TPA-MHL2-8R – Quick Start Guide
HDMI -> MHL
MHL SINK DUT
CBUS PASSIVE MONITOR
2.2
What is in the TPA-MHL2-8R shipping box
The TPA-MHL2-8R instrument shipping container includes the items listed in the table below:
Table 1-1: TPA-MHL2-8R Shipping Box Contents
Item
TPA-MHL2-8R
Power Adapter assembly
MHL Cable Kit
(optional)
2.3
Power Considerations
The TPA-MHL2-8R is powered through a 12VDC source jack. The TPA-MHL2-8R is supplied with a12V DC power
supply and charger and line cord.
November 20, 2013
HDMI IN
MHL OUT
TO DUT
MHL IN
FROM SOURCE
MHL OUT
TO SINK
TO 980
TRIGGER IN
CBUS
12V DC power supply
Line cord
Contents
RG590A BNC cable
(2) MHL Cables
HDMI Cable
This is an HDMI input used for HDCP compliance testing of MHL
sink devices. An HDMI cable is connected to the Encryption Status
Tester (EST) used with the 882EA HDMI output. For basic
functional testing of an MHL sink device, an HDMI source devices
or 780 Handheld Test Instrument is connected to this port.
Connect MHL cable to the MHL sink device under test, e.g. HDTV.
Connect MHL cable from MHL source device under test, e.g.
mobile phone.
Connect MHL cable to the MHL sink device under test, e.g. HDTV.
Connect coax cable to TRIG IN port on 980 Protocol Analyzer.
Part No.
00-00233
25-00094
30A00400A03
78-00061
30-00125
30-00189
30-00146
Page 6
Revision B2
