Basic Settings

This chapter describes the basic settings in Anybus Configuration Manager. For explanations of
advanced configuration settings, please refer to the help texts that are displayed in the Informa-
tion Window when building the configuration.
5.2.1 Project
Used to store project information such as project name, project creator, version and description.
5.2.2 Network Settings
General
During startup the fieldbus interface is initialized to fit the configuration created in Anybus Con-
figuration Manager. Some initialization parameters can optionally be set manually to provide
better control over how the data shall be treated by the Anybus Communicator CAN.
Network Type
The higher level network type must be selected here in order to create a valid configuration.
5.2.3 Communicator Settings
Additional settings for the Anybus Communicator CAN.
General
Parameter
Control/Status Word
Start-up Operation Mode
Transaction Live List
Statistics
Parameter
Counters
Receive Counter
Address
Transmit Counter
Address
Fatal Event
Parameter
Action
®
Anybus Communicator ™ CAN PROFINET
Comment
If enabled, the Control/Status Word will occupy the first two bytes of the Output/In-
put areas of the memory.
To avoid memory address collisions this parameter should be enabled before
adding frames to the configuration.
Decides the start-up mode of the CAN subnetwork if the Control Word is enabled.
If the Transaction Live List is enabled it is mapped from the beginning of the input
area or, if the Control/Status Word is enabled, after the Status Word. It is possible
to map from 8 to 128 transactions, in steps of 8. Each transaction is represented
by a bit that tells the system whether the transaction is alive or not.
Comment
The receive counter and the transmit counter count successful CAN messages on
the subnetwork. If enabled, the counters can be mapped to the input data area.
The first free address in the input data area is selected by default. The counters
can be disabled and enabled separately.
To avoid memory address collisions this parameter should be enabled before
adding frames to the configuration.
The messages are counted only if they have been configured in Anybus Configu-
ration Manager.
Enter the address in the input data area where the receive counter shall be
mapped. The receive counter occupies 2 bytes.
Enter the address in the input data area where the transmit counter shall be
mapped. The transmit counter occupies 2 bytes.
Values Comment
Stay in Safe-State In case of a fatal software event, the Anybus Communica-
tor CAN will be locked in the safe state.
Software Reset In case of a fatal software event, the software will be reset
and the Anybus Communicator CAN will be restarted.
®
