Compressor

Choose an appropriate compressor for your Eclipse airbrush. The
Iwata Smart Jet Compressor is a good beginner choice and will
provide approximately 20-25 psi of air pressure to the Eclipse. The
high-powered Iwata Power Jet, Power Jet Lite and Power Jet Pro
compressors can provide up to 50 psi to the Eclipse. At 35 psi, the
ideal air pressure to utilize all of the airbrush's unique potential, the
Eclipse's versatility provides high-paint flow for background spray as
well as for controllable fine line detail performance. This unmatched
versatility is a unique feature of the Iwata Eclipse airbrush series.
(BCS)
1. Screw the air hose onto the compressor.
2. Screw the air hose onto the airbrush.
3. If using a Power Jet, Power Jet Lite or Power Jet Pro
compressor, adjust the pressure to between 30 and 45 psi.
4. Check for any air leaks in the compressor and air hoses.
5. Fill the bottle with Medea Airbrush Cleaner, or the appropriate
solvent for your paint.
6. Attach the bottle to the airbrush by pushing the bottle stem
into the bottle joint of the airbrush body.
GETTING STARTED HP-BCS, SBS, CS, BS
7. Point the airbrush away from you.
8. Press down on the main lever (#12) to start the flow of air
9. Pull back on the main lever to open the nozzle of the airbrush.
10. Spray cleaning solution through the airbrush to rinse out any
(BS, CS, SBS)
1. Screw the air hose onto the compressor.
2. Screw the air hose onto the airbrush.
3. If using a Power Jet, Power Jet Lite or Power Jet Pro
4. Check for any air leaks in the compressor or air hoses.
5. Place a few drops of cleaner into the bowl.
6. Point the airbrush away from you.
7. Press down on the main lever (#12) to start the flow of air
8. Pull back on the main lever to open the nozzle of the airbrush.
9. Spray cleaning solution through the airbrush to rinse out any
through the airbrush.
residual pre-testing pigment.
compressor, adjust the pressure to between 30 and 45 psi.
through the airbrush.
residual pre-testing pigment.
