Congratulations on purchasing
your new Hunter® ceiling fan! It will
provide comfort and performance
in your home or office for many
years. This installation and operation
manual contains complete
instructions for installing and
operating your fan.
We are proud of our work and
appreciate the opportunity to
supply you with the best ceiling fan
available anywhere in the world.
To register your fan, please visit:
www.HunterFan.com/register
Save your receipt for proof of purchase.
Blades
13
What to Expect with
Your Installation
7 feet
Preparation
Remote Control
& Cradle
Light Kit
14
M3630-01 • 06/06/17 • © 2017 Hunter Fan Company
Tools Needed
30 inches
2
Ladder
3
Downrod
6
7
Maintenance
& Cleaning
17
19
1
www.HunterFan.com
Mounting Options
Ceiling Bracket
4
Wiring
Canopy
10
Troubleshooting
?
?
20
1.888.830.1326
5
12
?
21
Advertisement
Table of Contents
Related Manuals for Hunter M3630-01
Summary of Contents for Hunter M3630-01
- Page 1 To register your fan, please visit: www.HunterFan.com/register Save your receipt for proof of purchase. Remote Control Maintenance & Cradle Blades Light Kit & Cleaning Troubleshooting M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
-
Page 2: What To Expect With Your Installation
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company... -
Page 3: Tools Needed
The symbols can be used to identify the appropriate hardware for each step. Power Drill 9/64” Drill Bit Screwdrivers (optional) (optional) If mounting to a support structure, you will also need these tools. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company... -
Page 4: Mounting Options
You need BOTH You need ONLY a Longer a Longer Downrod & Downrod an Angled Mounting Kit *most common M3630-01 • 06/06/17 • © 2017 Hunter Fan Company... -
Page 5: Ceiling Bracket
To avoid possible electrical shock, before installing your fan, disconnect the power by turning off the circuit breakers to the outlet Refer to warning w.1 on pg. 2 box associated with the wall switch location. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company... - Page 6 Save the screws. They will be next couple of steps. needed for blade iron installation. Note: Some fans will have a shipping ring instead of shipping blocks. Please remove the ring and save the screws. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
- Page 7 Steps 1-5 to remove standard downrod pipe Longer Downrod for angled ceilings or ceilings 10’ or higher Shorter Downrod for fans installed close to ceiling Steps 6-10 to reassemble with new pipe M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
- Page 8 4-5 full turns) until it stops. with pliers. DO NOT can be inserted. from the top of the downrod. HAND TIGHTEN. 8” 3/8” If the setscrew is not tightened securely, the fan may fall. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
- Page 9 Put the wires and downrod through the canopy. Let the canopy sit loosely on top CANOPY OR WIRES. Place the downrod of the fan. ball into the slot in the ceiling bracket. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
- Page 10 Spread the wires apart, with the grounded wires on one side of Refer to CAUTION c.1 on pg. 2 the outlet box and the ungrounded wires on the other side of the outlet box. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
- Page 11 Spread the wires apart, with the grounded wires on one side of Refer to CAUTION c.1 on pg. 2 the outlet box and the ungrounded wires on the other side of the outlet box. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
- Page 12 Lift the canopy into place so that Insert the two canopy screws lifted into place, the canopy fits into the screw holes are aligned. found in the hardware bag. the hanging bracket as shown. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
- Page 13 M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
-
Page 14: Light Fixture
Make sure to line up the colored fixture in order to successfully markings on the connectors and that the mount the light fixture to the fan. connectors are latched together. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company... - Page 15 Make sure the fixture is securely attached to the mounting plate. Failure to engage the locking pin could result in the assembly falling. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
- Page 16 Raise the shades the sockets. When necessary, See next page for fan to the light fixture. Tighten all replace with bulbs of the same operation instructions. thumbscrews securely. type and wattage. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
-
Page 17: Remote Control
If three beeps sound, the remote was unpaired. Re-pair using the steps above. To prevent faulty operation, please disconnect power from all other ceiling fans within range while pairing. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company... - Page 18 Install the cradle bracket to the wall with bracket per the instructions firmly for 30 seconds. the included screws. on the adhesive sticker. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
- Page 19 Press and quickly release the light button on the remote control to turn the light OFF or ON. Press For questions regarding removing a light kit, call and hold the light button for continuous dim. customer service 1-888-830-1326. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
-
Page 20: Download The App
Need to install the app later? SIMPLEconnect connects to available 2.4 GHZ WiFi networks. When ready, turn the wall switch off and then on. Wait three minutes before downloading the app. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company... -
Page 21: Troubleshooting
“How do I properly install U.S. and other countries. HomeKit is a trademark of Apple Inc. held at close range multiple remote-controlled fans?” • Change battery. for information on how to correct this issue. M3630-01 • 06/06/17 • © 2017 Hunter Fan Company...
