NOTE:
•
-XX, -X mean standardized parts, so they may
have some differences from the original one.
•
Items marked "*" are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
5-1. CABINET SECTION
2
Ref. No.
1
1
2
3
4
5
6
7
8
9
10
Downloaded from
www.Manualslib.com
7
5
4
5
6
3
8
9
1
Part No.
Description
X-3380-592-1 CABINET (FRONT) ASSY (EXCEPT CND)
X-3380-593-1 CABINET (FRONT) ASSY (CND)
3-881-938-00 STRAP, HAND
7-624-104-04 STOP RING 2.0, TYPE -E
3-227-386-01 BUTTON (PAGE)
3-227-387-01 SHEET (BUTTON), ADHESIVE
3-227-385-01 BUTTON (SCAN)
3-227-384-01 BUTTON (10 KEY)
3-227-388-01 BUTTON (LIGHT)
3-227-405-01 KNOB (HOLD)
3-227-401-01 PLATE (ANT), CONTACT
manuals search engine
SECTION 5
EXPLODED VIEWS
•
The mechanical parts with no reference number
in the exploded views are not supplied.
•
Hardware (# mark) list and accessories and
packing materials are given in the last of this
parts list.
10
11
Remarks
Ref. No.
Part No.
11
3-893-852-01 CUSHION (BATTERY CASE LID)
12
3-918-696-01 SCREW (M3X6 LOCK ACE)
13
3-227-402-01 STAND
14
3-227-403-01 TERMINAL (+/-), BATTERY
15
7-685-152-19 SCREW +BTP 3X25 TYPE2 N-S
16
3-893-846-01 FOOT, RUBBER
17
3-227-400-01 CABINET (REAR) (EXCEPT CH)
17
3-227-400-11 CABINET (REAR) (CH)
18
3-227-404-01 LID, BATTERY CASE
ANT101 1-501-712-11 ANTENNA, TELESCOPIC
ICF-SW7600GR
•
Abbreviation
CH
: Chinese model
CND : Canadian model
EA
: Saudi Arabia model
ANT101
12
15
17
18
Description
13
15
14
15
16
Remarks
17
