PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M8 Split
Washer Wave Washer M8 Washer
(90)–3 (111)–2 (88)–6
M4 x 16mm Screw M4 x 16mm Round #8 x 16mm Screw
M8 Jam Nut M10 Locknut
(103)–6 (112)–4
Head Screw
(79)–7 (81)–2
(101)–6
#10 x 13mm Screw
M4 x 32mm Round
#10 x 51mm Screw
(104)–4
Head Screw (105)–6
(108)–4
Hub Screw (87)–8
M8 x 23mm Shoulder M8 x 23mm Screw M8 x 41mm Bolt
Screw (115)–4 (78)–4
(84)–4
M8 x 69mm Bolt (80)–1 M8 x 80mm Bolt (116)–2
M10 x 80mm Carriage Bolt (82)–2
M10 x 127mm Screw (83)–2
