Summary of Contents for Showline SL HYDRUS 350
-
Page 2: Special Product Information
The material in this manual is for information purposes only and is subject to change without notice. Showline assumes no responsibility for any errors or omissions which may appear in this manual. For comments and suggestions regarding corrections and/or updates to this manual, please contact your nearest Showline office. -
Page 3: Table Of Contents
LCD Display and Menu System Operation ........................6 Menu Settings ..................................6 DMX CONTROL SL HYDRUS 350 Luminaire DMX Mapping..........................9 Lamp Replacement SL HYDRUS 350 Luminaire Lamp Replacement ........................12 Product Specifications Overview....................................13 Features..................................... 13 Color System..................................13 Gobos / Effects.................................. -
Page 4: Introduction
About Quickstart Guide This Quickstart Guide is intended for a knowledgeable user to unpack, install, and use the SL HYDRUS 350 Luminaire in a short time period. For the complete manual in PDF format, please visit our web site at: www.philips.com/showline... -
Page 5: Connecting Power
Luminaire to AC Power • Connection from the AC output of another SL HYDRUS 350 Luminaire. When using this method, it is very important not to connect any other type of equipment. WARNING: Only connect other SL HYDRUS 350 Luminaires to the AC Output (Thru) connector of a SL HYDRUS 350 Luminaire. -
Page 6: Ac And Dmx Input / Output Connections
Floor Mounting The SL HYDRUS 350 Luminaire is designed to sit directly on its base (Omega Clamps must be removed) in a floor installation application. When used in this type of application, be sure to leave enough space around the luminaire to allow proper, uninterrupted airflow for cooling and movement. -
Page 7: Menu System
LCD Display Menu The SL HYDRUS 350 Luminaire’s LCD Display and Menu System provides local control for accessing the fixture’s settings: Note: If there are multiple luminaires in a system, changes would need to be made at each LCD Menu as desired. - Page 8 SL HYDRUS 350 Luminaire QuickStart Guide Table 4: Menu Settings First Level Second Level Third Level Description Lamp ON/OFF ON or OFF Turns lamp ON or OFF. OFF is default. When unit is first powered on, this setting Automatic On ON or OFF determines if the lamp is automatically struck.
-
Page 9: Dmx Control
Note: This stable assumes a DMX start address of 1. When a different starting address is used, this address becomes channel 1 function and other functions follow in sequence. SL HYDRUS 350 Luminaire DMX Mapping Table 5 provides DMX channel mapping of all DMX512 control values for the SL HYDRUS 350 Luminaire. Table 5: SL HYDRUS 350 Luminaire DMX Channel Mapping Default -... - Page 10 SL HYDRUS 350 Luminaire QuickStart Guide Table 5: SL HYDRUS 350 Luminaire DMX Channel Mapping Open = 0 - 21 Gobo 1 = 22 - 28 Gobo 2 = 29 -35 Gobo 3 = 36 -42 Gobo 4 = 43 - 49...
- Page 11 SL HYDRUS 350 Luminaire QuickStart Guide Table 5: SL HYDRUS 350 Luminaire DMX Channel Mapping Open (out of beam) = 0 - 23 Line Prism Index = 24 - 49 8 Facet Prism Index = 50 - 75 Line Prism Rotate = 76 - 101...
-
Page 12: Lamp Replacement
QuickStart Guide Lamp Replacement SL HYDRUS 350 Luminaire Lamp Replacement WARNING: Before performing the procedure described herein, you must disconnect the luminaire for its power source. Dousing the lamp does not disconnect power. Failure to remove the power completely before replacing the lamp may result in serious injury or death! This procedure should only be done by a trained and qualified technician. -
Page 13: Product Specifications Overview
Overview The SL HYDRUS 350 is a hybrid BEAM/SPOT/WASH moving luminaire designed for special event, television, and concert lighting applications. Powered by the PHILIPS Platinum 17RA Lamp, the luminaire delivers powerful output, great color control and a comprehensive beam effects system in a compact sized luminaire. -
Page 14: Luminaire Dimensions
SL HYDRUS 350 Luminaire QuickStart Guide Luminaire Dimensions 420.3 mm / 16.6 in 260.3 mm / 10.3 in 108.9 mm / 4.3 in 400.7 mm / 15.8 in 431.6 mm / 17.00 in 653.9 mm / 25.8 in Sh wline... - Page 15 Sh wline...
