INSTRUCTION MANUAL
3290-10
CLAMP ON AC/DC HiTESTER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3290-10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hioki 3290-10

Summary of Contents for Hioki 3290-10

  • Page 1 INSTRUCTION MANUAL 3290-10 CLAMP ON AC/DC HiTESTER...

  • Page 3: Table Of Contents

    1 Overview Product Overview ..........9 Features ............10 Identification of Controls and Indicators ... 12 1.3.1 Model 3290-10 CLAMP ON AC/DC HiTESTER 12 1.3.2 Model 9691, 9692, 9693 CLAMP ON AC/DC SENSOR (Optional)..........18 Buttons Operations ........... 19 Measurement Modes ........20 Quick References ..........
  • Page 4 Contents 3 Basic Measurement Procedure Measuring DC Current ........39 Measuring AC Current ........40 DC Integration ..........41 AC Integration by Timer ........42 Outputting Integral Values ........ 44 Measuring Duty by Timer ......... 46 4 Measurement Procedure Verifications Before Measuring ......49 Selecting the Measurement Parameter ....
  • Page 5 6.3.2 Model 9692 CLAMP ON AC/DC SENSOR ..118 6.3.3 Model 9693 CLAMP ON AC/DC SENSOR ..120 Combined Accuracy ........122 6.4.1 Models 9691 + 3290-10 Combined Accuracy .122 6.4.2 Model 9692 + 3290-10 Combined Accuracy ...124 6.4.3 Model 9693 + 3290-10 Combined Accuracy ...125 6.4.4 Method of Calculation ........126...
  • Page 6 Contents...

  • Page 7: Introduction

    Introduction Introduction Thank you for purchasing the HIOKI “Model 3290-10 CLAMP ON AC/DC HiTESTER.” To obtain maximum performance from the meter, please read this manual first, and keep it handy for future reference. This manual describes the operation of the 3290-10 when used with the 9691, 9692, or 9693 CLAMP ON AC/DC SENSOR.

  • Page 8: Safety Notes

    Safety Notes Safety Notes This meter is designed to comply with IEC 61010 Safety Stan- dards, and has been thoroughly tested for safety prior to shipment. However, mishandling during use could result in injury or death, as well as damage to the meter. Be certain that you understand the instructions and precautions in the manual before use.
  • Page 9 Safety Notes The following symbols in this manual indicate the relative impor- tance of cautions and warnings. Indicates that incorrect operation presents an extreme hazard that could result in serious injury or death to the user. Indicates that incorrect operation presents a signifi- cant hazard that could result in serious injury or death to the user.
  • Page 10 Safety Notes Measurement categories (Overvoltage categories) This device complies with CATIII (600 V), CATII (1000 V) safety requirements. To ensure safe operation of measurement devices, IEC 61010 establishes safety standards for various electrical environments, categorized as CAT I to CAT IV, and called measurement catego- ries.

  • Page 11: Usage Notes

    Follow these precautions to ensure safe operation and to obtain the full benefits of the various functions. Setting Up the 3290-10 • This meter should be installed and operated indoors only, between 0 and 40°C and 80% RH or less.
  • Page 12 Before using the meter the first time, verify that it operates normally to ensure that the no damage occurred during storage or shipping. If you find any damage, contact your dealer or Hioki representative. Before using the meter, make sure that the insulation on the probes is undamaged and that no bare conductors are improperly exposed.
  • Page 13 Usage Notes • The maximum continuous-input limit is obtained from the tem- perature increase due to self-heating during measurement. To prevent damage to the clamp-on sensor, do not input a current exceeding this limit. • The maximum continuous-input limit varies depending on the clamp-on sensor and the frequency of the current to be mea- sured.
  • Page 14 Usage Notes...

  • Page 15: Overview

    1.1 Product Overview Overview 1.1 Product Overview The 3290-10 CLAMP ON AC/DC HiTESTER is used with the 9691, 9692, or 9693 CLAMP ON AC/DC SENSOR. These sensors are interchangeable and any model can be used with the 3290-10. The 3290-10 automatically detects the sensor connected and sets up the appropriate range.

  • Page 16: Features

    1.2 Features 1.2 Features Current integration functions (total, positive and negative integrals) Polarity-specific positive and negative current integrals can be measured (at ten samples/second) D/A output (selectable total, positive or negative integral). Measures the mean current value within a specified interval (total integral / integration interval).
  • Page 17 1.2 Features Low-frequency current measurement AC current as low as 1 Hz can be measured in the SLOW AC+DC mode. Filter function Switchable 500-Hz low-pass filter (in AC and AC+DC modes) Switchable 1-Hz low-pass filter (in DC mode, for MON output) AC+DC measurement Measures superimposed AC and DC components and full- and half-wave rectified waveforms.

  • Page 18: Identification Of Controls And Indicators

    1.3 Identification of Controls and Indicators 1.3 Identification of Controls and Indicators 1.3.1 Model 3290-10 CLAMP ON AC/DC HiTESTER Front Panel Output Jack 1 Output Jack 2 (OUT1) (OUT2) Connect the optional Connect the optional 9094 AC Adapter OUTPUT CORD to this...
  • Page 19 1.3 Identification of Controls and Indicators Notation for multi-button operations : Press Button A and button B at the same time. Example: SHIFT Press the buttons at the same time. SHIFT POWER → : Press Button A and then press Button B. →...
  • Page 20 1.3 Identification of Controls and Indicators Current Measurement (see page 53) • Selects auto range or manual range. (Hz mode uses auto-ranging only) AUTO → L → H • The current ranges for the 9691 and 9692 are 20 A and 200 A; the ranges for the 9693 are 200 A and 2000 A.
  • Page 21 1.3 Identification of Controls and Indicators • Suspends or deactivates the display-updating function. • Holding down the button and turning power on disables the auto power-off function. (see page 104) • Press and hold for two seconds to store settings and data. (See page 101) •...
  • Page 22 1.3 Identification of Controls and Indicators Direct Current (DC) 500 Hz filter is active. FILTER Alternating Current (AC) Maximum value Alternating Current and Direct Minimum value Current (AC+DC) Auto zero adjustment is active. Interval mean current value Stores integral and Low battery warning TIME duty measurement data...
  • Page 23 Unfasten the screw, then remove the case to replace the battery. Others Top Case Cover the 3290-10 with this case when not in use to protect the LCD, buttons and jacks. Top Case Clasp Insert the clasp into the top case to attach the case.

  • Page 24: Model 9691, 9692, 9693 Clamp On Ac/Dc Sensor (Optional)

    1.3 Identification of Controls and Indicators 1.3.2 Model 9691, 9692, 9693 CLAMP ON AC/DC SEN- SOR (Optional) Model 9693 Model 9691 Model 9692 Output Connector...

  • Page 25: Buttons Operations

    1.4 Buttons Operations 1.4 Buttons Operations AC+DC AUTO range AUTO range AUTO range AUTO range L range L range L range H range H range H range PEAK PEAK + PEAK - PEAK Total integral Integral value Integral value Positive integral Interval mean Interval mean current value...

  • Page 26: Measurement Modes

    1.5 Measurement Modes 1.5 Measurement Modes For current, three modes are provided: DC (direct current, ), AC (alternating current, ), and AC+DC (alternating current and direct current, ) modes. Select a proper mode according to the waveform shown below: OUTPUT (only for current mode) Input Mode Display...

  • Page 27: Quick References

    1.6 Quick References 1.6 Quick References Operations Page DC measurement Measure- ment → SHIFT DC peak measurement Measure- PEAK CLEAR ment → SHIFT AC measurement Measure- ment AC peak measurement Measure- PEAK CLEAR ment AC+DC measurement Measure- ment → SHIFT Press twice AC+DC peak measurement Measure-...
  • Page 28 1.6 Quick References Operations Page DC integral measurement INTEG CLEAR → SHIFT Measure- START ment → SHIFT DC interval mean current measurement INTEG CLEAR → SHIFT Measure- START ment → SHIFT Press three times AC integral measurement Measure- INTEG CLEAR START ment →...
  • Page 29 1.6 Quick References Operations Page AC+DC interval mean current measurement INTEG CLEAR → SHIFT Press twice Measure- START ment → SHIFT DC duty and operating time measurements Duty Numerical Accept the Display Entry Display CLEAR Setting Setting → → SHIFT SHIFT Display the duty Display the...
  • Page 30 1.6 Quick References Operations Page View elapsed measurement time 66, 79 Set the timer Accept the Timer Numerical Setting Setting Display Entry Display 66, 79 → SHIFT → SHIFT Set the number of repetitions Accept the Numerical Number of Times Timer Setting Entry Display...
  • Page 31 1.6 Quick References Operations Page Make output settings AC, AC+DC Output OUT1: MON OUT1: REC → → 51, 62 → → OUT2: REC SHIFT OUT2: REC Bar graph ± Change the display update rate (AC and AC+DC modes) → → →...
  • Page 32 1.6 Quick References Operations Page View repetition data (TIME is displayed) → → Verify remaining battery charge → SHIFT Suspend display updating (TIME is not displayed) HOLD is displayed. Disable: Button lock → LOCK is displayed. → Disable: SHIFT SHIFT Disabling the auto power off function Power ON is not displayed.
  • Page 33 Measurement Preparations Attaching the Strap See Section 2.1 "Attaching the Strap" (page 28) See Section 2.2 "Connecting Connecting Power Power" (page 29) See Section 2.3 "Connecting the Connecting the Clamp-on Sensor CLAMP ON AC/DC SENSOR" (page 33) See Section 2.4 "Connecting Connecting the Output Cords the Output Cords (Optional)"...

  • Page 34: Attaching The Strap

    2.1 Attaching the Strap 2.1 Attaching the Strap Using the 3290-10 with the strap attached improves operability. Fasten the two straps together into one. Attach each end to the 3290-10 as shown in the figure above.

  • Page 35: Connecting Power

    • Handle and dispose of batteries in accordance with local regulations. Remove the batteries when operating from external power. When the batteries are installed, the 3290-10 will turn on even if the polar- ity of the external power is reversed, damaging the meter. • The indicator appears when battery voltage becomes low.

  • Page 36: Connecting The Ac Adapter (Optional)

    (such as with new batteries), the batteries power the meter until battery voltage decreases, at which point operation switches to the AC adapter. Connecting the AC Adapter Confirm that the 3290-10 is turned off. Remove the dust cap over the AC adapter jack, and plug in the AC adapter securely.

  • Page 37: Using External Power

    2.2 Connecting Power 2.2.3 Using External Power • To avoid electric shock and short-circuit accidents when connecting the optional 2m external power cable, first be sure the meter is turned off. • The external voltage requirements are 8.4 to 15.6 V DC at 1.2 VA.
  • Page 38 • When using the external power, note that current of approxi- mately 3 mA is consumed regardless of whether the power switch of the 3290-10 is on or off. • While operating from the external power, the remaining battery charge indicator (bar graph) indicates the loaded output volt- age (about 6V) of the external power.

  • Page 39: Connecting The Clamp On Ac/Dc Sensor

    • When disconnecting the output connector of the clamp-on sen- sor from the 3290-10 sensor jack, be sure to hold it by the metal part and pull it upward. Because the connectors lock, pulling or twisting the cable can damage the cable.

  • Page 40: Connecting The Output Cords (Optional)

    2.4 Connecting the Output Cords (Optional) To use current measurement output (OUT1) or integral output (OUT2), connect the optional Model 9094 OUTPUT CORD to the output jack. Confirm that the 3290-10 is Connecting the Output Cord turned off. OUT 1:...

  • Page 41: Turning Power On And Off

    2.5 Turning Power On and Off 2.5 Turning Power On and Off Power On Press the button to turn the meter on. All display segments should appear. After displaying the model name (3290), the bar graph shows the remaining battery charge.
  • Page 42 2.5 Turning Power On and Off...

  • Page 43: Basic Measurement Procedure

    Basic Measurement Procedure • To avoid short circuits and potentially life-threatening haz- ards, never attach the clamp to a circuit that operates at more than 600V, or over bare conductors. • Clamp sensor should only be connected to the secondary side of a breaker, so the breaker can prevent an accident if a short circuit occurs.
  • Page 44 • Be sure to read the instruction manual for the clamp sensor to be used before starting measurement. • The hall element is used for the detector of the clamp-on sen- sor. The hall element tends to drift with age or due to the ambi- ent temperature.

  • Page 45: Measuring Dc Current

    3.1 Measuring DC Current 3.1 Measuring DC Current Sensor used : Model 9691 CLAMP ON AC/DC SENSOR Range : AUTO Press the button to select DC Button presses are ignored if TIME is dis- → played: press to clear it. →...

  • Page 46: Measuring Ac Current

    3.2 Measuring AC Current 3.2 Measuring AC Current Sensor used : Model 9691 CLAMP ON AC/DC SENSOR Range : AUTO Press the button to select AC Button presses are ignored if TIME is dis- → played: press to clear it. When measuring current below 10 Hz, use the →...

  • Page 47: Dc Integration

    3.3 DC Integration 3.3 DC Integration Sensor used : Model 9691 CLAMP ON AC/DC SENSOR Measured current : 20 A or less Manually stop measuring (no timer) Press the button to select DC Button presses are ignored if TIME is dis- →...

  • Page 48: Ac Integration By Timer

    3.4 AC Integration by Timer 3.4 AC Integration by Timer Sensor used : Model 9691 CLAMP ON AC/DC SENSOR Measured current : at least 20 A Timer : 30 minutes Number of repetitions : 10 times Press the button to select AC Button presses are ignored if TIME is dis-...
  • Page 49 3.4 AC Integration by Timer Press to display the repetition entry display. Blinking Press the to set 10 repetitions. Blinking → Press ) to SHIFT INPUT/SET accept the entered values. Press button to display the inte- gral. Unless output is required, the integrating range can be left as AUTO.

  • Page 50: Outputting Integral Values

    3.5 Outputting Integral Values 3.5 Outputting Integral Values Sensor used : Model 9691 CLAMP ON AC/DC SENSOR Measured current : 100 A or less After two hours or less, stop measurement manually (no timer) → Maximum integral value derived from measured current and measurement time is 200 Ah (100 A X 2 h) or less OUT1 : MON output...
  • Page 51 3.5 Outputting Integral Values → Press ) to dis- SHIFT OUTPUT play the output settings. The bar graph appears in both "+" and "-" regions. → Press ) so that SHIFT OUTPUT the bar graph appears only in the "+" region.

  • Page 52: Measuring Duty By Timer

    3.6 Measuring Duty by Timer 3.6 Measuring Duty by Timer Sensor used : Model 9691 CLAMP ON AC/DC SENSOR Measured current : 20 A or less Current threshold :2 A AC (defines the operating state as 2 A or higher current) Timer : 24 hours Repetitions...
  • Page 53 3.6 Measuring Duty by Timer → Press ) to dis- SHIFT INPUT/SET play the timer display. → Press ) to dis- SHIFT INPUT/SET play the numerical entry display. Blinking Press the buttons to enter 24 hours. → Press ) to SHIFT INPUT/SET Blinking...
  • Page 54 3.6 Measuring Duty by Timer...

  • Page 55: Measurement Procedure

    4.1 Verifications Before Measuring Before using the meter the first time, verify that it operates normally to ensure that the no damage occurred during storage or shipping. If you find any damage, contact your dealer or Hioki representative. Verification Location Verification Content...

  • Page 56: Selecting The Measurement Parameter

    4.2 Selecting the Measurement Parameter 4.2 Selecting the Measurement Parameter Select the parameter to measure from the following. • Current (see page 51) • Frequency (see page 51) • Peak Current (see page 62) Duty & Integral • Integral (see page 66) •...

  • Page 57: Measuring Current

    4.3 Measuring Current 4.3 Measuring Current Current Measurement Mode Selection See page 52 DC Measurement Frequency Not including DC Measurement AC Measurement AC+DC Range Selection Range Selection Range Selection See page 53 See page 53 See page 53 Is Output Required? Is Output Required? Is Output Required? →...
  • Page 58 4.3 Measuring Current Mode Selection Press the button to select the mode. → Button presses are ignored if TIME is displayed: press to clear it. For Current Measurement DC Mode Select this to measure DC current. AC Mode Select this to measure AC current. AC+DC Mode Select this to measure current other than the above.
  • Page 59 4.3 Measuring Current Range Selection Press the button to select the range. For Current Measurement AUTO Ranging AUTO When using the 9691 or 9692 : 20.00 A/ 200.0 A When using the 9693 : 200.0 A/ 2000 A L (Low) Range When using the 9691 or 9692 : 20.00 A When using the 9693...
  • Page 60 4.3 Measuring Current Output Settings If you don’t need to make any output settings, proceed to "Auto Zero Adjustment (for DC and AC+DC modes)" (page 57). Confirm that the optional 9094 OUTPUT CORD is inserted securely into output jack 1 (OUT1) (OUT2 is for integral value out- put) →...
  • Page 61 100 A 200 A 500 A 1000 A 2000 A Numerical values are current per division on the connected instrument (e.g., data recorder). Frequency Characteristics of clamp-on sensor + Model 3290-10 MON Output 1000 10000 100000 入力周波数（Hz） Frequency (Hz) Models 9691+3290-10...
  • Page 62 4.3 Measuring Current • The input impedance of the connected instrument should be at least 1 MΩ. If the impedance is lower, displayed values may be affected. • To use the output function, be sure that is displayed by OUT1 →...
  • Page 63 4.3 Measuring Current Auto Zero Adjustment (for DC and AC+DC modes) See Section 5.1 "Auto Zero Adjustment Function" (page 89) Verify that the measurement current is zero, or that the clamp- on sensor is not clamped around a conductor. → Press ) to execute auto zero adjustment.
  • Page 64 4.3 Measuring Current Sensor Temperature Characteristics The 9691, 9692 and 9693 CLAMP ON AC/DC SENSORs employ a Hall-effect element for current detection. The zero point and sensi- tivity are therefore temperature dependent according to the charac- teristics of the individual Hall-effect element. Zero-Point Temperature Characteristics Because of the individual differences between Hall-effect ele- ments, the actual offset and rate of change cannot be specified.
  • Page 65 4.3 Measuring Current Model 9693 Zero Point vs. Temperature No.1 No.2 No.3 No.4 No.5 -2.0 -4.0 温度（℃） Temperature (°C) Sensor Sensitivity Temperature Characteristics Hall-element sensitivity is temperature dependent, so temperature compensation is provided in the circuitry. The examples show sensitivity variations (normalized to 23°C) with temperature change for different sensors (characteristics vary slightly from one element to another).
  • Page 66 4.3 Measuring Current Starting Measurement Open the sensor clamp and clamp it around the conductor to be measured, position the conductor at the center of the clamp, and start measuring. LOAD (DC mode case) Make sure that the direc tion of current flow in the conductor matches that SOURCE of the arrow on the...
  • Page 67 4.3 Measuring Current For Current Measurement • AC and AC+DC modes If fluctuations cause measured values to be hard to read, press → ) to select the SLOW display update SHIFT SAMPLE rate. • When the display update rate is and the measurement SLOW range changes automatically (by AUTO ranging) as a result of...

  • Page 68: Measuring Peak Current

    4.4 Measuring Peak Current 4.4 Measuring Peak Current Peak Current Measurement Mode Selection See page 63 Display of both polarities necessary Polarity display unnecessary Usable with all waveforms Usable with all wave- Not including DC forms AC Measurement (absolute value display) (absolute value display) AC+DC Selects Peak...
  • Page 69 4.4 Measuring Peak Current Mode Selection Press the button to select the mode. → Button presses are ignored if TIME is displayed: press to clear it. DC Mode Usable with all waveforms. Displays + (positive) and - (negative) peak values. AC Mode Usable with AC waveforms with no DC component.
  • Page 70 4.4 Measuring Peak Current Range Selection Press the button to select the range. AUTO Ranging AUTO When using the 9691 or 9692 : 20 A/ 200 A When using the 9693 : 200 A/ 2000 A L (Low) Range When using the 9691 or 9692 : 20 A When using the 9693 : 200 A...
  • Page 71 4.4 Measuring Peak Current Starting Measurement Open the sensor clamp and clamp it around the conductor to be measured, position the conductor at the center of the clamp, and start measuring. LOAD (DC mode case) Make sure that the direc tion of current flow in the conductor matches that SOURCE...

  • Page 72: Current Integration

    4.5 Current Integration 4.5 Current Integration Integral Measurement Preparations for See Section 4.3 "Measuring Current" Current Measurement See page 67 (page 51) Timer Setting Timer Settings Needed? Time Display Appears → SHIFT Display Integral See page 69 Value Settings Appear Clear INTEG Data Enter Timer Value...
  • Page 73 4.5 Current Integration Preparations for Current Measurement Preparing for current measurement. Follow the procedure beginning at Section 4.3 "Measuring Current" (page 51) up until "Starting Measurement" (page 60). Be aware of the temperature characteristics the 9691, 9692 and 9693 CLAMP ON AC/DC SENSORs.
  • Page 74 4.5 Current Integration Press the buttons to set the timer (from 1 minute to 99 hours, 59 minutes). : Increment/decrement digit : Move cursor to another digit Blinking Press the button to move the cursor to the right to display the repetition setting.
  • Page 75 4.5 Current Integration Integral Value Display Press the button to display the integral. Press the button to clear INTEG data (integral and interval mean values). Clearing INTEG data on the integral display clears RATE and PEAK data as well.
  • Page 76 4.5 Current Integration Integral Range Setting Press the button to select the range for the integral. • If no integral value output is needed, select AUTO ranging. • The integral range consists of five components for each cur- rent range (four are common, so there are a total of six range components).
  • Page 77 4.5 Current Integration Output Settings If no integral value output is needed, skip ahead to "Starting Mea- surement" (page 73). Confirm that the optional 9094 OUTPUT CORD is inserted securely into output jack 1 (OUT1) (OUT2 is for integral value out- put) →...
  • Page 78 4.5 Current Integration • The maximum count of 9999 produces 999.9 mV output. If the count exceeds 9999, the integral range is automatically incre- mented. → → Example: 99.99 Ah 100.0 Ah, 999.9 Ah 1.000 kAh → When this increment occurs, output steps from 999.9 mV →...
  • Page 79 4.5 Current Integration • The input impedance of the connected instrument should be at Ω least 1 M to avoid affecting the displayed value. • Output is unaffected by pressing the button. • Use the optional 9445-02 AC ADAPTER for long-term record- ing.
  • Page 80 4.5 Current Integration → Press ) to start integration. SHIFT START/STOP appears, and the colon ( ) in the elapsed time display blinks. START Auto power-off is disabled ( not displayed). → Press ) to stop integration. SHIFT START/STOP appears, and the colon ( ) in the elapsed time display stops STOP blinking.
  • Page 81 4.5 Current Integration To integrate continuously → Press SHIFT (START/STOP) again to start inte- (Cumulative integration) gration. is displayed.If the timer has been set, refer START to the following table regarding limitations (data is not stored when stopped). To resume integration after Press the button and then the button to clear...
  • Page 82 4.5 Current Integration Setting Example (Setting range is up to 99 hours, 59 minutes, in minute steps) 30 min 30 min 30 min 30 min 30 min Timer Setting Repetitions 9 times Once 2 times 3 times 10 times Setting (up to 20 times) Start Measurement View Data History...
  • Page 83 4.5 Current Integration About the Measurement Process The DC measurement method of this meter separates the input signal into positive and negative polarity components. A typical current integrator passes the signal through a low-pass fil- ter (LPF), then converts the waveform (e.g., square wave) into DC for measurement.
  • Page 84 4.5 Current Integration Functions available during measurement (START displayed) • View INTEG data (integral and interval mean value) • View PEAK data (peak values, etc.) • View elapsed time • View timer setting and repetition • View present current value •...

  • Page 85: Measuring Duty

    4.6 Measuring Duty 4.6 Measuring Duty Duty Measurement Preparations for See page 82 Current Measurement 4.3 "Measuring Current" (page 51) Timer Setting Display the Duty See page 80 Time Display Appears → SHIFT Clear RATE Data Value Settings → Appear SHIFT Show the Numeri- cal Entry Display...
  • Page 86 4.6 Measuring Duty Preparations for Current Measurement Preparing for current measurement. Follow the procedure beginning at Section 4.3 "Measuring Current" (page 51) up until "Starting Measurement" (page 60). Be aware of the temperature characteristics the 9691, 9692 and 9693 CLAMP ON AC/DC SENSORs.
  • Page 87 4.6 Measuring Duty Press the buttons to set the current threshold. The current threshold is the value used for judging the operating state. Blinking → Press ) to accept the setting. SHIFT INPUT/SET • Do not change the current range after setting the current threshold.
  • Page 88 4.6 Measuring Duty For DC measurements, the meter splits the signal into positive and Measurement negative components before low-pass filtering. The inherent Process response time of the filter suppresses the detection of short pulses, so errors can result in the operating time measurement. This error can affect the duty measurement (although current values below the threshold have no affect on the measurement).
  • Page 89 4.6 Measuring Duty Press the buttons to set the timer (from 1 minute to 99 hours, 59 minutes). : Increment/decrement digit : Move cursor to another digit Blinking Press the button to move the cursor to the right to display the repetition setting.
  • Page 90 4.6 Measuring Duty Duty Display Press the button to display the duty. Starting Measurement Open the sensor clamp and clamp it around the conductor to be measured, position the conductor at the center of the clamp, and start measuring. LOAD (DC mode case) Make sure that the direc tion of current flow in the...
  • Page 91 4.6 Measuring Duty → Press ) to start duty measure- SHIFT START/STOP ment. appears, and the colon ( ) in the elapsed time display blinks. START Auto power-off is disabled ( not displayed). → Press ) to stop duty measure- SHIFT START/STOP ment.
  • Page 92 4.6 Measuring Duty To measure continuously → Press SHIFT (START/STOP) again to start mea- (Continuous measurement) suring. is displayed.If the timer has been set, refer START to the following table regarding limitations. To resume measuring after Press the button and then the button to clear clearing RATE data →...
  • Page 93 4.6 Measuring Duty Setting Example (Setting range is up to 99 hours, 59 minutes, in minute steps) 30 min 30 min 30 min 30 min 30 min Timer Setting Repetitions Once 2 times 3 times 9 times 10 times Setting (up to 20 times) Start Measurement View Data History...
  • Page 94 4.6 Measuring Duty Functions available during measurement (START displayed) • View INTEG data (integral and interval mean value) • View RATE data (duty, operating time, and current threshold) • View PEAK data (peak, maximum, and minimum values) • View elapsed time •...

  • Page 95: Applicable Measurement Modes

    5.1 Auto Zero Adjustment Function Applicable Measurement Modes 5.1 Auto Zero Adjustment Function Measurement Modes: DC and AC+DC The auto-zero adjustment function automatically adjusts the offset in the internal circuit that results from temperature characteristics or clamp-sensor magnetization. The clamp core is magnetized when a large DC current is measured or a powerful magnet is placed close to the clamp core.

  • Page 96: Display Update Rate

    5.2 Display Update Rate 5.2 Display Update Rate Measurement Modes: AC, AC+DC The display update rate can be changed to suit measurement con- ditions. In the DC mode, this is fixed at about once per second. → Press SHIFT SAMPLE The display update rate changes as follows.
  • Page 97 5.2 Display Update Rate • The digital display update rate at power on is about twice per NORMAL second. • If fluctuations make the measured value hard to read during cur- SLOW rent measurement, set the display update rate to SLOW (about once every three seconds) to improve readability.

  • Page 98: Measurement Response Time

    5.3 Measurement Response Time 5.3 Measurement Response Time Measurement Modes: AC, AC+DC → Press SHIFT SAMPLE The measurement response time changes. See pages 93 and 94 SLOW FAST NORMAL • Changes to the display update rate and measurement response time are interdependent. •...
  • Page 99 5.3 Measurement Response Time Output Response Waveform (Rising Edge) FAST Input waveform OUT 1: REC output waveform 200 A 100 A → AC mode 200 A range: 0 A 180 A (45 Hz) 0.2 s NORMAL Input waveform OUT 1: REC output waveform 200 A 100 A →...
  • Page 100 5.3 Measurement Response Time Output Response Waveform (Falling Edge) FAST Input waveform OUT 1: REC output waveform → AC mode 200 A range: 200 A 20 A (45 Hz) 0.2 s NORMAL Input waveform OUT 1: REC output waveform → AC mode 200 A range: 200 A 20 A (10 Hz) 0.8 s...

  • Page 101: Filter Function

    5.4 Filter Function 5.4 Filter Function Measurement Modes: DC, AC, AC+DC This function can remove unwanted frequency components such as noise. → Press SHIFT FILTER The Filter function is enabled. → When OUT1 is set to MON output, press ) to DC Mode SHIFT FILTER...

  • Page 102: Data Hold

    5.5 Data Hold 5.5 Data Hold Use this function to suspend changes to the current display. is displayed, and the measured value and bar graph indica- tions are retained (display updating is suspended). During repeating measurements of integral or duty ( dis- TIME played), historical data can be viewed.

  • Page 103: Viewing Historical Data

    5.6 Viewing Historical Data 5.6 Viewing Historical Data Historical measurement data can be viewed while measuring. Press the button during repeating measurement ( HOLD displayed). The bar graph indicates the sequential number of the currently dis- played measurement. Use the buttons to scroll through collected measurement data.
  • Page 104 5.6 Viewing Historical Data (Setting range is up to 99 hours, 59 minutes, in minute steps) Timer Setting 30 min 30 min 30 min 30 min 30 min Repetitions 9 times Once 2 times 3 times 10 times Setting (up to 20 times) Start Measurement View Data History (After pressing...
  • Page 105 5.6 Viewing Historical Data Stored data for timer setting S and 20 repetitions is as follows. DC Mode Data Item No. ÉgÅ[É^Éã ΣA (=ΣB +ΣC Total Integral (Ah) ΣB Positive Integral (Ah) INTEG Data É×C Negative Integral (Ah) Interval Mean Value (=ΣA /S X 100) /S X 100)

  • Page 106: Saving Data

    5.7 Saving Data 5.7 Saving Data Data that you want to view after measuring (when is dis- TIME played) can be stored. (Data cannot be manually stored during measurement.) Settings are stored at the same time data is stored. However, because of the overwriting method employed, only one set of measurements can be stored (including the set of values of repeating measurements).

  • Page 107: Saving Settings

    5.8 Saving Settings 5.8 Saving Settings A frequently used measurement mode can be set up and saved as the meter power-on default. Other settings can also be saved (using the same overwriting pro- cedure as for saving data). With the meter turned on, set the desired measurement mode and range.

  • Page 108: Recalling Stored Data

    5.9 Recalling Stored Data 5.9 Recalling Stored Data Stored data can be recalled. See Section 5.7 "Saving Data" (page 100) Hold the button while pressing the button to turn the SHIFT meter on. Stored data is recalled. Verify the data. The procedure is the same as the second procedure in Section 5.6 "Viewing Historical Data"...

  • Page 109: Auto Power-Off Enabled

    5.11 Auto Power-off Enabled 5.11 Auto Power-off Enabled When approximately 10 minutes have elapsed since the last button operation, the power to the 3290-10 is automatically turned off. This prevents the 3290-10 from being left on unintentionally and minimizes battery consumption.

  • Page 110: Battery Checking

    5.12 Battery Checking 5.12 Battery Checking This function indicates remaining battery charge on the bar graph. → Press SHIFT B.CHECK Battery charge condition (0, 25, 50, 75 or 100%) is indicated for about two seconds. New battery 50% remaining charge 0% remaining charge is displayed, and three beeps sound.

  • Page 111: Battery-Low Warning

    5.13 Battery-Low Warning 5.13 Battery-Low Warning If the unit is operated with very low battery power, accuracy cannot be guaranteed. When the battery-low warning indicator ( appears, replace all batteries with new batteries. • Be aware that current measurement conditions which cause to be displayed also increase meter current consumption, O.L.

  • Page 112: Beeper

    5.14 Beeper 5.14 Beeper The beeper normally beeps once when any button is pressed. To Disable the Beeper Hold the button while pressing the button to turn the meter on. The beeper is disabled. To re-enable the beeper, press the button to turn the meter off and back on.

  • Page 113: Specifications

    6.1 Measurement Specifications Specifications 6.1 Measurement Specifications Measurement items are as follows: • DC • AC • AC+DC • Hz (Frequency) • Current Integral • Duty (Percentage) and Operating Time...

  • Page 114: Current Measurement

    6.1 Measurement Specifications 6.1.1 Current Measurement Current Ranges The meter automatically recognizes the sensor capabilities at the time of connection (maximum continuous measuring range and max- imum peak current value for the particular sensor). Range selection methods consist of auto ranging, and L and H man- ual ranges.
  • Page 115 6.1 Measurement Specifications DIsplay Accuracy ± (rdg.+dgt.) 1 to 10 Hz 10 to 45 Hz 45 to 66 Hz 66 to 1 kHz ± (0.3%+5) FAST NORMAL ± (0.3%+7) ± (0.3%+3) ± (0.3%+3) AC+DC (AC+DC only) ± (0.3%+3) ± (1.0%+3) SLOW (AC+DC only) REC Output Accuracy...

  • Page 116: Frequency Measurement

    6.1 Measurement Specifications 6.1.2 Frequency Measurement Frequency Ranges Range is selected automatically (Internal Ranges: 10.00, 100.0 and 1000 Hz) Accuracy • When input is 5% or larger of the current range ± DIsplay Accuracy (rdg.+dgt.) Maximum Range (Accuracy Range) Resolution Display 10 Hz (1.00 to 12.50 Hz) 0.01 Hz...

  • Page 117: Current Integral Measurement

    6.1 Measurement Specifications 6.1.3 Current Integral Measurement Integral Ranges Range selections are auto ranging or manual (6 ranges) See "Integral Range Table" (page 111) Measurement Calculated from current measurement values Process Measurement Same as current measurement Sampling Measurement Model 9691: 0 to ± 210.0 kAh Ranges Model 9692: 0 to ±...

  • Page 118: Duty Measurement

    6.1 Measurement Specifications 6.1.4 Duty Measurement Measurement Calculated from measured current and measurement time method Measurement Same as current measurement sampling Valid input range Determined by current measurement Function • Operating time Operating time is the amount of time during which the measured current exceeds the specified current threshold •...

  • Page 119: General Specifications

    6.2 General Specifications 6.2 General Specifications Functions Auto zero → Press the buttons to perform auto zero adjustment (in SHIFT adjustment DC and AC+DC modes). Data hold Press the button to retain the current value on the display. Filter switching →...
  • Page 120 6.2 General Specifications Display • Liquid crystal display (LCD) • Digital counter Max. 3000 counts (current) Max. 3000 counts (peak current) Max. 1250 counts (frequency) Max. 9999 counts (integration) Max. 1000 counts (duty) • Bar graph display 21 segments • Over-range is indicated by on the bar graph when a measurement O.L.
  • Page 121 6.2 General Specifications Temperature 0 to 40°C range: 0.1 x accuracy specifications/°C characteristics (32 to 104°F range: 0.18 x accuracy specifications/°F) Location for use Indoor, altitude up to 2000 m (6566 feet) Operating 0 to 40°C (32 to 104°F), 80% RH or less (no condensation) temperature and humidity range Storage temperature...

  • Page 122: Clamp On Ac/Dc Sensor Specifications

    6.3 CLAMP ON AC/DC SENSOR Specifications 6.3 CLAMP ON AC/DC SENSOR Specifications 6.3.1 Model 9691 CLAMP ON AC/DC SENSOR Rated current AC/DC 100 A Output voltage AC/DC 1 V /100 A 100 Ω or less Output resistance Maximum 100 Arms continuous (Derating according to frequency) permissible input Maximum peak 150 A...
  • Page 123 6.3 CLAMP ON AC/DC SENSOR Specifications Dimensions Approx. 53W X 129H X 18D mm (Approx. 2.09"W X 5.08"H X 0.71"D) Mass Approx. 230 g (8.1 oz.) Cable length Approx. 2 m (6.5 feet) Accessory Instruction manual............1 Applying standards Safety EN61010 Type A current sensor Measurement categories III (Anticipated Transient Overvoltage: 6000 V)

  • Page 124: Model 9692 Clamp On Ac/Dc Sensor

    6.3 CLAMP ON AC/DC SENSOR Specifications 6.3.2 Model 9692 CLAMP ON AC/DC SENSOR Rated current AC/DC 200 A Output voltage AC/DC 2 V/ 200 A 100 Ω or less Output resistance Maximum permissible 200 Arms continuous (Derating according to frequency) input Maximum peak current 300 A...
  • Page 125 6.3 CLAMP ON AC/DC SENSOR Specifications Accessory Instruction manual............1 Applying standards Safety EN61010 Type A current sensor Measurement categories III (Anticipated Transient Overvoltage: 6000 V) Pollution Degree 2 EN61326 Continuous Input Range to 66 Hz 66 to 1 kHz 0 to 200 A ±...

  • Page 126: Model 9693 Clamp On Ac/Dc Sensor

    6.3 CLAMP ON AC/DC SENSOR Specifications 6.3.3 Model 9693 CLAMP ON AC/DC SENSOR Rated current AC/DC 2000 A Output voltage AC/DC 2 V/ 2000 A 100 Ω or less Output resistance Maximum permissible 2000 Arms (Derating according to frequency) input Maximum peak current 2840 A value...
  • Page 127 6.3 CLAMP ON AC/DC SENSOR Specifications Accessory Instruction manual............1 Applying standards Safety EN61010 Type A current sensor Measurement categories III (Anticipated Transient Overvoltage: 6000 V) Pollution Degree 2 EN61326 Continuous Input Range to 66 Hz 66 to 500 Hz 0 to 1800 A ±...

  • Page 128: Combined Accuracy

    6.4 Combined Accuracy 6.4 Combined Accuracy This section shows the accuracy tables when the 3290-10 is com- bined with the 9691, 9692, or 9693, and describes the method of calculation. 6.4.1 Models 9691 + 3290-10 Combined Accuracy Display Accuracy ±...
  • Page 129 6.4 Combined Accuracy MON Output Accuracy ± (%rdg.+mV) 1 to 10 Hz 10 to 66 Hz 66 to 500 Hz AC+DC 1.3%+10 mV 2.3%+10 mV to 80 A 2.3%+5.5 mV AC+DC 1.3%+5.5 mV 80 to 100 A 2.8%+5.5 mV to 80 A 2.3%+5.5 mV 80 to 100 A 2.8%+5.5 mV...

  • Page 130: Model 9692 + 3290-10 Combined Accuracy

    6.4 Combined Accuracy 6.4.2 Model 9692 + 3290-10 Combined Accuracy Display Accuracy ± (%rdg.+A) 1 to 10 Hz 10 to 66 Hz 66 to 1 kHz 1.3%+0.10 A AC+DC 1.3%+0.12 A 2.0%+0.08 A 1.3%+0.08 A 2.3%+0.08 A 1.3%+0.5 A AC+DC 1.3%+0.7 A...

  • Page 131: Model 9693 + 3290-10 Combined Accuracy

    6.4 Combined Accuracy 6.4.3 Model 9693 + 3290-10 Combined Accuracy Display Accuracy ± (%rdg.+A) 1 to 10 Hz 10 to 45 Hz 45 to 66 Hz 66 to 1 kHz 1.8%+1.0 A AC+DC 1.8%+1.2 A 3.0%+0.8 A 2.3%+0.8 A 1.3%+0.8 A 2.3%+0.8 A...

  • Page 132: Method Of Calculation

    True value when 160.0 A is shown: 157.5 A to 162.3 A *1 See the accuracy at 10 to 66 Hz in AC mode for H range in the 9692+3290-10 combined display accuracy table on page 124. *2 rdg. error = 160 A x 1.3% Total error when REC output is 1.2 V (60 Hz) (for L range)

  • Page 133: Maintenance And Service

    7.1 Cleaning Maintenance and Service • Calibration and repair of this meter should be performed only under the supervision of qualified technicians knowledgeable about the dangers involved. • If the protective functions of the meter are damaged, either remove it from service or mark it clearly so that others do not use it inadvertently.

  • Page 134: Repair And Servicing

    • If damage is suspected, check the "Troubleshooting" section before contacting your dealer or Hioki representative. • If uncertain whether the problem can be attributed to the 3290-10 or clamp sensor, request that both be repaired. • The minimum stocking period for replacement parts is five years after end of production.

  • Page 135: Troubleshooting

    7.2 Repair and Servicing Troubleshooting If problems are encountered with operation, check the appropriate items below. Symptom Items to Check • Meter does not turn When using AC adapter • Is the AC adapter plug securely inserted into the jack, and the •...
  • Page 136 7.2 Repair and Servicing Symptom Items to Check • Display does not • Occurs after switching to peak measurement or changing range? return to zero Always press button to clear data after switching to peak measurement or changing range. See "Starting Measurement" (page 65) •...
  • Page 137 • Is the frequency of the measured current out of the specified seem too low range of either the 3290-10 or clamp-on sensor? If the carrier frequency of an inverter is high, the displayed value may be smaller than the total rms value.
  • Page 138 7.2 Repair and Servicing Symptom Items to Check • Displayed values Current Measurement seem too high • Are the tips of the clamp-on sensor in good condition? • Is the range correct? • Has auto zero adjustment been performed correctly in DC and AC+DC modes? If the displayed value is positive, measurement values will be high.
  • Page 139 • Does the selected display update rate (measurement response time) suit the frequency of the current to be measured? See Section 5.3 "Measurement Response Time" (page 92) • The 3290-10 turns • Data may be stored by the Data Save function. Use the Data off and data cannot Recall function to view saved data.
  • Page 140 Contents Solution E.001 ROM Checksum Error in the one- chip internal microcontroller A component requires replace- E.002 RAM R/W Error in the one-chip ment. Contact your dealer or internal microcontroller Hioki representative. E.003 EEPROM Checksum Error E.004 EEPROM Data Error...

  • Page 141: Appendix

    The graph below shows frequency characteristic differences among standard equipment, that with a 10 m extension cable, and that with a 100 m extension cable. Model 9691 + extension cable + Model 3290-10 MON output frequency characteristics 1000 10000 100000 入力周波数...
  • Page 142 Model 9692 + extension cable + Model 3290-10 MON output frequency characteristics 1000 10000 100000 入力周波数 (Hz) Frequency (Hz) Standard 10 m 100 m Model 9693 + extension cable + Model 3290-10 MON output frequency characteristics 1000 10000 100000 入力周波数 (Hz)

  • Page 143: Carrying Case

    Carrying Case The optional 9400 CARRYING CASE is used to house the instru- ments described below. • Model 3290-10 CLAMP ON AC/DC HiTESTER......1 • Model 9691 CLAMP ON AC/DC SENSOR .......1 • Model 9692 CLAMP ON AC/DC SENSOR .......1 • Model 9693 CLAMP ON AC/DC SENSOR ......1 •...
  • Page 144 Open the carrying case cover. Fold the cover under the case. Remove the top cover from the meter. Connect the clamp-on sensor to the meter. Model 3290-10 Carrying Case Cover Sensor Cable Close the carrying case cover. Carrying Case Cover Top Cover Start measuring.

  • Page 145: Differences Between Models 3290 And 3290-10

    Current Measure- Measurement ment response time set- 0.2, 0.8 and 8 s (linked to display update rate in the 3290-10) ting AC filter function In AC and AC+DC modes, fc = 550 Hz settable on/off MON output of DC: MON output of DC and AC+DC:...
  • Page 146 HiTester Model 3290-10 3290 Data Hold function Suspends display update Button Lock function Settable by button operation Bar Graph display Indicates data memory number Range magnification function DC: Once/ s (fixed) AC and AC+DC: NORMAL Twice/s Display update switching NORMAL...
