Operating Instruction Manual
Offering total control for fine detail spraying, Iwata's Hi-Line and High Performance Plus Series airbrushes are designed
around the legendary Iwata HP Series which established the Iwata name in the creative community over 50 years ago.
The Hi-Line Series, with its Micro Air Control Valve, enables incremental control of airflow for a fine to medium spray
and creating stipple effects.
