Showline SL BAR 510 Installation And User Manual

Rgbw led luminaire
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SL BAR 510/510N
RGBW LED Luminaire

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL BAR 510 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Showline SL BAR 510

Summary of Contents for Showline SL BAR 510

  • Page 1 SL BAR 510/510N RGBW LED Luminaire...

  • Page 2: Showline Offices

    Note: Information contained in this document may not be duplicated in full or in part by any person without prior written approval of Showline. Its sole purpose is to provide the user with conceptual information on the equipment mentioned. The use of this document for all other purposes is specifically prohibited.
  • Page 3 Showline Limited Two-Year Warranty Showline offers a two-year limited warranty of its luminaires against defects in materials or workmanship from the date of delivery. A copy of Showline two-year limited warranty containing specific terms and conditions can be obtained by contacting your local Showline office.

  • Page 5: About This Manual

    Please read all instructions before installing or using this product. Retain this manual for future reference. Additional product information and descriptions may be found on the product specification sheet. Note: The SL BAR 510/510N RGBW LED Luminaire is universal voltage 100 to 240 VAC (auto-ranging). Included Items...

  • Page 6: Common Luminaire Components

    AC Output DMX512 / RDM Input DMX512 / RDM Output High Power LEDs Luminaire Mount (x2) Figure 1: SL BAR 510/510N RGBW LED Luminaire Common Components LCD Display / Menu System Edit a Preset Edit a Chase Home (menu settings)

  • Page 7: Installation And Setup

    Connection from the AC output of another SL BAR 510/510N RGBW LED Luminaire. When using this method, it is very important not to connect any other type of equipment device. W ARN ING! Only connect other SL BAR 510/510N RGBW LED Luminaires to the AC Output (Thru) connector of a SL BA R 510/510N RGBW LED Luminaire.
  • Page 8 If the unit is supplied with an AC input cable but you did not order an AC input connector, Table 2 describes how to connect power to your SL BAR 510/510N RGBW LED Luminaire. Field wiring of the SL BAR 510/510N RGBW LED Luminaire is straight forward.

  • Page 9: Connecting To The Dmx512 Network

    DMX connector on the first SL BAR 510/510N RGBW LED Luminaire. Another cable runs from the other DMX connector on the first unit to a DMX connector on the next SL BAR 510/510N RGBW LED Luminaire (or DMX512 device to be controlled).

  • Page 10: Mounting Luminaire

    Truss / Hanging Applications The SL BAR 510/510N RGBW LED Luminaire is provided with the ability to hang via truss hooks, clamps, etc. (sold separately). Simply attach hook, clamp, etc. to the SL BAR 510/510N RGBW LED Luminaire enclosure assembly in the provided M10 holes.

  • Page 11: Operation And Programming

    OPERATION AND PROGRAMMING LCD Display and Menu System SL BAR 510/510N RGBW LED Luminaires The SL BAR 510/510N RGBW LED Luminaire’s LCD Display and Menu System provides local control for accessing the following fixture’s settings: Presets (Standard and User Defined)

  • Page 12: Lcd Display And Menu System Operation

    Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires 2. LCD Display and Menu System Operation The LCD Display Menu system consists of several categories. Use the Menu Buttons to access and make changes to the menu items. When the desired menu item is reached, press the desired Menu Button to display the menu options and to navigate and configure the menu options as required.
  • Page 13 1-- 4 Current Color 1--4 Select Color Color Filter :0-43 0-100% Green 0-100% Blue 0-100% White 0-100% Continued on next page Figure 9: SL BAR 510/510N RGBW LED LUMINAIRE Menu Tree(Part 1) SL BAR 510/510N RGBW LED Luminaire Menu Tree...
  • Page 14 86 Celsius degree Min_Value xx Celsius degree Max_Value xx Celsius degree Max Intensity 0-100% Other Information RDM UID 0X000000000000 Firmware Version Rev 0.0 Figure 10: SL BAR 510/510N RGBW LED LUMINAIRE Menu Tree(Part 2) SL BAR 510/510N RGBW LED Luminaire Menu Tree...

  • Page 15: Quick Selection Buttons

    SL BAR 510/510N RGBW LED Luminaires Installation & User’s Manual 4. Quick Selection Buttons When in Manual Mode, the SL BAR 510/510N RGBW’s features can be accessed via the on-board LCD menu system or via three quick select buttons: Edit a Preset Button...
  • Page 16 Linear Curve PL_Curve* DMX Value DMX Value *PL Curve follows the dimming curve of Philips Selecon PL series LED luminaires. S_Curve Square Curve DMX Value DMX Value Figure 11: SL BAR 510/510N RGBW LED Luminaire Dimmer Curves Dimming Curve Selection...

  • Page 17: Master / Slave Operational Mode

    6. Master / Slave Operational Mode The Master / Slave Operational Mode allows one SL BAR 510/510N RGBW LED Luminaire to act as the "Master" unit and all other connected units are controlled by this unit. When a unit is set to "Slave" mode, it will only listen to and follow any commands sent from a "Master"...

  • Page 18: Dmx Control

    SL BAR 510/510N RGBW LED Luminaire DMX Mapping Simple 8-Bit Mode Table 3 provides DMX channel mapping of all DMX512 control values when the SL BAR 510/510N RGBW LED Luminaire is in simple 8-bit DMX512 mode (as set by the luminaire’s menu system).
  • Page 19 Installation & User’s Manual 2. Simple 8Bit Group Mode Table 4 provides DMX channel mapping of all DMX512 control values when the SL BAR 510/510N RGBW LED Luminiare is operated in various Simple 8-bit DMX512 Group Control Modes. Table 4: SL BAR 510/510N RGBW LED Luminaire DMX Channel Mapping (Simple 8Bit Group Mode)
  • Page 20 SL BAR 510/510N RGBW LED Luminaires 3. RGBW 8 - Bit Mode Table 5 provides DMX channel mapping of all DMX512 control values when the SL BAR 510/510N RGBW LED Luminaire is in RGBW 8-bit DMX512 mode (as set by the luminaire’s menu system).
  • Page 21 SL BAR 510/510N RGBW LED Luminaires Installation & User’s Manual Table 5: SL BAR 510/510N RGBW LED Luminaire DMX Channel Mapping (RGBW 8-Bit Mode) Parameter Range DMX Range% Description Default Channel Color Presets 0 - 255 0 - 100% CF_11_Moroccan Pink...
  • Page 22 Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires Table 5: SL BAR 510/510N RGBW LED Luminaire DMX Channel Mapping (RGBW 8-Bit Mode) Default - recom- Parameter Range DMX Range% mended console Description Channel default values Color Presets 0 - 255...
  • Page 23 Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires Table 5: SL BAR 510/510N RGBW LED Luminaire DMX Channel Mapping (RGBW 8-Bit Mode) Default - recom- Parameter Range DMX Range% mended console Description Channel default values Timing 0 - 255...

  • Page 24: Rgbw 8Bit Group Mode

    SL BAR 510/510N RGBW LED Luminaires RGBW 8Bit Group Mode Table 6 provides DMX channel mapping of all DMX512 control values when the SL BAR 510/510N RGBW LED Luminiare is operated in various RGBW8-bit Group Control Modes. Table 6: SL BAR 510/510N RGBW LED Luminaire DMX Channel Mapping (RGBW 8 Bit Group Mode)
  • Page 25 SL BAR 510/510N RGBW LED Luminaires 5. RGBW 16 - Bit Mode Table 7 provides DMX channel mapping of all DMX512 control values when the SL BAR 510/510N RGBW LED Luminaire is in RGBW 16-bit DMX512 mode (as set by the luminaire’s menu system).
  • Page 26 Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires Table 7: SL BAR 510/510N RGBW LED Luminaire DMX Channel Mapping (RGBW 16-Bit Mode) Default - recom- Parameter Range DMX Range% mended console Description Channel default values CF_11_Moroccan Pink DMX 91 - 92...
  • Page 27 Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires Table 7: SL BAR 510/510N RGBW LED Luminaire DMX Channel Mapping (RGBW 16-Bit Mode) Default - recom- Parameter Range DMX Range% mended console Description Channel default values Color Presets 0 - 255...
  • Page 28 Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires Table 7: SL BAR 510/510N RGBW LED Luminaire DMX Channel Mapping (RGBW 16-Bit Mode) Default - recom- Parameter Range DMX Range% mended console Description Channel default values Allows for timing control of intensity, color, and zoom parameters.

  • Page 29: Rgbw 16Bit Group Mode

    Installation & User’s Manual 6. RGBW 16Bit Group Mode Table 8 provides DMX channel mapping of all DMX512 control values when the SL BAR 510/510N RGBW LED Luminiare is operated in various RGBW 16bit DMX512 Group Control Modes. Table 8: SL BAR 510/510N RGBW LED Luminaire DMX Channel Mapping (RGBW 16Bit Group Mode)
  • Page 30 Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires DMX CONTROL...
  • Page 31 SL BAR 510/510N RGBW LED Luminaires Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaire DMX Mapping...
  • Page 32 Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires DMX CONTROL...
  • Page 33 I nstal l ati on & User ’ s M anual SL B AR 510/510N RGBW L ED Lumi nai r es SL B AR 510/510N RGBW L ED Luminair e DMX M appi ng...
  • Page 34 Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires DMX CONTROL...
  • Page 35 SL BAR 510/510N RGBW LED Luminaires Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaire DMX Mapping...
  • Page 36 SL BAR 510/510N RGBW LED Luminaires 15. HSIC Mode Table 17 provides DMX channel mapping of all DMX512 control values when the SL BAR 510/510N RGBW LED Luminaire is in HSIC Mode (as set by the luminaire’s menu system). Table 17: SL BAR 510/510N RGBW LED Luminaire DMX Channel Mapping (HSIC Mode)
  • Page 37 Installation & User’s Manual 16. HISC GROUP Mode Table 18 provides DMX channel mapping of all DMX512 control values when the SL BAR 510/510N RGBW LED Luminiare is operated in various HSIC DMX512 Group Control Modes. Table 18: SL BAR 510/510N RGBW LED Luminaire DMX Channel Mapping (HSIC GROUP Mode)

  • Page 38: Dmx Timing Channel Detail

    2. DMX Timing Channel Detail Timing channel control improves the timed moves of certain groups of parameters. The SL BAR 510/510N RGBW LED Luminaire provides timing channels in 16-bit mode (one for intensity time and one for color time) and one timing channel in 8-bit (color and intensity timing combined).
  • Page 39 SL BAR 510/510N RGBW LED Luminaires Installation & User’s Manual Table 19: SL BAR 510/510N RGBW LED Luminaire Timing Channel Detail = Seconds % Value (unless noted) 10.2 10.4 10.6 10.8 11.2 11.4 11.6 11.8 DMX TIMING CHANNEL DETAIL...
  • Page 40 Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires Table 19: SL BAR 510/510N RGBW LED Luminaire Timing Channel Detail = Seconds % Value (unless noted) 12.2 12.4 12.6 12.8 13.2 13.4 13.6 13.8 14.2 14.4 14.6 14.8 15.2 15.4...
  • Page 41 SL BAR 510/510N RGBW LED Luminaires Installation & User’s Manual Table 19: SL BAR 510/510N RGBW LED Luminaire Timing Channel Detail = Seconds % Value (unless noted) DMX Timing Channel Detail...
  • Page 42 Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires Table 19: SL BAR 510/510N RGBW LED Luminaire Timing Channel Detail = Seconds % Value (unless noted) DMX Timing Channel Detail...
  • Page 43 SL BAR 510/510N RGBW LED Luminaires Installation & User’s Manual Table 19: SL BAR 510/510N RGBW Luminaire Timing Channel Detail = Seconds % Value (unless noted) 5 Minutes 15 Minutes 30 Minutes 60 Minutes 60mS 250* 80mS 251* 100mS 252*...
  • Page 44 SL BAR 510/510N RGBW LED Luminaires 1. SL BAR 510/510N RGBW LED Luminaire RDM Parameter IDs The following tables outline and describe all the RDM parameters Ids associated with SL BAR 510/510N RGBW LED Luminaires. Table 20, “SL BAR 510/510N RGBW LED Luminaire RDM Product Parameters IDs”...
  • Page 45 SL BAR 510/510N RGBW LED Luminaires Installation & User’s Manual Table 22: SL BAR 510/510N RGBW LED Luminaire RDM Parameters IDs RDM Parameter IDs Value Comment Implemented Allowed Allowed Category - Product Information DEVICE_INFO 0x0060 PRODUCT_DETAIL_ID_LIST 0x0070 DEVICE_MODEL_DESCRIPTION 0x0080 MANUFACTURER_LABEL...
  • Page 46 PRESET_PLAYBACK 0x1031 Table 23: SL BAR 510/510N RGBW LED Luminaire RDM Parameter Status IDs Manufacturer Specific messages are in the range of 0x8000 - 0xFFDF. Each Manufacturer-specific Status ID shall have a unique meaning, which shall be consistent across all products having a given Manufacturer ID. See Table B-2, ANSI E1.20-2010...

  • Page 47: Front Lens Cleaning

    SL BAR 510/510N RGBW LED Luminaire. These types of cleaners or solvents can permanently damage the optics or housings of the fixture. If you have any questions regarding the use or care of your SL BAR 510/510N RGBW LED Luminaire, please contact Showline technical support or your local Authorized Dealer.

  • Page 48: Technical Specifications

    Installation & User’s Manual SL BAR 510/510N RGBW LED Luminaires TECHNICAL SPECIFICATIONS 1. Operational Specifications Source: 4 Osram Olson RGBW LED Array Beam Angle: 24 Degrees Light Output: > 2000 lumens Color Temerature: 2700 - 6500K (user adjustable) Input Voltage:...

  • Page 49: Luminaire Dimensions

    SL BAR 510/510N RGBW LED Luminaires Installation & User’s Manual 2. Luminaire Dimensions Technical Specifications...
  • Page 50 Dallas 10911 Petal Street Dalls, TX 75238 Tel: +1 214-647-7880 Fax: +1214-647-8031 Asia Unit C, 14/F, Roxy Industrial Centre No. 41-49 Kwai Cheong Road Kwai Chung, N.T., Hong Kong Tel: +852 2796 9786 Fax: +852 2798 6545 Auckland 19-21 Kawana Street Northcote, Auckland 0627 New Zealand Tel: +64 9 481 0100...
