Model #
EV-5105-N1SQ
EV-T5105-N2SQ
Features:
/
" 1.3MP Sony STARVIS CMOS
1
3.2
2.4mm Wide angle lens
Weatherproof construction
Vandal-resistant design
Adjustable mounting angle
Wall-Plate Cameras
Lens
Image Sensor
/
" 1.3MP Sony
1
3.2
2.4mm
STARVIS CMOS
®
Manual
Resolution
1000TVL
720p
Includes: 1 camera, 1 single-gang plate,
1 slimline plate, and angled mounting rings
2DNR (2D Digital Noise Reduction)
WDR (Wide Dynamic Range)
12VDC Operating voltage
Video Output Format
NTSC
HD-TVI
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ENFORCER EV-T5105-N2SQ
Summary of Contents for ENFORCER EV-T5105-N2SQ
- Page 1 Resolution Video Output Format EV-5105-N1SQ 1000TVL NTSC " 1.3MP Sony 2.4mm STARVIS CMOS EV-T5105-N2SQ 720p HD-TVI Features: Includes: 1 camera, 1 single-gang plate, " 1.3MP Sony STARVIS CMOS 2.4mm Wide angle lens 1 slimline plate, and angled mounting rings ...
- Page 2 1x Camera 1x Angled rubber ring (EV-5105-N1SQ) 1x Slimline plate 2x Mounting screws 1x Angled aluminum ring (EV-5105-N1SQ) 1x Single-gang plate 1x Aluminum hex nut 2x Angled aluminum rings (EV-T5105-N2SQ) 1x Manual Dimensions: EV-5105-N1SQ EV-T5105-N2SQ Single-gang plate Slimline plate Camera body Camera body "...
- Page 3 ENFORCER Wall-Plate Cameras Before Starting: 1. Read this manual carefully and keep it for future 4. Do not mount the camera in areas exposed to reference. radiation, strong magnetic fields, or strong 2. Use the camera within given temperature and electrical signals.
- Page 4 ENFORCER Wall-Plate Cameras Troubleshooting: Check that the camera is powered up Check that the power supply's polarity is correct The screen is blank Check that the monitor is powered up Check that the video cable connecting the camera to the monitor is connected properly ...
