Instruction Manual
EV-6680 Series
Motion-activated LED
programmable from the
OSD menu, simulating a
real PIR sensor.
EV-6681 Series
Invisible 940nm IR
LEDs provide infrared
light for the camera but
are invisible to the
human eye.
Model
EV-6680-N3WQ
EV-6680-P3WQ
EV-6681-N3WQ
EV-6681-P3WQ
Camera is covertly hidden in a
•
non-functioning PIR sensor housing
OSD (On-Screen Display) for
•
programming special features
Note: Model numbers that end with "Q" or that have a round green "Q" sticker signify RoHS-compliant products.
Covert PIR Camera
(Non-functioning PIR)
Manual
Format
NTSC
PAL
NTSC
PAL
Programmable
Motion-Activated LED
Yes
Yes
No
No
/
" Sony CCD
1
•
3
3.7mm Lens
•
700 TV Lines, 960H high resolution
•
Covert
IR LEDs
No
No
Yes
Yes
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ENFORCER EV-6680-N3WQ
Summary of Contents for ENFORCER EV-6680-N3WQ
- Page 1 LEDs provide infrared light for the camera but are invisible to the human eye. Programmable Covert Model Format Motion-Activated LED IR LEDs EV-6680-N3WQ NTSC EV-6680-P3WQ EV-6681-N3WQ NTSC EV-6681-P3WQ Camera is covertly hidden in a ” Sony CCD • • non-functioning PIR sensor housing 3.7mm Lens...
-
