b) Resetting the capacity counter
In the case of recent systems, such as the PowerBox Baselog, Competition and
Cockpit, and also the SRS types, the magnet trigger can also be used to erase the
capacity counter. This is accomplished by repeatedly moving the ring magnet to
and from between the two LEDs or switching points, as if you were trying to wipe
something off. After five contacts have been made, you will hear an audible signal,
and the backer's integral screen displays the Reset message.

3. SPECIFICATION

Energy source:
Current drain:
Temperature range:
Weight:
EMV apporval:
CE approval:
WEEE-Reg.-No.:
The MagSensor satisfies the EMV protective requirements, EN 55014-1:2006,
with certificate dated 10 February 2009. EMC approval 2004/108/EG.
Cautlon: The magnet trigger contains a powerful permanent magnet. Keep
well away from heart pacemakers and magnetic data media such as EC and
credit cards, etc.
www.powerbox-systems.com
from the connected PowerBox
Power-on state approx. 10mA
Power-off state approx. 20µA
-30 °C to +75 °C
10 g
EN 55014-1 :2006
2004/108/EG
DE 639 766 11
5
