Summary of Contents for PowerBox Systems MagSensor

  • Page 1 Instruction Manual...
  • Page 2 SensorSwitch. The basic purpose of the MagSensor is to switch the dual power circuits on and off, but it can also be used to reset the capacity display fitted to more recent systems, if this is an integral feature of the PowerBox.
  • Page 3 The MagSensor is designed to be mounted in your model in either of two ways: a) Fully concealed Installation The MagSensor is designed in such a way that the two Hall sensors for both pow- er circuits can be „addressed“ from the front or back of the MagSensor.
  • Page 4 2. OPERATING THE MAGSENSOR a) Switching on and off The MagSensor still requires you to activate both power circuits individually - as with all PowerBox systems. The reason behind this feature is that the PowerBox contains two redundant switching and regulatory systems. Separate control also gives you the opportunity to check each of the PowerBox‘s power circuits indivi-...

  • Page 5: Specification

    2004/108/EG WEEE-Reg.-No.: DE 639 766 11 The MagSensor satisfies the EMV protective requirements, EN 55014-1:2006, with certificate dated 10 February 2009. EMC approval 2004/108/EG. Cautlon: The magnet trigger contains a powerful permanent magnet. Keep well away from heart pacemakers and magnetic data media such as EC and credit cards, etc.

  • Page 6: Set Contents

    4. DIMENSIONS 5. SET CONTENTS - MagSensor with 40 cm connecting lead - Magnet trigger containing ring magnet - Double-sided adhesive tape - Key-ring - Blue key fob - Operating instructions in German and English PowerBox-Systems − World Leaders in RC Power Supply Systems...

  • Page 7: Service Note

    6. SERVICE NOTE We are anxious to offer good service to our customers, and to this end we have set up a Support Forum which deals with all queries concerning our products. This relieves us of a great deal of work, as it eliminates the need to answer frequently asked questions time and again.

  • Page 8: Guarantee Conditions

    They are guaranteed “Made in Germany”! That is why we are able to grant a 36 month guarantee on our MagSensor from the initial date of purchase. The guarantee covers proven material faults, which will be corrected by us at no charge to you. As a precautionary measure, we are obliged to point out that we reserve the right to replace the unit if we deem the repair to be economically unviable.

  • Page 9: Liability Exclusion

    For this reason we deny liability for loss, damage or costs which arise due to the use or operation of the MagSensor, or which are connected with such use in any way. Regardless of the legal arguments employed, our obligation to pay compen- sation is limited to the invoice total of our products which were involved in the event, insofar as this is deemed legally permissible.
  • Page 10 11/2017 PowerBox-Systems GmbH certificated according to DIN EN ISO 9001:2008 Ludwig-Auer-Straße 5 D-86609 Donauwoerth Germany +49-906-99 99 9-200 +49-906-22 45 9 www.powerbox-systems.com...
