Clarke C2K-16 Operator's Manual
C2k series 230v 50hz polisher
Hide thumbs
Also See for C2K-16:
- Operator's manual (42 pages) ,
- Operator's manual (88 pages) ,
- Operator's manual (89 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
Operator's Manual
C2K Series
Operator's
230V 50Hz
Manual
Polisher
UK
READ THIS BOOK
CAUTION: Read the Operator's Manual before using the appliance.
This book has important information for the use and safe operation of this machine. Failure to read
this book prior to operating or attempting any service or maintenance procedure to your ALTO
machine could result in injury to you or to other personnel; damage to the machine or to other property
could occur as well. You must have training in the operation of this machine before using it. If your
operator cannot read English, have this manual explained fully before attempting to operate this
machine.
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books write to: ALTO U. S. Inc., 2100 Highway 265, Springdale, Arkansas 72764.
Form No. 70199A 1/02
CLARKE TECHNOLOGY
Printed in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Clarke C2K-16
Summary of Contents for Clarke C2K-16
- Page 1 All directions given in this book are as seen from the operator’s position at the rear of the machine. For new books write to: ALTO U. S. Inc., 2100 Highway 265, Springdale, Arkansas 72764. Form No. 70199A 1/02 CLARKE TECHNOLOGY Printed in the U.S.A.
-
Page 2: Table Of Contents
Motor Assembly Drawing & Parts List ................20 Gearbox Assembly Drawing & Parts List ................. 21 Motor Assembly Drawing and Parts List ................22 Gearbox Assembly Drawing and Parts List ..............23 Wiring Diagrams ......................24 Page -2 - CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V... -
Page 3: Operator Safety Instructions
Read all machine labels before attempting to operate. Make sure all of the labels and instructional information are attached or fastened to the machine. Get replacement labels and decals from your authorized distributor. CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V Page - 3 -... -
Page 4: Machine Introduction
This appliance is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops, offices and rental businesses. Page -4 - CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V... -
Page 5: Accessories
WARNING: Use only brushes and accessories supplied by the manufacturer. The use of other brushes and accessories may impair safety. Large diameter brushes provided specifically for dry buffing are not intended for general polishing. CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V Page - 5 -... -
Page 6: Machine Specifications
Brush Diameter (cm) Block Diameter (cm) Brush Speed (rpm) 180/320 180/320 Cord Length (m) Weight (kg) Noise (dBA) <70 <70 <70 <70 <70 Vibration (m/s <2.5 <2.5 <2.5 <2.5 <2.5 Page -6 - CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V... -
Page 7: How To Prepare The Machine For Operation
NOTE: For the best operating position, keep your back straight, bend only your arms. 3. Using your foot, push the locking lever down. 4. Hold the handle against your body for the best control. CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V Page - 7 -... - Page 8 If the receptacle or connector body does not fit the plug, see your Authorized person to make the connection. Page -8 - CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V...
-
Page 9: How To Operate The Machine
MAINTENANCE WARNING: Maintenance must be done by authorized personnel only. Maintenance Instructions Return the machine to a Clarke Technology Authorized Service Location every 12 months for maintenance inspections. CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V Page - 9 -... - Page 10 NOTES Page -10 - CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V...
-
Page 11: Section Ii Parts And Service Manual
C2K Series 230V Section II Parts and Service Manual (70199A) CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V Page - 11 -... -
Page 12: Maintenance
Return the machine to the nearest Clarke Technology Service Branch or Clarke Technology Authorized Service Center. For safe operation, and longer life to your Clarke Tech- nology product, use only Clarke Technology parts. NOTE: The grease (503802) for the gear box needs to be changed every year. - Page 13 NOTES CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V Page - 13 -...
-
Page 14: Assembly Drawing 2/01
CLARKE TECHNOLOGY C2K-16, C2K-18, C2K-160, C2K-180, C2K-200, C2K-1600, C2K-1800, C2K-2000, C2K-160HS, C2K-180HS, C2K-200HS Assembly Drawing 2/01 23 1 Page -14 - CLARKE TECHNOLOGY Operator's Manual - C2K Series... - Page 15 50784A Bumper, (200, 2000) 80098A Screw, -18 x 2 50796A Bushing, Cord 50795A Tube, Handle 50870A Cord Assembly 441401 Cam Assembly (includes 14,15, 16) 747553 Strain Relief 77378A Label 82100A Locknut CLARKE TECHNOLOGY Operator's Manual - C2K Series Page - 15 -...
- Page 16 CLARKE TECHNOLOGY C2K-1600DS and C2K-2000DS Assembly Drawing 2/01 21 22 23 1 Page -16 - CLARKE TECHNOLOGY Operator's Manual - C2K Series...
-
Page 17: Assembly Parts List 2/01
Label, (High - Low) 77378A Label 441401 Cam Asm (includes 14,15,16) 30605A Baffle 50870A Cord Asm. (w/ strain Relief) 47201A Filter 98458A Bushing 962957 Screw 82100A Locknut 51058A Baffle CLARKE TECHNOLOGY Operator's Manual - C2K Series Page - 17 -... -
Page 18: Motor Assembly Drawing & Parts List
CLARKE TECHNOLOGY C2K-16, C2K-18, C2K-160, C2K-180 and C2K-200 230V - 50 Hz Motor Assembly Drawing & Parts List 2/01 Note: If your machine has motor #44638A refer to this drawing for service part replacement. Ref. Part No. Description Qty. Ref. -
Page 19: Gearbox Assembly Drawing & Parts List
CLARKE TECHNOLOGY C2K-16, C2K-18, C2K-160, C2K-180 and C2K-200 Gearbox Assembly Drawing & Parts List 1/02 Note: If your machine has gearbox #50872A refer to this drawing for service part replacement. Ref. Part No. Description Qty. 80141A Screw, Socket Hd. Cap... -
Page 20: Motor Assembly Drawing & Parts List 1/02
"HS" machines 50880A 50879A Ref. Part No. Part No. Description 50861A 50861A Ball Bearing 40153A 51054A Centrifugal and Switch 40154A 51055A Rotor 40155A 50862A Capacitor, Start 40156A 50863A Capacitor, Run Page -20 - CLARKE TECHNOLOGY Operator's Manual - C2K Series... -
Page 21: Gearbox Assembly Drawing & Parts List 1/02
962794 Screw 10-24" x 1" 54858A Cover, Housing 902736 Bearing 58314A Retainer 442473 Coupling Gear, Pinion 902737 Bearing, Needle Cage Gear, Idler 58312A Shaft 902573 Bearing, Ball Housing, Drive CLARKE TECHNOLOGY Operator's Manual - C2K Series Page - 21 -... -
Page 22: Motor Assembly Drawing & Parts List
Armature Asm. (Includes #12) 58056A Strain Relief 831102 Bushing 55648A Red Lead (included w/#8) 980076 Wave Washer 55647A Yellow Lead (included w/#8) 59607A Varistor (Included w/#8) 46736A Speed Control 51343A Gearbox Page -22 - CLARKE TECHNOLOGY Operator's Manual - C2K Series... -
Page 23: Gearbox Assembly Drawing & Parts List 1/02
962794 Screw 10-24" x 1" 54858A Cover, Housing 902736 Bearing 58314A Retainer 442473 Coupling Gear, Pinion 902737 Bearing, Needle Cage Gear, Idler 58312A Shaft 902573 Bearing, Ball Housing, Drive CLARKE TECHNOLOGY Operator's Manual - C2K Series Page - 23 -... -
Page 24: Wiring Diagrams
Wiring Diagram 230V - 50Hz 3/00 CLARKE TECHNOLOGY C2K-1600DS and C2K-2000DS Wiring Diagram 230V 3/00 CLARKE TECHNOLOGY C2K-1800HSV Wiring Diagram 230V 2/01 WARNING: All electrical repairs must be performed by qualified personnel only. Page -24 - CLARKE TECHNOLOGY Operator's Manual - C2K Series... - Page 25 1355 West Oak Common Lane Stuartweg 4C (770) 973-5225 NL-4131 NJ Vianen +31 347 324000 ALTO Sverige AB, Molndal (Sweden) CLARKE TECHNOLOGY Aminogatan 18 AMERICAN SANDERS TECHNOLOGY Box 4029 A.L. COOK TECHNOLOGY S-431 04 Molndal Customer Service Headquarters and Factory...
- Page 26 WARRANTIES, INCLUDING BUT NOT LIMITED TO WARRANTY OF MERCHANTABILITY, SHALL BE IMPLIED. A warranty registration card is provided with your Clarke Technology floor machine. Return the card to assist Clarke Technology in providing the performance you expect from your new floor machine.
