RUM-FEC

Parameter
Frequency range
Operation modes
Modulation
Symbol rate
Receiver settings
Input format(s)
Additional Info
RUM-FEC operates at symbol rates of 164.5 and 218.3 Bd on the radio link.
The HNG-FEC and RUM-FEC modes are technically very similar. RUM-FEC alphabet has a codeword length
of 16 bits where each of the 32 used bit combinations corresponds to an ITA-2 character.
The RUM-FEC alphabet is designed to obtain a maximum Hamming distance for error detection and has
deep interleaving. The actual ITA-2 alphabet is not contained in the code table. As in HNG-FEC error cor-
rection is performed by table look-up of the bit pattern (character) closest resembling the character in er-
ror.
RUM-FEC has a bit interleaving of 128 bits, each new character starting at intervals of 16 bits. The soft-
ware synchronizes to traffic as well as idle bit patterns.
Error correction may be enabled or disabled using the ECC item in the Options menu.
In RUM-FEC mode the signal polarity (sideband) can be manually selected by toggling the Polarity item in
the Demodulator menu. If polarity changes during a transmission, synchronization will not be lost.
