Installation Manual

Step 3

Slightly loosen the adjustable nuts to adjust the length of the drive shaft (5). Insert the assembled
drive shaft into the slots that located at the top of each leg.
Loosen the adjustable nut
5
Insert to the slots
Tighten the nut
Adjust the length of drive shaft

Step 4

Using the hex key (A), connect both the left and right side brackets (6, 7) to the bottom legs
using 4 bolts (G).
7
A
G
6
04
7
Please note:
Do not misplace the two brackets (6, 7).

Step 5

Insert the crank shaft (8) into the right leg which has a shaft hole, using 2pcs bolts (D) and lock firmly
with hex key (C).
Then insert crank handle (9) into crank shaft (8).
D
8
C
9
05
