- Page 1 Wall-Plate Camera Manual EV-5105-N1SQ Includes 1 single-gang (NTSC) EV-5105-P1SQ and 1 slimline plate (PAL) EV-5145-N1SQ (NTSC) Includes 1 European plate EV-5145-P1SQ (PAL) Note: Each set includes only 1 camera.
-
Page 2: Specifications
ENFORCER Wall-Plate Camera Specifications: EV-5105-N1SQ EV-5105-P1SQ EV-5145-N1SQ EV-5145-P1SQ Type Wall Plate Camera Plate type 1 Single-gang, 1 slimline 1 European ” Interline Color CCD Resolution 700 TV Lines Video output format NTSC NTSC Effective pixels 976x494 pixels 976x582 pixels 976x494 pixels... -
Page 3: Mounting Options
ENFORCER Wall-Plate Camera Before Starting: 1. Please read this manual carefully and keep it for 4. Do not mount the camera in areas exposed to radiation, future reference. strong magnetic fields, or strong electrical signals. 2. Use the camera within given temperature and 5. -
Page 4: Troubleshooting
ENFORCER Wall-Plate Camera Troubleshooting: • Check that the camera is powered up. • Check that the power supply’s polarity is correct. The screen is blank. • Check that the monitor is powered up. • Check that the video cable connecting the camera to the monitor is connected properly.
