Summary of Contents for Stahl 8118
- Page 1 Operating Instructions Terminal box > 8118...
-
Page 2: Table Of Contents
Repairs and Maintenance ..................7 Accessories and spare parts .................7 Disposal .........................7 Type examination certificate (Page 1) ..............8 Declaration of conformity ..................9 General Information 2.1 Manufacturer R. STAHL Schaltgeräte GmbH Am Bahnhof 30 D-74638 Waldenburg Telephone: +49 7942 943-0 Fax: +49 7942 943-4333 Internet: www.stahl.de... -
Page 3: Safety Instructions
EN/IEC 60079-0, EN/IEC 60079-7, EN/IEC 60079-11, EN/IEC 60079-18, EN/IEC 61241-0, EN/IEC 61241-1 Device type 8118 is suitable for use in hazardous areas, zones 1, 2 and zones 21, 22. Function The polyester resin terminal boxes are used for the transfer and distribution of electrical energy. -
Page 4: Technical Data
Maximum number of cables related to conductor cross-section and number of terminals under load for temperature class T6 when ( 40 °C or T5 when T ( 55 °C: Types 8118/112 and 8118/114 Rated operating cur- max. number of cables *... - Page 5 10 A 10 (of 16) 63 % 2.5 mm 16 A 4 (of 12) 33 % 96 % < 100 % Installing fuses (8118/1.3 and 8118/1.4) Fuse-base Temperature class Max. permissible surface temperature ( 2 A 40 °C T80 °C >...
-
Page 6: Fitting
M 20 M 25 M 32 Pg 11 Pg 13,5 04466E00 04467E00 04468E00 8118/.1. 8118/.2. 8118/.3. Additional dimensions for Terminal box Terminal box Terminal box cable entries 8161 When explosion-protected equipment is exposed to the weather, it is advisable to provide a protective cover or wall. -
Page 7: Repairs And Maintenance
The device may only be cleaned with a damp cloth! 11 Accessories and spare parts WARNING Use only original spare parts as well as original accessories made by R. STAHL Schaltgeräte GmbH. WARNING The fuses fitted may only be replaced by fuses with matching characteristics. Any infringements can change the temperature class of the whole box. -
Page 8: Type Examination Certificate
Equipment and Protective Systems Intended for Use in Potentially Explosive Atmospheres - Directive 94/9/EC EC Type Examination Certificate Number PTB 99 ATEX 3103 Equipment: Junction and Terminal Boxes Type 8118/...-... Manufacturer: R. Stahl Schaltgeräte GmbH Address: Bergstraße 2, D-74653 Künzelsau This equipment and any acceptable variation thereto are specified in the schedule to this certificate. -
Page 9: Declaration Of Conformity
Declaration of conformity 14 Declaration of conformity 8118609300 Terminal box S-BA-8118-02-en-15/06/2007 8118... - Page 12 8118609300 S-BA-8118-02-en-15/06/2007...
