Summary of Contents for SunTech ST4940B
- Page 1 Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 1 of 51 Features and how to configure ST4940B Asset Tracker ST4940B User Manual...
-
Page 2: Table Of Contents
2-3. Operational Features ............................10 3. Accessories ................................11 4. How to insert Micro SIM card by step ........................12 5. How to turn on and off ST4940B ..........................13 6. Charging Battery ............................... 14 7. Appearance ................................15 8. How to operate ................................16 9. - Page 3 1.03 2-7-2019 3 of 51 Features and how to configure ST4940B 11-8. Command on how to get Google Map Address ..................35 11-9. Command on how to Improve Battery Life ....................35 11-10. Command on how to turn off the device....................36 11-11.
- Page 4 Suntech International Ltd., which is hereinafter referred to as “Suntech”. The information in this manual is believed to be accurate and reliable at the time of releasing. We, at Suntech, also assume no responsibility for any damage or loss resulting from the use of this manual, and expressly disclaim any liability or...
-
Page 5: Revision History
Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 5 of 51 Features and how to configure ST4940B Revision History Rev. No. Date Contents of Revision FirmwareNumber Author reflecting the latest revision 1.00 28 May. 2019 Initial writing 1.0.18... -
Page 6: Introduction
Without any efforts for connecting wires, the ST4940B (hereinafter referred to as ‘device’) works autonomously with its built-in battery. If users want to track an object with the ST4940B, all they have to do is just simply put it onto container or location where the object is contained. -
Page 7: Key Features
Power On/Off by magnet can be disabled SMS/GPRS/LTE M1 communications Alert report when the battery is in a low status Periodic reporting in real time Built-in motion detector for alarming ST4940B with its Magnet holder Waterproof in compliance with IP67... -
Page 8: Hw Specifications
Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 8 of 51 Features and how to configure ST4940B 2-1. HW Specifications Item Description Battery Rechargeable 3.7V, Li-ion Battery- 18200mAh Motion Detection Built-in 3-axis Acceleration sensor Frequency... -
Page 9: Gps Specifications
ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 9 of 51 Features and how to configure ST4940B 2-2. GPS Specifications Item Description Receiver Type GPS & Glonass GPS L1 band(1575.42MHz), Glonass L1 band (1601.71MHz) Galileo* E1B/L1, Compass* ready... -
Page 10: Operational Features
ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 10 of 51 Features and how to configure ST4940B 2-3. Operational Features Item Description either by SMS or PC Configuration either by SMS or GPRS/LTA M1 Parameter Change... -
Page 11: Accessories
Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 11 of 51 Features and how to configure ST4940B 3. Accessories The ST4940B provides below accessories Wall Charger External Power cable Cigar Jack Cable ... -
Page 12: How To Insert Micro Sim Card By Step
4. How to insert Micro SIM card by step There are 3 steps in inserting a Micro SIM card into the ST4940B as shown below in the pictures. Step 1.:Unscrew Case and open. be careful of battery cable not being disconnected... -
Page 13: How To Turn On And Off St4940B
5. How to turn on and off ST4940B ST4940B can be turned on and off via magnet. If magnet is attached on below point over 3 seconds, ST4940B will turn on automatically With same way, you can turn off ST4940B... -
Page 14: Charging Battery
<Caution!!> The ST4940B (device) should be charged by using the 12V output wall charger that Suntech provides the user with. In such a case, however, Suntech does not guarantee that charging the device can be done completely. It is highly... -
Page 15: Appearance
Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 15 of 51 Features and how to configure ST4940B 7. Appearance... -
Page 16: How To Operate
Features and how to configure ST4940B 8. How to operate The ST4940B, multifunctional battery-powered GPS tracker, is ideal for tracking valuable assets like merchandises that are delivered by putting it onto an object. While tracking, it reports location information about the object at a predefined interval and alerts if it detects motion of the object. - Page 17 Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 17 of 51 Features and how to configure ST4940B Blue& GSM/LTE M1 network & Operating Status indicator LEDs (2 colors) Right after the device is turned on, the blue LED starts to blink as below. Five (5) minutes after the blue LED starts to blink, it is turned off automatically to save battery.
-
Page 18: Configuration
Option 3: by messaging via SMS. In practice, configuration can be made more efficiently with ‘SyncTrak’, i.e. a setting tool provided by Suntech. Once a device receives a command from the server, it gets back to the server with a relevant response. Device also changes some parameters (if it is required to do so) or takes an action as instructed below as per the command sent by the server. - Page 19 Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 19 of 51 Features and how to configure ST4940B SEVER_IP String Server IP Address SEVER_PORT String Server Port B_SERVER_IP String Backup Server IP Address B_SERVER_PORT String...
-
Page 20: How To Set 'Report Parameters
1.03 2-7-2019 20 of 51 Features and how to configure ST4940B so that the device can receive a command from the server. Sometimes, the device may send ‘Alive Report’ to keep the connection because the network provider may disconnect the GPRS/ LTE-M1 connection if there is no communication for such a time-period. Also, the device may send‘Alive Reports’... - Page 21 Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 21 of 51 Features and how to configure ST4940B Field Marks Value Meaning “ST600RPT” Command type. DEV_ID 10 char Device ID. “02” Protocol Version MOVING_STOP_IN String Second Sending interval of location report while Moving stop.
-
Page 22: How To Set 'Additional Parameters
Page of Pages 1.03 2-7-2019 22 of 51 Features and how to configure ST4940B 9-3. How to set ‘Additional Parameters’ ● The following table shows how to setprotocol types for GPRS/LTE M1 such as TCP and UDP with device port No.: DEV_ID... - Page 23 Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 23 of 51 Features and how to configure ST4940B ‘0’ Reserved ‘0’ Reserved ‘0’ Reserved ‘0’ Reserved ‘0’ Reserved ‘0’ Reserved <Example> [command] ST600ADP;0123456789;02;T;T;0;;0;0;0;0;0;0 [response] ST600ADP;Res;0123456789;309;T;T;0;;0;0;0;0;0;0 <ACK in case of UDP>...
-
Page 24: How To Set 'Service Parameters
Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 24 of 51 Features and how to configure ST4940B 9-4. How to set ‘Service Parameters’ VI_ON_PERCENT DEV_ID VI_ON_THRES VI_ON_DELAY VI_OFF_TH VI_OFF_DEL VI_OFF_PER DEEP SLEEP SPEED_LIMIT CENT ●... -
Page 25: How To Set 'Geo-Fence Parameters
1. Driving or Parking is decided by Motion Sensor. If VI_ON_THRES is equal to zero, it cannot recognize ‘driving’. Please do not forget that the ST4940B may show you a bigger distance than the real one while the vehicle is parked, if you make an optional configuration to enable the device not to check motion. -
Page 26: How To Set 'Function Parameters
Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 26 of 51 Features and how to configure ST4940B DEV_ID GEO_ID ACTIVE RADIUS Field Marks Value Meaning “ST600CGF” Command type. DEV_ID 10 char Device ID. “02”... -
Page 27: How To Set 'Off Parameters
Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 27 of 51 Features and how to configure ST4940B 1 :If you set the device to ‘1’, you can turn off the device by using the ‘Magnet’ and command. MOTION_DET_ 0 / 1 Only works when Enabled. -
Page 28: Command For General Use
2-7-2019 28 of 51 Features and how to configure ST4940B When the device receives this command, it turns the power off and on after OFF_TIME minutes pass. During the time period of ‘power off’, the device cannot send either any reports or alert. It cannot receive any commands either. -
Page 29: Pre-Setting
Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 29 of 51 Features and how to configure ST4940B ● The following table shows how to make command in order to get the current position of the device. Field Marks Value Meaning “StatusReq”... -
Page 30: Ack Of Emergency
Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 30 of 51 Features and how to configure ST4940B “PresetA” CMD_ID Report all the parameters including additional parameter. <Example> [command] ST600CMD;100850000;02;PresetA [response] ST600CMD;Res;0123456789;309;PresetA;NTW;1;mft;mft;mft;183.109.78.85;8024;;;;;1;RPT;180;180;60;3;0.10; FUNC;1;0;SVC;1;5;10;70;5;10;70;0;0;500;300;200;ADP;T;T;0;;0;15;360;30;0;0 10-4. ACK of Emergency Once this command is made by the server, the device will stop reporting about the occurrence of emergency. -
Page 31: Requesting To Send Information About Device Version
1.03 2-7-2019 31 of 51 Features and how to configure ST4940B [response] ST600CMD;Res;0123456789;309;ReqICCID;8982111412600301307 10-6. Requesting to send information about Device Version Once this command is made, some interactions will be made between the server and the device as described in the ‘Meaning’... -
Page 32: Command For Various Usages
Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 32 of 51 Features and how to configure ST4940B 11. COMMAND FOR VARIOUS USAGES Description on each factor necessary to make types of these commands is shown in this Chapter. DEV_ID CMD_ID Field... -
Page 33: Command On How To Initialize Message Number
Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 33 of 51 Features and how to configure ST4940B <Example> [command] ST600CMD;0123456789;02;SetDist=100 [response] ST600CMD;Res;0123456789;309;SetDist 11-3. Command on how to initialize Message Number This command is used if you want to initialize sequence number of the message. -
Page 34: Command On How To Reboot
Page of Pages 1.03 2-7-2019 34 of 51 Features and how to configure ST4940B Response consists of continuous field (0 or 1) and information about all the geo-fences including the first geo-fence up to the last one whose last digit is 1 (One). -
Page 35: Command On How To Get Google Map Address
Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 35 of 51 Features and how to configure ST4940B “SetGoogleMap” CMD_ID Set location link address format (Google map address). This command is either followed by “=” or inserted inside the address. <Example>... -
Page 36: Command On How To Turn Off The Device
[response] ST600CMD;Res;0123456789;309;GpsOffMov In a case that user utilizes this option (“1” to be selected in the SyncTrak, a setting tool of Suntech) which is (Note): operational only while the device (in a vehicle, for example) is moving, power of the battery can be consumed less than in a case that this option is not selected. -
Page 37: Command On How To Set The Time Period That Gps Is Stabilized
2-7-2019 37 of 51 Features and how to configure ST4940B 11-11. Command on how to set the time period that GPS is stabilized. This command is made if the device user does not want to utilize functions of motion sensing of the device, which means that the case that the value of <VI_ON_THRES>... -
Page 38: Command On How To Get The Status Of Device
Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 38 of 51 Features and how to configure ST4940B the area where you utilize the device. Field Marks Value Meaning “ReqGpsOnPercent” COMMAND This command is used to request the device to report about what information ‘SetGpsONPercent”... -
Page 39: Command On How To Access To Maintenance Server To Check For Update
Page of Pages 1.03 2-7-2019 39 of 51 Features and how to configure ST4940B This command is used to initialize all the parameters with the values set in the factory of the devices and to reboot the device. <Example> [command] ST600CMD;0123456789;02;Reset [response] ST600CMD;Res;0123456789;308;Reset... -
Page 40: Reporting To Server
1.03 2-7-2019 40 of 51 Features and how to configure ST4940B 12. Reporting to server This Chapter explains how device makes a report and sends it to the server. This report (‘Status Report’) is sent to the server periodically as defined by user to configure ‘status report’ if conditions for issuing the report are met. - Page 41 Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 41 of 51 Features and how to configure ST4940B PWR_VOLT RESERVED MODE MSG_NUM RESERVED RESERVED MSG_TYPE Field Marks Meaning “ST600STT” Header of Status Report. DEV_ID 10 char Device ID.
-
Page 42: Emergency Report
ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 42 of 51 Features and how to configure ST4940B 97: greater than -44 dBm String Latitude (+/-xx.xxxxxx). String Longitude (+/-xxx.xxxxxx). String Speed in km/h. This value returns to 0 when it is higher than 200,000km (kilometers). - Page 43 Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 43 of 51 Features and how to configure ST4940B ST4940B DEV_ID MODEL SW_VER DATE TIME CELL_ID RX_LVL SATT DIST PWR_VOLT RESERVED EMG_ID RESERVED RESERVED MSG_TYPE Field...
- Page 44 Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 44 of 51 Features and how to configure ST4940B String Location Area Code. 4 digits hex RX_LVL String Signal Strength. 0 ~ 63 in GSM. (RSSI) 0: less than -110 dBm 1: -110 to -019 dBm …...
-
Page 45: Alert Report
1.03 2-7-2019 45 of 51 Features and how to configure ST4940B 12-3. Alert Report Device sends ‘Alert’ to the server as defined by user in the course of setting the relevant parameters. Most of cases that requiring an alert to be issued means that the vehicle or asset or its driver is in danger or is almost in danger that should be notified by device to the server and/or the cellular phone (If communication via SMS has been configured) for warning. - Page 46 Doc. Title ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 46 of 51 Features and how to configure ST4940B SW_VER 3 char Software Version. DATE 8 char GPS date (yyyymmdd). TIME 8 char GPS time (hh:mm:ss).
-
Page 47: Keep-Alive Report
ST4940B User Manual Concerning: Rev. Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 47 of 51 Features and how to configure ST4940B 33: Motion On 34: Motion Off 52 = Low Battery. 70 = Shutdown by Magnet or CMD RESERVED EMPTY RESERVED... -
Page 48: Parameter Report
Date (dd-mm-yy) Page of Pages 1.03 2-7-2019 48 of 51 Features and how to configure ST4940B <Example> ST600ALV;0123456789 12-5. Parameter Report “Parameter Report” is sent when UDP connection is established for informing of device IP assigned by PDP, and whenever device IP is changed by PDP, “Parameter Report” is sent, too. -
Page 49: Appendices
How to install USB Driver on PC under environment of WINDOW 13-1. If you start using WINDOW on your PC and connect the PC, for the first time by using a USB cable, with the ST4940B which is off, you SHOULD take the procedure by step as described below. -
Page 50: What To Do If Pc Displays "Alcatel Single Rndis Interface
Step 1. Probable problem in connecting a PC with the ST4940B by using a USB Cable There is one thing that you, as a user of the ST4940B, should be very careful in a case that you have never installed a ‘USB driver’... - Page 51 2-7-2019 51 of 51 Features and how to configure ST4940B In such a case, the first thing that you have to do is remove the “Alcatel Single RNDIS Interface” from the “Network Adapters” of the PC.And then, remove the USB Cable from the PC ...
