SonicWALL SonicPoint - Model APL13-02C
FCC Part 15 Class A Notice
NOTE: This equipment was tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy. And if
not installed and used in accordance with the instruction manual, the device may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user is required to correct the interference at
his own expense.
Complies with EN 55022 Class A and CISPR22 Class A.
*Refer to the label on the bottom of the unit for device information including Class A or Class
B FCC information.
Caution: Modifying this equipment or using this equipment for purposes not shown in this
manual without the written consent of SonicWALL, Inc. could void the user's authority to
operate this equipment.
BSMI Statement
VCCI Statement
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SonicWALL APL13-02C
Summary of Contents for SonicWALL APL13-02C
- Page 1 *Refer to the label on the bottom of the unit for device information including Class A or Class B FCC information. Caution: Modifying this equipment or using this equipment for purposes not shown in this manual without the written consent of SonicWALL, Inc. could void the user’s authority to operate this equipment. BSMI Statement...
-
Page 2: Canadian Radio Frequency Emissions Statement
(7.9 inches) between the radiator (antenna) and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. For more information regarding the above statement, please contact SonicWALL, Inc. at 1143 Borregas Avenue, Sunnyvale, CA 94089-1306 or 1-408-745-9600. Cable Connections All Ethernet and RS232 (Console) cables are designed for intra-building connection to other equipment. - Page 3 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 5 Wall Mounting the SonicWALL SonicPoint Follow the instructions below to mount the SonicPoint on the wall. 1. Using the mounting plate as a template, mark the places to insert the mounting anchors. 2. Using a #2 Phillips screw driver, press the tip of the anchor into the marked places on the hollow wall.
- Page 6 6. Slide the plate down to the narrowest part of the keyhole so that the mounting plate rests on the screws. 7. Tighten the mounting screws to secure the mounting plate. 8. Snap the SonicPoint onto the mounting plate. Page 4...
- Page 7 Mounting the SonicWALL SonicPoint on the Ceiling 1. Locate a metal support to hang the SonicPoint. 2. Using the mounting plate as a template, mark the places to insert the mounting anchors. 3. Drill two holes for #6 x 1-1/4” screws in the marked location.
- Page 8 8. Snap the SonicPoint onto the mounting plate. Other Considerations for Mounting the SonicWALL SonicPoint • Mount in a location away from direct sunlight and sources of heat. A maximum ambient temperature of 104º F (40º C) is recommended. •...
- Page 9 SonicWALL, Inc. 1143 Borregas Drive Sunnyvale, CA 94089 Tel: (408) 745-9600 Fax: (408) 745-9300 P/N 232-000512-00 E-mail: info@sonicwall.com Rev A. 04/04 Web: www.sonicwall.com Page 7...
