Tinkerine Studio Ditto Pro Quick Start Manual

Hide thumbs Also See for Ditto Pro:
1
2
3
4
5

Advertisement

Table of Contents

See also: User Manual
UNBOXING TIPS
2
Remove lament and shipping bracket from the box.
A
B
Accessory Checklist
Power Cable
3
USB Cable
Hex Wrench
Use a pair of box cutters to trim along the taped edges and peel back the outer box aps.
The Ditto
Pro 3D Printer can be too heavy to lift out of the box by yourself. Ask for help to
™
prevent injury or damages to the printer.
Make sure you have a pair of scissors handy to remove zip ties that fasten down printer
components during shipping.
1
Open shipping box and remove top shipping foam bracket.
Remove shipping bracket and accessories box from printer.
A
Glass Print Bed
PAGE 1
B
Print Bed Clips x4
SD Card

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ditto Pro and is the answer not in the manual?

Questions and answers

Related Manuals for Tinkerine Studio Ditto Pro

Summary of Contents for Tinkerine Studio Ditto Pro

  • Page 1 Use a pair of box cutters to trim along the taped edges and peel back the outer box aps. The Ditto Pro 3D Printer can be too heavy to lift out of the box by yourself. Ask for help to ™...

  • Page 2: Turning On The Printer

    UNBOXING TIPS Lift the printer out of the box and place it down on a rm surface. Make sure the printer is located near an accessible power outlet. Using a pair of scissors, cut away the zip ties that are securing the extruder in place. There will be one tie per axis. DPR1234567 John Doe Keep the Inspection Certi cate...

  • Page 3: Installing The Filament

    INSTALLING THE FILAMENT Extend the lament guide tube from the retracted position. Remove the lament spool from the packaging and place it on the spool holder. Take the end of the lament from the spool and insert it into the guide tube. Thread the lament through the guide tube and insert it into the extruder.

  • Page 4: Starting A Print

    INSTALLING THE PRINT BED Place the glass print surface onto the bed with the blue painter’s tape side facing upward. The tape will act as an adhesion material for the plastic. Replace any worn or damaged blue painter’s tape as needed to ensure that your prints stick properly during the printing process.

  • Page 5: Bed Leveling Guide

    BED LEVELING GUIDE To ensure that your prints always stick to the glass build plate, the build surface must be properly leveled so that the nozzle is at an equal set distance across the print surface. Use the Bed Leveling Wizard and follow the on-screen instructions to assist you in leveling the print bed.
