Zte AC3635 User Manual

Zte AC3635 User Manual

Wireless data terminal
Hide thumbs
Table of Contents

Advertisement

Quick Links

Wireless Data Terminal

User Manual

The manual is applicable for the AC3635.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC3635 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zte AC3635

Summary of Contents for Zte AC3635

  • Page 1: User Manual

    Wireless Data Terminal User Manual The manual is applicable for the AC3635.
  • Page 2 ZTE Corporation. ZTE Corporation reserves the right to make modifications on print errors or update specifications in this manual without prior notice.

  • Page 3: Table Of Contents

    Contents Let’s get started ......................1 Lost or stolen? ......................1 Using your router safely ................... 2 Inserting and removing the SIM ................5 Restore factory settings ................... 5 LED..........................6 Functions of Data card ....................7 Install ........................7 Onscreen icons ......................
  • Page 4 Advanced ....................... 13 Firewall ......................15 SMS ....................... 17 Status ......................19 Appendix ........................20 Care and maintenance ..................20 FCC Regulations: ....................22 RF Exposure Information (SAR) ................23 Declaration of RoHS compliance ................26 Disposal of your old router..................27 Problems and their solutions..................

  • Page 5: Let's Get Started

    Let’s get started Thank you for choosing the ZTE-AC3635 CDMA Mini Router hereinafter referred to as Router. The router works in CDMA/1X/EVDO network. The client devices could connect to it via USB or Wi-Fi interface. The router supports data and SMS services, enabling you to communicate anytime and anywhere.

  • Page 6: Using Your Router Safely

    Using your router safely on the road  Using a router while driving is illegal in many countries. Please follow local laws and drive safely at all times. near sensitive electronics Don’t use your router near sensitive electronic equipment – particularly ...
  • Page 7 to switch off your router, or disable its wireless functions, please do as they say. in hospital  Your router may interfere with the normal operation of medical equipment. Follow all hospital regulations and turn it off when you’re asked to by posted warnings or medical staff. at a petrol station Don’t use your router at petrol stations.
  • Page 8 Keep your mobile out of children’s reach. It should never be used as a  toy and it might not be good for their health. original accessories  Only use the original accessories supplied with your router or those approved by the manufacturer. Using unapproved accessories may affect performance, make the warranty void, break national regulations on the use of routers, or even cause injury.

  • Page 9: Inserting And Removing The Sim

    Inserting and removing the SIM Put out the tap. Take out USB interface and SIM card cover in the direction indicated by the arrow. Insert SIM card as below. Push back SIM card cover. factory settings Restore As the router is working, long press Reset key to restore factory settings.

  • Page 10: Led

    Functions Descriptions Power on, WiFi idle status WiFi blue LED slow blink WiFi connected WiFi blue LED lights up always WiFi disconnected or abnormal WiFi blue LED turns off Didn’t logging on the internet 3G red LED slow blink EVDO Logging on the internet 3G green LED standard blink 1X Logging on the internet 3G red LED standard blink...

  • Page 11: Functions Of Data Card

    Functions of Data card When connected with the PC, the router can be used as a data card. It supports Windows XP/Vista/7/8, MAC and Linux operating system. In the area where there is signal, it allows you to go surfing on the Internet. Note: As the router is used as a data card, the Wi-Fi function is Off automatically.

  • Page 12: Onscreen Icons

    Note: If your CD-ROM autorun function is prohibited by the firewall, the auto installation interface will not appear. In this case, go to “My computer” to find the virtual CD-ROM and run the relevant installation application in the virtual CD-ROM. After the application is installed successfully, the application icon will appear on your desktop.

  • Page 13: Functions Of Router

    the system will automatically uninstall the driver. Please wait for a while till uninstallation is completed. Functions of router Note: 1. Prior to use, please check if your computer has Wi-Fi function or not. 2. The parameter settings may have been preset by your service provider, and you will enjoy your Internet service directly.

  • Page 14: Settings

    enter http://192.168.0.1 in a web browser address bar. The login page appears. Input the case-sensitive default username admin and password admin, and then click Login to access the WebGUI Configuration page. Settings After logging in, select Settings, and you can do the following operations. Quick settings The Quick Setup wizard guides you how to set the basic parameters for your device in the safest way.

  • Page 15: Network Settings

    Network Preference: Network Preference has three options: Hybrid, 1X Only and EVDO Only. Hybrid: AC3635 will attempt to connect to EVDO network. If it is not available, it will automatically connect to 1X network. 1X Only: AC3635 will attempt to connect to 1X network only.

  • Page 16: Wi-Fi Settings

    Wi-Fi settings Station list Select Settings>Wi-Fi Settings> Station List to show the Wi-Fi client status. Basic Select Settings>Wi-Fi Settings to config the basic settings of the wireless work. Network Name (SSID): Service Set Identifier (SSID). Enter a string less than 32 characters as the name for your wireless local area network (WLAN).

  • Page 17: Advanced

    connect the AP simultaneously. Click Apply button to confirm your configuration. Security Select Settings>Wi-Fi Settings>Security to set the wireless network security of your device. Enter the Pass Phrase manually. Click Apply to confirm. Advanced View the current status of your device, change the Administrator Settings, restore factory defaults or set the LAN interface configuration.
  • Page 18 DHCP Server: It shows the DHCP server is enabled or not. DHCP IP Pool: You can manually assign IP address field. DHCP Lease Time: Limit on a client's use of an IP address to connect AC3635. Management Select Settings>Advanced> Management to change the login password of the WEB GUI Configuration page.

  • Page 19: Firewall

    AC3635. Block: do not allow the packet that doesn't match with IP/Mac address filtering rules to pass through AC3635. MAC Address: Host's MAC address (when setting as White list, it allows the host with this MAC address only to get access to the network; when...
  • Page 20 access to the network) Source IP Address: Source IP Address (when setting as Whitelist, it's allowed to get access to the website at this IP address only; when setting as Blacklist, it's not allowed to get access to the website at this IP address) Protocol: Trigger protocol.

  • Page 21: Sms

    The setting method is as follows: 1. Select the default filtering rule: do not allow the packet that doesn't match with the IP address filtering rules to pass through AC3635. 2. Add new： Allow the IP address 192.168.0.100 to have unrestricted access to all IP addresses in the external network.
  • Page 22 Device Click the Reply button to reply to the sender. Click the Delete button to delete your selected records. Click the Delete All button to delete all the records in the inbox.

  • Page 23: Status

    Status After logging in, select Status, and you can do the following operations. Functions Descriptions View the Network information and Basic status system information Network View the WAN information, LAN and status WLAN information...

  • Page 24: Appendix

    Appendix Care and maintenance Your router is a delicate device. The following advice will help you to keep it looking good and performing well… Use a soft dry cloth to clean your router. Don’t use liquids such as  alcohol, dilution agents or benzene. ...
  • Page 25 them to your nearest service centre for inspection.

  • Page 26: Fcc Regulations

    FCC Regulations: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 27: Rf Exposure Information (Sar)

    -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment.
  • Page 28 known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value.
  • Page 29 SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this device is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: SRQ-AC3635.

  • Page 30: Declaration Of Rohs Compliance

    EU 2002/95/EC, or are exempt due to their application. The AR910 manufactured by ZTE CORPORATION, meets all the requirements of EU 2002/95/EC.

  • Page 31: Disposal Of Your Old Router

    Disposal of your old router 1. When the wheelie bin symbol is attached to a product, it means the product is covered by the European Directive 2002/96/CE. 2. All electrical and electronic products should be disposed of separately from normal household waste via designated collection points provided by government or local authorities.

  • Page 32: Problems And Their Solutions

    Problems and their solutions Symptoms Possible Causes Solutions Poor network Unable to Move to other places signal connect the network Out of the service Make sure your router is in area CDMA network service area. Open http://192.168.0.1 to enter the router's homepage and check if Wi-Fi is on.
