Tinkerine Studio DITTO PRO Quick Start Manual page 2

Remove the two gantry clips securing
6
the extruder by pushing down the tabs
on each end of the clips.
Store the removed clips and reuse when
transporting the printing for shipping.
TURNING ON THE PRINTER
1
Make sure the power switch on the printer is in the Off position ( O ).
2 Insert the female end into the power socket located on the back of the printer.
3
Insert the male end of the power cord into an electrical socket.
4
Turn on the printer by ipping the power switch to the On position ( I ).
INSTALLING THE FILAMENT
Extend the lament guide tube
1
from the retracted position.
Remove the lament spool from
2
the packaging and place it on
the spool holder.
Take the end of the lament
3 from the spool and insert it
into the guide tube.
Make sure the spool will spin
clockwise as the lament
feeds into the guide tube.
2x
