OPE R AT IN G M A N U A L
O
M
PE R AT IN G
A N U A L
R OOM A IR CON DIT ION E R
S PLIT T Y PE
Indoor Unit
A S Y 17A S
A S Y 17R S
Outdoor Unit
AOY 17A N
AOY 17R N
K E E P T HIS OPE R AT ION M A N U A L
FOR FU T U R E R E FE R E N CE
FUJITSU GENERAL LIMITED
P/N 9363577044

Advertisement

Table of Contents
loading

Summary of Contents for Fujitsu ASY17AS

  • Page 1 AOY 17A N AOY 17R N K E E P T HIS OPE R AT ION M A N U A L FOR FU T U R E R E FE R E N CE FUJITSU GENERAL LIMITED P/N 9363577044...
  • Page 2: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS .......... 1 SLEEP TIMER OPERATION ......... 12 NAME AND FUNCTION OF PARTS ......2 CARE AND MAINTENANCE ....... 13 PREPARATION ............4 TROUBLE SHOOTING ......... 15 OPERATION .............. 6 OPERATION DETAILS .......... 16 AIR DIRECTION ADJUSTMENT ......9 SPECIFICATIONS ..........
  • Page 3: Name And Function Of Parts

    NAME AND FUNCTION OF PARTS Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle). For details of operation, see the pages indicated by the ( ) mark. Fig. 1 Fig. 2 Fig. 4 Fig. 3 Fig.
  • Page 4 Fig. 1 Indoor Unit Fig. 5 Remote Control Unit 1 Operating Control Panel (Fig. 2) G SLEEP Button ( P. 12) 2 MANUAL AUTO button H MASTER CONTROL Button This button can be used for temporary opera- I SET TEMP./SET TIME Buttons ( tion in the AUTOMATIC mode in the event the J Signal Transmitter remote control unit is unavailable.
  • Page 5: Preparation

    PREPARATION Turn on the Power Connect the power plug to an electrical point. Open the Intake Grille. Set the POWER switch to ON (Fig. 2 3). Close the Intake Grille. Opening/closing the Intake Grille 1 Press both lower sides of the intake grille until you hear a clicking sound. 2 Release your hands and the intake grille will open toward the front.
  • Page 6 Set the Current time Press the TIME ADJUST button (Fig. 6 O). Use the tip of a ball-point pen or other small object to press the button. Use the ( ) SET TIME buttons (Fig. 5 I) to adjust the clock to the current time. button: Press to advance the time.
  • Page 7: Operation

    OPERATION Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle). To Select AUTOMATIC Operation Press the START/STOP button (Fig. 5 M). The air conditioner will start operation. Press the MASTER CONTROL button to select AUTO (Fig.
  • Page 8 To Change the Fan Speed Press the FAN CONTROL button (Fig. 5 L). Each time the button is pressed, the fan speed changes in the following order: AUTO HIGH About three seconds later, the entire display will reappear. When the FAN CONTROL is set to AUTO: COOL : Operation begins and as the room temperature approaches that of the thermostat setting, the fan speed switches to the low setting.
  • Page 9 OPERATION To Set the Thermostat Press the TEMPERATURE set button (Fig. 5 I). button: Press to increase the thermostat setting. button: Press to lower the thermostat setting. GThermostat setting range: Cooling/Drying ....18 to 30 °C COOLING MODEL Fan ........17 to 30 °C HEAT &...
  • Page 10: Air Direction Adjustment

    AIR DIRECTION ADJUSTMENT Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle). G Use the remote control unit’s AIR FLOW DIRECTION button to adjust the up-down direction of airflow. (Left-right air direc- tion is changed by manually moving the air louvers.) G Begin unit operation and confirm that the airflow-direction louvers are stopped before setting the airflow-direction.
  • Page 11 AIR DIRECTION ADJUSTMENT Adjusting the Airflow-Direction Press the AIR FLOW DIRECTION button. G This control allows you to select a desired airflow direction. Types of airflow: Slight downward Horizontal Downward diagonal Downward Double direction diagonal In order to heighten the efficiency of cooling and drying modes, the airflow-direc- tion louvers should be set within the following ranges: For Cooling: Horizontal, slight downward diagonal.
  • Page 12: Timer Operation

    TIMER OPERATION Before using the timer function, be sure that the remote control unit is set to the correct current time ( P. 5). To Use the ON timer or OFF timer To Cancel the Timer Press the START/STOP button (Fig. 5 M) Use the TIMER button to select “TIMER (if the unit is already operating, proceed to step 2).
  • Page 13: Sleep Timer Operation

    SLEEP TIMER OPERATION Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle). Unlike other timer functions, the SLEEP timer is used to set the length of time until air conditioner operation is stopped (for example, 2:00 hours). To Use the SLEEP timer To Cancel the Timer: While the air conditioner is operating or stopped, press the...
  • Page 14: Care And Maintenance

    CARE AND MAINTENANCE G Before cleaning the unit, be sure to stop the unit and disconnect the power supply. CAUTION! G Disconnect the power plug. G Turn off the electrical breaker. G A fan operates at high speed inside the unit, and personal injury could result. When cleaning the air conditioner, disconnect the power plug or turn off the electri- CAUTION! cal breaker.
  • Page 15 CARE AND MAINTENANCE Cleaning the Intake Grille Cleaning the Air Filter If dirt is allowed to collect in the air filter, the airflow will be 1. Removing the Intake Grille reduced, leading to reduced performance, and increased 1 Press in both lower edges of the intake grille until you operating noise.
  • Page 16: Troubleshooting

    TROUBLESHOOTING Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle). In the event of a malfunction (burning smell, etc.), immediately stop operation, turn off the elec- WARNING! trical breaker or disconnect the power supply plug, and consult authorized service personnel. Merely turning off the unit’s power switch will not completely disconnect the unit from the power source.
  • Page 17: Operation Details

    TROUBLESHOOTING Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle). Consult authorized service personnel for any repairs. WARNING! Items to check Symptom See Page CHECK ONCE Doesn’t operate at all: G Is the power plug disconnected from its outlet? MORE G Has there been a power failure? —...
  • Page 18 OPERATION DETAILS Operation and Performance *Heating Performance *Microcomputer-controlled Automatic Defrosting G This air conditioner operates on the heat-pump principle, When using the Heating mode under conditions of low out- absorbing heat from outdoor air and transferring that heat door air temperature high humidity, frost may form on the indoors.
  • Page 19: Specifications

    SPECIFICATIONS MODEL INDOOR UNIT ASY17AS ASY17RS OUTDOOR UNIT AOY17AN AOY17RN TYPE COOLING MODEL HEAT & COOL MODEL (REVERSE CYCLE) POWER 1~ 220-240 V 50 Hz COOLING CAPACITY [kW] 4.75-4.90 4.70-4.80 POWER INPUT [kW] 1.75-1.85 1.70-1.78 CURRENT 8.0-7.8 7.9-7.6 ENERGY EFFICIENCY RATIO [kW/kW] 2.71-2.65...
