User's Manual
BCD-3000
Customer Display
Rev. 1.00
http://www.bixolon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCD-3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIXOLON BCD-3000

Summary of Contents for BIXOLON BCD-3000

  • Page 1 User’s Manual BCD-3000 Customer Display Rev. 1.00 http://www.bixolon.com...
  • Page 2 BCD-3000 Introduction BCD-3000 is designed to be used while connected to computer peripherals and electronic devices such as ECR (Electronic Cash Register) and POS (Point Of Sales). ※ The main features of the printer are as follows: 1. Customer Display LCD Model 2.

  • Page 3: Table Of Contents

    BCD-3000 Table of Contents 1. Product Components ......................4 2. Unpacking ..........................5 3. How to Connect & Size ......................6 3-1 How to Connect (USB) ...................... 6 3-2 How to Connect (RJ45) ..................... 7 3-3 Sizes ..........................7 4. Features ..........................8 4-1 Tilting..........................

  • Page 4: Product Components

    BCD-3000 1. Product Components • The following display models are available BCD-3000 Component Description Brightness Level Control the brightness level of the backlight on the display Control Switch (knob) Features a LCD screen. Display The screen can be tilted. Remove the protective film on the screen before use.

  • Page 5: Unpacking

    BCD-3000 2. Unpacking BCD-3000 Installation Guide USB Cable (Optional) RJ45 Serial Cable (Optional,40cm) - 5 - Rev. 1.00...

  • Page 6: How To Connect & Size

    BCD-3000 3. How to Connect & Size 3-1 How to Connect (USB) 1) Install the USB Virtual COM driver. 2) Connect the display cable to the USB port on a PC. 3) Turn on the PC and display. The PC will automatically detect new hardware connected to the USB port.

  • Page 7: How To Connect (Rj45)

    BCD-3000 Serial (RJ45) Use only the compatible cable as the RJ45 port is designed exclusively for Bixolon SRP-Q300/302 printer serial (UART) Caution or Warning communication port. - Do not connect the RJ45 Plug to any port other than the serial communication port (especially, LAN port) to avoid damage.

  • Page 8: Features

    BCD-3000 4. Features 4-1 Tilting • The device can be tilted to the degree you want. Please follow the instructions below to avoid damage or malfunction when installing the device. The screen can be tilted to the right from the center line. (Tilt: max. 35°) Center Line 35°...

  • Page 9: Lcd Brightness Level Control

    BCD-3000 4-2 LCD Brightness Level Control • The brightness level of the LCD backlight can be adjusted using the Brightness Level Control Switch (knob). Brightness Control Switch (knob) Bright Dark - Do not use any tools other than your hands to control the Caution or Warning Brightness Level switch (knob) to avoid damage.

  • Page 10: Connection

    BCD-3000 5. Connection 5-1 USB Communication 5-1-1 USB Interface Connector 5-1-2 USB Interface Connector Pin Layout Pin No. Signal Designation(Color) Function Shell Shield Drain cable Grounding of frame VBUS Host power White Data line (D-) Green Data line (D+) Black...

  • Page 11: Vmsm (Virtual Memory Switch Manager)

    BCD-3000 6 VMSM (Virtual Memory Switch Manager) • Other than DIP switch settings, you can change the following settings using VMSM software. The following settings apply when powered on and are executed by the initialization command. 1) MSW 1 Memory...
  • Page 12 ESC/POS is 0: ESC/POS (*) 8 Emulation Selection n = 0 selected 1: CD5220 (*) In connecting BCD-3000 with SRP-Q300 via Serial communication, baud rates will fix at 9600bps. (*) Refer to following Table Memory Switch Baud rate(bps) Remark MSW3-3...

  • Page 13: Specifications

    BCD-3000 7. Specifications Display Display Method STN LCD Background / Display Color Blue / White Text(Image) Active Area (W) x (H) mm 118.5 x 45.5 Visual Area (W) x (H) mm 127.2 x 33.9 Brightness (cd/m²) Character Number (Letters) x (Lines)
  • Page 14 BCD-3000 Warning - U.S.A This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 15 BCD-3000 Revision history Rev. Date Page Description 1.00 10.05.17 - 15 - Rev. 1.00...
