7. Identify the Right Upright Cover (17) and hold it
against the right side of the Upright (3).
Attach the Right Upright Cover (17) with two
M4 x 16mm Round Head Screws (101).
Attach the Left Upright Cover (39) in the
same way.
8. Identify the Right and Left Handlebars (119, 120)
and orient them as shown.
Tip: Avoid pinching the Pulse Wires (118).
Attach the Right and Left Handlebars (119, 120)
to the Upright (3) with two M8 x 80mm Bolts
(116) and two M8 Jam Nuts (79).
7
39
101
3
8
116
120
116
118
Avoid pinching
the wires
9
17
101
3
79
119
118
