Fujitsu ASY14FSBCW Service Manual

Wall mounted type
Hide thumbs Also See for ASY14FSBCW:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , Operating Manual
SPLIT TYPE ROOM AIR
CONDITIONER

WALL MOUNTED TYPE

Indoor unit
ASY14FSBCW AOY14FSBC
ASY14USBCW AOY14USBC
CONTENTS
. . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . . . . . . . . . 4
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .13
. . . . . . . . . . . . . . . . . . . . . 15
Outdoor unit
. . . . . . . . . . . 2
. . . . . 3
6
. . . . . . . . . . . . . . .
8
. . . . . . . . . 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASY14FSBCW and is the answer not in the manual?

Questions and answers

Related Manuals for Fujitsu ASY14FSBCW

Summary of Contents for Fujitsu ASY14FSBCW

  • Page 1: Table Of Contents

    SPLIT TYPE ROOM AIR CONDITIONER WALL MOUNTED TYPE Indoor unit Outdoor unit ASY14FSBCW AOY14FSBC ASY14USBCW AOY14USBC CONTENTS ....1 SPECIFICATIONS ... 2 OUTLINE AND DIMENSIONS .

  • Page 2: Specifications

    SPECIFICATIONS ELECTRICAL DATA Cooling Cooling & Heating TYPE INDOOR UNIT ASY14FSBCW ASY14USBCW AOY14FSBC AOY14USBC OUTDOOR UNIT 4.20 kW 4.25 kW COOLING CAPACITY 4.80 kW HEATING CAPACITY ------ 230V 50Hz POWER SOURCE 230V 50Hz 6.6 A 6.1 A Cooling RUNNING CURRENT 5.6 A...

  • Page 3: Outline And Dimensions

    DIMENSIONS Unit : mm INDOOR UNIT OUTDOOR UNIT 2004.09.07...

  • Page 4: Refrigerant System Diagram

    REFRIGERANT SYSTEM DIAGRAM Models : ASY14FSBCW / AOY14FSBC [ INDOOR UNIT ] Evaporator (Flare connection) (Flare connection) [ Connecting pipe ] Gas pipe (12.7 dia.) Liquid pipe (6.35 dia.) (Flare connection) (Flare connection) [ OUTDOOR UNIT ] 3-Way valve 2-Way valve...

  • Page 5: Circuit Diagram

    CIRCUIT DIAGRAM Model : ASY14FSBCW CONTROL BOARD ORANGE YELLOW PINK CN201 BLUE STEPPING WHITE MOTOR WHITE WHITE TEST WHITE WHITE WHITE BLACK BLACK BLACK THERMISTOR (PIPE TEMP.) BLACK BLACK BLUE BLACK YELLOW WHITE THERMISTOR BLACK (ROOM TEMP.) POWER GREEN RELAY...
  • Page 6 Model : ASY14USBCW Model : AOY14USBC FAN MOTOR WHITE TERMINAL CAPACITOR DARK GRAY WHITE WHITE COMPRESSOR COMPRESSOR CAPACITOR FAN MOTOR OVER LOAD FOUR WAY RELAY VALVE COIL BLACK DARK GRAY BLACK 2005.08.03...

  • Page 7: Pcb Circuit Diagram

    INDOOR PCB CIRCUIT DIAGRAM Model : ASY14FSBCW BLUE POWER SOURCE 220 / 240V BROWN 50Hz GREEN / YELLOW Controller PCB assy ( main PCB ) K02DG-0401WSE-C1 I C 1 uPD780024ASGB-X49-8ET-A TERMAL FUSE R4 1.0K 2P-SAN ROOM TEMPERATURE THERMISTOR R25 - R24 <1/10W>...
  • Page 8 Model : ASY14USBCW BLUE POWER SOURCE 220 / 240V BROWN 50Hz GREEN / YELLOW Controller PCB assy ( main PCB ) K02DG-0400HSE-C1 I C 1 uPD780024ASGB-X49-8ET-A TERMAL FUSE R4 1.0K 2P-SAN ROOM TEMPERATURE THERMISTOR R25 - R24 <1/10W> AN I 0 CN2-1 BLACK 10K <1/10W>...

  • Page 9: Error Display

    ERROR DISPLAY Troubleshooting check table Operation lamp : Red lamp Timer lamp : Green lamp Large division indication Small division indication Error contents LED indication Error contents LED indication thermistor error RED lamp (2 times) thermistor error (room temp.) RED lamp Green lamp Green lamp (2 times)

  • Page 10: Disassembly Illustration

    DISASSEMBLY ILLUSTRATION INDOOR UNIT Ref. Description Part number Front Panel Total Assy 9312099023 Front Panel 9309999039 Intake Grill Assy 9312100026 Grille Clamper 9306755010 Air Filter 9309997011 Louver U Assy 9312368013 Louver Z Assy 9312369010 Wire Clamper 9311946014 Room Thermistor holder 9311948018 Bracket Panel 9310001004...
  • Page 11 INDOOR UNIT Ref. Description Part number Evaporator Sub Assy 9312108060 Joint Pipe Assy 9313750015 Holder (Evaporator) L Assy 9312360024 Holder (Evaporator) R 9309983014 Water Seal 9312912018 2010.10.26 in-2...
  • Page 12 Ref. Description Part number Casing Assy 9312112074 Holder (Louver) Assy 9312361014 Casing Cover F 9309987005 Casing Cover B 9314160011 Drain hose Assy 9310357026 INDOOR UNIT Drain Cap Assy 9314493010 Display PCB Assy 9705039025 Shaft Holder-C Assy 9306628017 Crossflow Fan Assy 9307836015 2010.10.26 in-3...
  • Page 13 INDOOR UNIT Ref. Description Part number Switch Box 9312908011 Fan Motor Assy 9601814016 Motor Clamper 9313724016 Switch Cover 9312909018 Terminal (FSBCW) 9701955022 Terminal (USBCW) 9701955039 Controller PCB Assy (F) 9705611023 Controller PCB Assy (U) 9705611016 Step Motor 9900139025 Gear A 9309994003 Power Cord Assy 9900157036...

  • Page 14: Parts List

    Model : AOY14FSBC 2004.09.15...
  • Page 15 Model : AOY14USBC 2004.09.15...
  • Page 16 OUTDOOR UNIT Ref. Ref. Part No. Part No. Description Description AOY14FSBC AOY14USBC Screw, Taptite (Earth) 0700179013 Screw, Taptite (Earth) 0700179013 Screw 301171134250 Screw 301171134250 Clamp No.1219 313361271706 Clamp No.1219 313361271706 Clamp SKB-100 313361275805 Clamp SKB-100 313361275805 Capacitor Clamp 313468061808 Capacitor Clamp 313468061808 Screw with Washer 313681304205...

  • Page 17: Accessories

    ACCESSORIES Name and Shape Part No. Wall hook bracket 9310001004 Remote control 9313693022 for FSBCW 9371190174 for USBCW Battery (penlight) 0600185534 Cloth tape 9310519004 Tapping screw ( big ) 0700076046 Tapping screw ( small ) 0700019036 Seal A 9304536000 Remote control unit holder 9305642014 Drain Pipe...
  • Page 18 0408G2649...
