Summary of Contents for Regency Liberty L965E

Page 1 Owners & Gas Fireplace Installation Manual Liberty® L965E Horizon® HZ965E www.regency-fire.com MODELS: L965E-NG 10 L965E-LP 10 HZ965E-NG 10 HZ965E-LP 10 WARNING: FOR YOUR SAFETY If the information in these instructions are not followed exactly, What to do if you smell gas:...
Page 2 FOR SAFE INSTALLATION AND OPERATION OF YOUR “Regency” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • To prevent injury, if the pilot or pilot and burners • All Regency gas-fired appliances must be installed in accordance with their instructions. Carefully read all have gone out on their own, open the glass door and the instructions in this manual first. Consult the building...
Page 3: Table Of Contents
Appendix A - Optional Reduced Ceiling Height Installation .....65 Door Removal and Installation: ...............40 Parts List ....................67 Gas Hook-Up: ..................41 Electrical Hook-Up: .................41 LP Gas Conversion: ................42 Glass Burner Removal/installation: ............45 Glass Crystal / stones installation : ............46 Optional Spa Stones Installation (around burner) ........46 Reflective panel installation / Removal: ..........47 Liberty Gas Horizon Gas Inserts Benefits Inserts Benefits Liberty L965E Horizon HZ965E HZ965/L965 Gas Fireplace |...
Page 4 VENTED GAS FIREPLACE HEATER standards in CANADA and the USA as follows: VENTED GAS FIREPLACE HEATER (L965E/HZ965E; NG/LPG) TESTED TO: ANSI Z21.88-2014/CSA 2.33-2014 VENTED GAS FIREPLACE HEATERS CAN/CGA 2.17-M91 GAS FIRED APPLIANCES FOR HIGH ALTITUDES CSA P.4.1-02 TESTING METHOD FOR MEASURING ANNUAL FIREPLACE EFFICIENCY This Regency L965E/HZ965E Fireplace: • Has been certified for use with either natural or propane gases. (See rating label.) • Is not for use with solid fuels. • I s approved for bedroom or bed sitting room. (IN CANADA: must be installed with a listed wall thermostat. IN USA: see current ANSI Z223.1 for installation instructions.) • M ust be installed in accordance with local codes. If none exist, use current installation code CAN/ CSA-B149.1 Natural Gas and Propane Installation Code (Canada in Canada or ANSI Z223.1/NFPA...
Page 5: Dimensions
dimensions DIMENSIONS: 5-1/4" 5-1/4" (133mm) (133mm) 18-3/4" 18-3/4" (476mm) (476mm) 52-5/16" 52-5/16" (1329mm) (1329mm) Figure 1. Dimensions of the Firebox. RATING LABEL LOCATION: The Rating and Lighting instruction label is located below the door frame, underneath the firebox attached to a chain. To access the label, slide the plate forward out from under the firebox. Always return it when finished. ELECTRICAL HOOK-UP: An electrical junction box is provided and fastened to the right side of the fireplace. Power needs to be brought to the electrical junction box. The power for the various control components are all provided from the fan control module. Install the provided electric outlet and cover and plug the the fan control module into it. See the Rating Label for the listed electrical requirements. When installed, the L965E/HZ965E, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1. See Page 39. Figure 2. Rating/Lighting Label Location. HZ965/L965 Gas Fireplace |...
Page 6: Copy Of The Safety Label
safety decal COPY OF THE SAFETY LABEL 919-087 DO NOT REMOVE THIS LABEL / N'ENLEVEZ PAS CETTE ETIQUETTE Manufactured in Canada for / Fabriqué dans le Canada pour: FPI Fireplace Products International Ltd. Delta, BC, Canada VENTED GAS FIREPLACE HEATER ENVIRO MODEL: HZ965E L965E FOYER AU GAZ A EVACUATION MODELE ENVIRO:...
Page 7: Planning Your Installation
installation PLANNING YOUR INSTALLATION INTRODUCTION: This section of the technical manual is for the use of qualified technicians only. Fireplace placement, hearths, facings, mantles, and venting terminations will be covered, as well as the gas and electric systems. There are several installation safety guidelines that must be adhered to. Please carefully read the safety precautions at the front of this manual. Warning: Clearances must be sufficient to allow access for maintenance and service. If installing a Power Vent Kit (706-922) or a Heat Distribution Kit (706-921), refer to the instructions included with the kits to aid in your planning. NON-COMBUSTIBLE MATERIAL ZONE: This installation guide will show you many options for installing your new L965E/HZ965E Some options include external chases, internal chases, rock facing and corner installations. No matter what direction your installation takes, this illustration shows an area where no combustible building products may go. This illustration applies to any and all installations for the L965E /HZ965E and should be used as the first reference before any others. Failure to comply with this requirement can lead to elevated operating temperatures, degradation of materials or even result in fire. If you are unclear about any details contained here, consult with your retailer prior to installation. 24" (610mm) 11" (279mm) 27-3/4" (705mm) **52-5/16" (1329mm) Figure 4. Non-Combustible Material Zone. When Installing a TV above the unit. ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS.
Page 8: Framing
installation FRAMING: Figure 5. Typical Framing for Internal Chase - General. INTERNAL CHASE: NOTE: Framing chase depth is 26-1/2” when using the heat distribution kit. 24" (610mm) Internal ceiling clearance is 90” Min. Chase Depth when using the heat distribution kit. 44-3/4" (1137mm) Minimum 52-5/16" (1329mm) Minimum 63" 52-5/16" (1600mm) (1329mm) to centerline To Header...
Page 9: External Chase
installation EXTERNAL CHASE: Non-Combustible Facing and Hearth Protector Dimensions: Facing (supplied) 1 Top = 46” x 19” 2 Sides = 32-15/16 x 4-9/16” Hearth Protector (supplied) 46” x 12” NOTE: N o hearth is required if the unit is raised a minimum of 18” off the floor. Hearth Protector Figure 7. Typical Framing for External Chase - General. 24" (610mm) Min. Chase Depth 44-3/4" (1137mm) Minimum 63" (1600mm) 52-5/16" to centerline (1329mm) To Header...
Page 10: Corner Framing
installation CORNER FRAMING: Figure 9. Typical Framing for Corner - General. 64” (1626mm) 44-3/4" (1137mm) Minimum 2-5/16"(1329mm) Minimum to Header/Shelf Height from Base of Unit Figure 10. Typical Framing for Corner - Detailed. 10 | HZ965/L965 Gas Fireplace...
Page 11: Framing For Sidewalls And Mantel
installation FRAMING FOR SIDEWALLS AND MANTEL: The mantel’s maximum overhang is 10” (254mm) at the minimum height of 52¼” (1327mm) measured from the base of the fireplace. The mantel can extend 1” (25.4mm) further for every 1” (25.4mm) of height it is installed over the minimum height, as shown in Figure 12. Non-combustible mantels and mantel legs are not limited to these dimensions. Mantel temperatures are monitored during testing and can reach 117°F (47°C) above room temperatures. Make sure the finish on your mantel is suitable for temperatures of this range.
Page 12: Typical Framing - Raised Hearth
installation TYPICAL FRAMING - RAISED HEARTH: Warning: Failure to follow these guidelines may result in elevated operating temperatures, an inability to remove or install the door. A non-combustible Hearth Insulation Board is required to be installed between any non-combustible hearth covering and any combustible floor- ing beneath. The design of the unit is such that the fireplace must be raised by the same distance as any additional hearth covering or riser that are added in front of the fireplace. Figure 14 shows a raised hearth made of a wooden construction hearth riser (B), covered with the insu- lation board provided and then covered with non- combustible slate (A). The thickness of the riser (B) is 4” (102mm). The thickness of the slate (A) is 2” (52mm). A+B=C which is 6” (152mm). In summary, the fireplace must be raised by the same thickness of any material added in front of the fireplace. If the raised hearth is deeper or wider than the Insulation Board provided with the unit, additional non-combustible materials such as Backer Board...
Page 13: Installation Of Fireplace Facing
installation INSTALLATION OF FIREPLACE FACING: Non-Combustible Fireplace Door Facing (Supplied) Non-Combustible Board (Supplied) ” (13mm) Mantel ” (13mm) ” (16mm) Minimum Air Gap Standard Wall Board Tile or other non-combustible facing including grout or cement Stone Facing Optional Fronts Figure 17. Option 1 - Fireplace Facing Less Than 1”...
Page 14: Receiver Installation
installation RECEIVER INSTALLATION Electrical Box (Supplied) Wall Stud Receiver Cover Receiver Figure 22. Receiver Installation. The Receiver is the heart of the remote control system. You need to access this receiver after installation to change the batteries (for operation during a power failure), to program a new remote / receiver combination and to operate a manual override should you lose your remote control or the batteries in the remote control lose their power. The Receiver is connected to the fireplace with a wire harness that has a maximum length of 8 ft (2.4m). The connection point on the fireplace is on the right side of the unit, where the gas valve and electronic ignition module is located. Because of the 8 ft (2.4m) limitation in the wiring harness, the receiver needs to be mounted to the right side of the fireplace. An electrical box is provided for the receiver. Mount this electrical box as you would any electrical outlet or switch box. Thread the cable and connector through the back of the electrical box and connect it to the rear of the receiver. Secure the receiver into the electrical box. Once the facing of the fireplace installation is complete, install the receiver cover, supplied with the unit as shown. The receiver cover also functions as a switch plate and allows for access to the program button, critical for remote control operation. Review the section in this manual regarding the remote control operations for more information on the functions of the receiver. 14 | HZ965/L965 Gas Fireplace...
Page 15: Allowable Vent Configurations
installation ALLOWABLE VENT CONFIGURATIONS: The vent chart, in Figure 23, illustrates the vent configurations that have been tested and approved for use with this appliance. 45˚ elbows are acceptable for this installation and may be used instead of 90˚ elbows. You may use two (2) 45˚ elbows for every 90˚ elbow shown in this chart. This appliance is also approved for use with 5” x 8” flex venting. Only use flexible venting that is approved for this appliance. Flex vent runs must comply with the same limitations as the rigid vent chart shown here. Flexible vent runs greater than 10’ total are not permitted. When using the flexible vent system, part # 946-601 5” x 8” flex pipe adaptor must be used to adapt from rigid venting to flex venting. This must be attached to the appliance prior to attaching flex venting. The restrictor settings shown in Figure 23, are recommended. Installation factors such as altitude, prevailing weather conditions such as temperature or wind, or the number of elbows used may affect your final restrictor settings. Insufficient restriction may cause pilot outages or reduced efficiencies. Too much restriction may lead to elevated operating temperatures, poor flame appearances, sooting or carbon deposits building up on burner effects or window glass. Only use the restrictors supplied with this appliance. Table 1: Vent Restrictor Sizes. Ø of Flue Restriction Restrictor * Horizontal Vent Sections rise ”/ft (21mm/m) * 3.878” 40’ (12.19m) (98.5mm) 3.540” (89.9mm) 35’ (10.67m) 3.166” (80.4mm) 30’...
Page 16: Vent Termination Restrictions
installation VENT TERMINATION RESTRICTIONS: NOT FOR POWER VENT SYSTEM - IF USING POWER VENT - SEE POWER VENT SECTION Fixed Closed Fixed Openable Closed Openable Termination Cap Air Supply Inlet Gas Meter Restriction Zone (Termination not allowed) Figure 24. Vent Termination Restrictions, refer to Table 2. Table 2: Vent termination clearances, refer to Figure 24.
Page 17: Approved Vent Parts
installation APPROVED VENT PARTS: Table 3: Vent part numbers (Must state if galvanized or black wanted, PART NUMBERS). Simpson American Part Description Security Chim. Selkirk Int. Metal-Fab EXCELDirect Duravent Metal 6” Pipe Length 58DVA-06 SV5L6 5DT-06 TC-5DL6 9” Pipe Length 58DVA-09 5DT-09 12” Pipe Length 58DVA-12 SV5L12 5D12 5DT-12...
Page 18: Installation Of Flue Restrictor
installation Table 4: Approved Vent Manufacturers Manufacturer Trade Name Nominal Sizes 5” x 8” American Metal Products AmeriVent Direct 5” x 8” Security Chimneys International LTD Secure Vent 5” x 8” Selkirk Metalbestos Direct-Temp 5” x 8” Simpson Dura-Vent Direct Vent GS 5” x 8” EXCELDirect INSTALLATION OF FLUE RESTRICTOR: Flue Restrictors are necessary to keep the fireplace running at its intended efficiency. They are also required to counteract the effect that taller vertical vent runs may have on the appliance.
Page 19: Tv Installation Above Unit
TV INSTALLATION ABOVE UNIT: During the development of the L965E/HZ965E, we took into consideration that in some installations TV’s or flat panel monitors may be located above the mantel. Although we can not anticipate every possible installation variable, we took time to evaluate the suitability of the installation of a TV or Plasma display above the mantel. We carried out testing to evaluate what possible operating temperatures that may be experienced when the appliance was installed in an internal chase. A mantel was installed with the maximum overhang at the minimum allowable installation height, with a full 13” (330mm) shelf installed over the unit (see section n omBustIBle aterIal The area above the mantel, within 4 inches (102mm) of the wall was measured under maximum operating conditions and found to not exceed 120°F (49°C). Variations of mantel overhangs, shelf depths or ceiling heights will affect this temperature. Please refer the TV owner’s manual for information on acceptable operating conditions. Care must be taken to evaluate your specific installation and operating conditions when deciding to install electronic equipment above or near this appliance when it is in operation. Always consult your TVs owner’s manual to ensure that this application is an approved installation. SEE NOTE BELOW Figure 27: Installation of TV Above the Unit. IMPORTANT: T emperature acceptance levels in TV’s vary greatly. Before installing any electronic appliance above this fireplace, first verify temperature requirements from the TV manufacturer. See temperatures above for guidance. Regency will not be responsible for heat damage to electronic appliances. HZ965/L965 Gas Fireplace |...
Page 20: Planning Your Installation
installation QUALIFIED INSTALLERS ONLY PLANNING YOUR INSTALLATION: Prior to starting your venting installation, refer to the section on Allowable Vent Configurations to make sure your plans fall into the allowable limits of horizontal and vertical installations. When planning your installation, it will be necessary to select the proper length of vent pipe for your particular requirements. For horizontal installations, refer to the section on Clearances to Combustibles to determine the minimum clearance from the rear of the appliance to the wall. It is also important to note the wall thickness. Select the amount of vertical rise desired for “vertical-to- horizontal” type installations. To determine the length of vent pipe required for vertical installations, measure the distance from the appliance flue outlet to the ceiling, the ceiling thickness, the vertical rise in an attic or second story, and allow for sufficient vent height above the roofline. For two-story applications, firestops are required at each floor level. If an offset is needed in the attic, additional pipe and elbows will be required. ASSEMBLY OF THE UNIT: Left and Right Facing Support 1. Using eight (8) T-20 screws provided, install the facing supports right and left as well as the heat shield in the middle, as shown in Figure 28. 2. U sing eight (8) T20 screws provided, attach both back stand-offs, as shown in Figure 29. Figure 29: Installation of Back Stand-Offs. Figure 28: Installation of Supports & Heat shield.
Page 21: Installation Of Non-Combustible Wall And Hearth Board
installation QUALIFIED INSTALLERS ONLY INSTALLATION OF NON-COMBUSTIBLE WALL AND HEARTH BOARD: Install the non-combustible wall board and hearth protector provided with the unit. The side boards are interchangeable and are secured with facing screws (¾” screws provided), three (3) to each side of the unit and three (3) to each side frame member. The top board is secured with three (3) facing screws along the top frame (header), three (3) along the top nailing flange of the unit and two (2) on each vertical frame member. Also secure the top wall board to the heat shield behind it with two (2) screws and each facing support upright with two (2) screws. See the section on hearth installation for installing the hearth protector, required with the installation of this unit. All the screws required to attach the wall board sides and top to the unit have corresponding holes already located on the units nailing flanges, facing supports and heat shield. INSTALLATION OF VENTING AND TERMINATIONS: Read all instructions carefully before starting the installation. Failure to follow these instructions may create a fire or other safety hazard, and will void the warranty.
Page 22: Horizontal Installation
installation WARNING • A lways maintain required clearances (air spaces) to nearby combustibles to prevent a fire hazard. Do not fill air spaces with insulation. Unless stated otherwise, clearances on horizontal vent sections are 2” (51mm) to combustible materials. Clearances to vertical vent sections are 1” (25mm) to combustible clearances.
Page 23: Vertical Termination Installation
installation ” (32mm) Figure 39: Installation of Wall Firestop. Figure 38: Installation of Vent Pipe to Termination. Figure 37: Installation of Vinyl Siding Standoff. VERTICAL TERMINATION INSTALLATION: Step 1. M aintain clearances between venting and combustible building materials as stated earlier in this section. Do not pack air spaces with insulation. Check with the Allowable Vent Configurations page when planning your installation to ensure the vertical and horizontal elements of your installation are within these limits.
Page 24 installation Step 5. C ut a hole in the roof centered on the small drill hole placed in the roof in Step 2. The hole should be of sufficient size to meet the minimum requirements for clearance to combustibles, as specified earlier. Continue to assemble lengths of Pipe and Elbows necessary to reach from the Ceiling Firestop up through the roof line. Notes: (1) I f an offset is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3 feet, to avoid excessive stress on the Elbows, and possible separation. Wall Straps are available for this purpose (see Figure 41).
Page 25: Venting Arrangements - Horizontal Termination (Flex)
1.83 Over 16/12 to 18/12 2.13 Over 18/12 to 20/12 2.29 Over 20/12 to 21/12 2.44 VENTING ARRANGEMENTS - HORIZONTAL TERMINATION (FLEX): Regency Direct Vent System ® These venting systems, in combination with the HZ965/L965, have been tested and listed as a direct vent system by Warnock Hersey. The location of the termination cap must conform to the requirements in the Vent Terminal Locations diagram from the "Exterior Vent Termination Locations" section. FPI Direct Vent (Flex) System Termination Kits include all the parts needed to install the HZ965/L965, using a flexible vent. FPI Kit #...
Page 26: Heat Distribution Kit Installation
installation HEAT DISTRIBUTION KIT INSTALLATION: Please ensure that your Heat Distribution Kit has not been damaged. IMPORTANT: When installing the Heat Distribution Kit, the framing clearances are different. See figure 12 on page 29. Clearances must be maintained. 1. R emove the rear standoff and the duct cover plate from the back of the unit. Rear of the Unit Item Description Hot Air Duct Hot Air Duct Angle Duct Cover Plate...
Page 27 installation " (57mm) " (57mm) Fireplace Vent Duct Collar " (464mm) Hot Air Duct Opening " " (349mm) (129mm) 2" Rear of the Unit " " (105mm) (103mm) Fireplace Vent Duct Figure 4: Install the vent duct kit. Figure 5: Fan housing overall dimensions. TYP 16"...
Page 28 installation Fan Housing Cover Plate Ground Strain Relief Figure 8: Wiring fan. Figure 9: Fan wiring options. e) Secure the cover plate to the back of the fan hous- ing with screws f) Secure the service wires to the strain relief f) For wiring options see Figure 9. 8. Attach the 5” Aluminum Flex Vent to the Fireplace Vent Duct Collar with sheet metal screws or a vent strap and run the vent to the Fan Housing Vent Duct Fan Housing Vent Duct Collar Collar. The Fan Housing Vent Duct can be installed through the rear or the bottom of the Fan Housing as shown in Figure 10. IMPORTANT: Maintain a minimum of 2” (51mm) clearance between the flex lines and combustible materials.
Page 29 installation 60" (1524mm) Chase Minimum Width 26 1/2" (610mm) Chase Minimum Depth ** Minimum Height from 44 3/4" the base of the unit. (1137mm) Minimum 90" (2286mm) to Internal Ceiling **52 5/16" (1329mm) to Header Figure 12: Installation Clearances with Heat Distribution Kit. HZ965/L965 Gas Fireplace |...
Page 30: Power Vent Kit Installation
installation POWER VENT KIT INSTALLATION: Please ensure that your Power Vent Kit has not been damaged. 1. Plan out the venting and wiring installation. Important notes to consider when planning where the venting will be installed: • Minimum horizontal vent run allowed with no rise is 1 foot (305mm). • Horizontal vent runs less than 8 feet (2.44m) require a 60% restrictor. Refer to the Owner’s Manual on how to install a restrictor. • Maximum vent run is 100 feet (30.5m) (H + V + H + H + H + H...
Page 31 installation 5" x 8" to " 4" x 6 " (240mm) Vent Reducer 1ft (305mm) 4" x 6" Vent 4” x 6-5/8” vent 5" x 8" 90 o Elbow Wall Power Thimble " Vent (368mm) 2" x 4" Wall Stud " Power Vent (368mm) Control Box Wall...
Page 32 installation Wall Board Wall Board Screw Outer Thimble Vents Power Vent Inner Thimble Electrical Cord Bushing Inner Thimble Power Vent Electrical Cord Bushing Screw Figure 6: Install the inner thimble and the power Figure 7: Install the outer thimble. vent cords. 7. Assemble the outer thimble to the inner thimble and secure the outer thimble to the wall board with screws.
Page 33 installation Power Vent Power Vent Case Cover Brown Black White Red-Vacuum Hose Vacuum Switch Screw Exhaust Two Black Wire from Blower Power Vent Cut-Out Assembly Figure 10: Fan and vacuum switch wired. Figure 11: Install the power vent cover case. 12. Secure the cord to the Power Vent Assembly with the Strain Relief as shown in Figure 9.
Page 34 installation 18. Locate the 9V clip from the Power Vent Kit (PVK) and the 9V clip of the unit and plug them together as shown in Figure 15a & 15b. 9V clip from unit 9V clips connected 9V clip from PVK : 9V clips Figure 15b Figure 15a 19. W hen using the Power Vent Kit (PVK), there is no need to have the unit set to continuous pilot so locate the CPI/IPI connectors (Blue and White wires) and disconnect them as shown in Figure 16a &16b. CPI/IPI switch CPI/IPI switch disconnected Figure 16a Figure 16b 20. L ocate the Green TH wire connection and disconnect as shown in Figure 17a & 17b. Green TH wire Figure 17a Figure 17b 34 | HZ965/L965 Gas Fireplace...
Page 35 installation 21. Connect the orange wires from the PVK kit to the Green TH wires disconnected in the previous step as shown in Figure 18a &18b. Green TH wire Green TH wire Orange wire Orange wire Figure 18a Figure 18b 22. Remove the inside access cover from inside the firebox by removing (10) screws as shown in Figure 19 Inside access cover Figure 19 23. C arefully remove the Orange EV1 wire from the gas valve and carefully connect Blue wires from PVK to EV1 and Orange wire (NOTE - gas valve has been removed from unit to better show the wire connections) – Shown in Figure 20a, 20b, 20c & 20d. Orange wire Blue wire Orange wire nected discon Figure 20a Figure 20b Blue wire connected to EV1 Blue wire connected to Orange wire...
Page 36 installation 24. R einstall access cover (removed in Step 22) from inside the firebox. 25. R emove cover plate off of Power Vent Control box (4 screws) Figure 21a, note the proper position of all wire connections prior to removing Figure 21b (they will need to be reinstalled exactly as removed in later steps), then carefully remove only the wires from the grey sleeved wire harness from the board shown in Figure 21c. Do not disconnect any of the other remaining wires. Cover Plate Figure 21a Figure 21b Figure 21c 26. L ocate the plastic grommet on the front top side of access panel and feed grey sleeved wires (disconnected in the previous step) through it as shown in Figure 22a & 22b. Grommet Gray Wire Figure 22a Figure 22b 27. Bring the grey sleeved wire harness to the PVC board and Carefully reconnect all wires onto the PVK board & reinstall cover plate shown in Figure 23a & 23b. Reconnect all wires Figure 23a Figure 23b 36 | HZ965/L965 Gas Fireplace...
Page 37 installation 28. Attach Velcro to underside of PVK box, secure in place and plug PVC into the receptacle that is located under it shown in Figure 24a & 24b. PVK box attached Figure 24a Figure 24b 29. R econnect FCM Com wire harness (removed in Step 17) and ensure that Fan Control Module (FCM) power switch is turned on – line pushed in is <ON> as shown in Figure 25a, 25b, and 25c. Reconnect FCM Fan control module ON/OFF switch Figure 25b Figure 25c Figure 25a 30. R einstall Outside Access Door (reverse Step 16) as shown in Figure 26. Outside Access Door Figure 26 WARNING: Electrical Grounding Instructions This appliance is equipped with a three-prong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug. Periodic examination of venting systems should be done by a qualified agency.
Page 38 installation 38 | HZ965/L965 Gas Fireplace...
Page 39 installation FOR POWER VENT SYSTEM ONLY IF NOT USING POWER VENT - SEE CHART ON PAGE 16. Fixed Closed Fixed Openable Closed Openable Termination Cap Air Supply Inlet Restriction Zone Gas Meter (Termination not allowed) Figure 19. Vent Termination Restrictions, refer to Table 1. Table 1: Vent termination clearances, refer to Figure 19.
Page 40: Door Removal And Installation
installation DOOR REMOVAL AND INSTALLATION: 1) T he fireplace door hangs on two (2) hooks on the top of the firebox. The two (2) door latches at the bottom of the firebox hook over the tabs on the bottom of the door frame. 2) L ower the door latch tool underneath the door frame. Catch the lower door latch Large hooked end for with the door latch tool (see Figure 45) and pull it out slightly, then down. Once removing the door. the lower door latch clears the tab on the bottom of the door frame, release it Slots on other end inwards and then remove the door latch tool. Refer to Figures 47 & 48. is for Air Shutter Adjustment Levers 3) P ull the Door Frame at the bottom forward about 2” (5cm), then lift the Door Frame upwards to clear the Upper Door Hooks. Refer to Figures 48 & 49.
Page 41: Gas Hook-Up
installation GAS HOOK-UP: The L965E/H965E are equipped from the factory with a 1/2” SAE 45º male gas fitting. This fitting will fit commonly used flexible gas supply lines. If your local code requires you to use only rigid pipe for gas supply, remove the flare fitting provided. The gas line is fastened to an MPT flare fitting. You can then use a common union to provide the gas connection to the appliance. The dimension shown in Figure 50 are for your convenience if you have to hard pipe directly to the unit. NOTES: ” (502mm) This appliance and it’s main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressure in excess of 1/2 psi (3.5 kPa). ” Isolate this appliance from the gas supply piping system by closing its the equipment shutoff (371mm) valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa). ”SAE 45 Flare Fitting Gas Inlet ”...
Page 42: Lp Gas Conversion
installation LP GAS CONVERSION: WARNING: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or production of carbon monoxide may result causing property damage, personal injury or loss of life.
Page 43 installation 9. Install the correct orifice and replace the pilot hood. The pilot hood has an indexing notch which must be align with the pilot base. Ensure the pilot hood is properly located and that the spring holding the pilot hood is properly engaged. Delayed ignition may be the result of an improperly installed pilot hood. 10. Using a socket wrench, remove both gas burner orifices from the orifice mounting brackets at the rear floor of the firebox (Figure 55). 11. Use only the gas burner orifices that were included in the LP gas conversion kit supplied by the manufacturer.
Page 44 installation 24. Fire the unit to ensure correct operation and flame picture. Ensure the Split Valve and Flame Modulation works as described in the operations section of this manual. 25. Check the pilot flame that it is the correct size and orientation. The pilot flame can be Manifold test Inlet test adjusted with the adjustment provision on the front face of the valve. This is located just up...
Page 45: Glass Burner Removal/Installation
installation GLASS BURNER REMOVAL/INSTALLATION: 4) C arefully pull the burner forward (see Figure 65) away from the 1) R emoval the front panel of the burner by removing 2 screws in the locations mixing tubes. When clear of the mixing tubes, lift the burner shown in Figure 61 and Figure 62. up and out. Figure 61: Front Panel Screw Locations Figure 65: Move Burner away from Mixing Tubes 5) T o install, reverse steps. Figure 62: Removing Front Panel Screws 2) A fter the screws are removed, lift out the front panel as shown in Figure 63.
Page 46: Glass Crystal / Stones Installation
installation GLASS CRYSTAL / STONES INSTALLATION : Evenly spread the Glass Crystals or optional Ceramic Spa Stones over the burner. Ensure the crystals (or stones) do not overlap too much as this will effect the flame pattern. IMPORTANT NOTE: Only the supplied approved Glass Crystals and Ceramic Spa Stones are to be used with these fireplaces. Use of any other type of glass crystals or stones can alter the unit's performance, any damage caused by the use of any unapproved glass or stones will not be covered under warranty. When using Ceramic Spa Stones DO NOT cover burner ports or pilot light that lead to pilot flame. Ensure the crystals or stones do not overlap excessively as this will effect the flame pattern. BURNER PACKAGES Unit *Glass Crystals **Ceramic Spa Stones HZ965 12 lbs 140 spa stones NOTE: * Glass Crystals are available in 1lb and 5lb bags. **Each Ceramic Spa stone package contains 70 stones. Figure 66 Figure 67 Figure 68 1) Start Crystals on back Burner and 2) Work Crystals downwards to front Firebox Floor of Burner and Firebox Floor...
Page 47: Reflective Panel Installation / Removal
installation REFLECTIVE PANEL INSTALLATION / REMOVAL: Before installation, panels must be handled and cleaned as per instructions noted below: Black Enamel Panels • Black Enamel panels must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time. Claims for damage after installation will not receive consideration. • Black Enamel panels will discolor a little during normal operation. This is normal and should not be considered a defect. All hand and finger marks MUST be cleaned off with a soft cloth. Use an ammonia based cleaner (ie. glass cleaner) to remove any fingerprints before applying heat to the unit. Failure to do this will result in burn stain on panels which you will be unable to remove. Not protected by product warranty. 1. I nstall the Rear Porcelain Panel by placing it behind the burner. Use cau- tion- do not scratch the panel. Figure 76: Panel /Unit Alignment. 3. I nstall the Top Panel by placing it on top of the Rear Panel and behind the Left Panel (see Figure 77). Hold with one hand then place right side panel. Figure 74: Rear Porcelain Panel 2. I nstall the Left Reflective Panel; it should be flush with the outer edge of the firebox (see Figure 76).
Page 48: Brick Panel Installation / Removal
l965E installation BRICK PANEL INSTALLATION / REMOVAL: BRICk PaneL InStaLLatIon / RemovaL: 1) Loosen screws securing Brick Panel Clip shown in Figure 76 and slide 4) Slide the upper back panel in behind the left side panel and on top Clip away from wall of unit.
Page 49: Log Burner / Ember Bed Removal / Installation
installation LOG BURNER / EMBER BED REMOVAL / INSTALLATION: 1. Pull the burner away from the mixing tubes. 2. Lift the burner up and out of the unit. 3. Reverse steps to reinstall. Note: Use caution when lifting, burner is heavy - do not drop. Figure 79: Burner Removal LOG SET INSTALLATION: Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation.
Page 50 installation LOG SET INSTALLATION: 4) Identify locator on Log A as shown in Figure 89. 1) Place Log A on the Ceramic Log Burner as shown in Figure 86. Figure 86: Log A Figure 89: Log A Locator 5) Position Log C on Log A using Locator as shown in Figure 90. 2) Identify locator on Log B as shown in Figure 87. Locator Figure 87: Log B Locator Figure 90: Log C Position 3) Line up Locator on Log B with Locator on Log A as shown in Figure 88.
Page 51 installation 7) Identify locator on Log E and opposing Locator on the Ceramic Log 10) Identify locator on Log H and opposing Locator on Log B as Burner as shown in Figure 94. Place Log E gently on Burner. shown in Figure 92. Place Log H gently on Log B. Figure 92: Log F Locator 8) I dentify locator on Log F and opposing Locator on the Ceramic Log Burner as shown in Figure 94. Place Log F gently on Burner. Figure 96: Log H Locator 11) Log H in position. Figure 93: Log F Locator 9) I dentify locator on Log G and opposing Locator on the Ceramic Log Burner as shown in Figure 94. Place Log G gently on Burner.
Page 52: Safety Screen Installation
installation SAFETY SCREEN INSTALLATION 52 | HZ965/L965 Gas Fireplace...
Page 53: Finishing Trim
installation FINISHING TRIM: Finishing trim is supplied with the unit for use if the unit is installed up from floor level. The trim will cover the gap between the unit and the non combustible materials. Non combustible Figure 102: Completed Trim install materials Figure 100: Top View - exposed non combustible materials 1. Slide trim into position over exposed non combustible materials. Trim piece Figure 101: Top View - Sliding trim into place HZ965/L965 Gas Fireplace |...
Page 54: Start-Up & Operation
operating instructions START-UP & OPERATION NORMAL SOUNDS DURING OPERATION: Table 1: Normal Sounds Component Sound & Reason Fascia Creaking when heating up or cooling down. Burner Light pop or poof when turned off; this is more common with LP units. Pilot Flame Quiet whisper while the pilot flame in on. Gas Control Valve Dull click when turning on or off, this is the valve opening and closing. REMOTE CONTROL OPERATIONS: The Proflame GTMFS is a modular remote control system that directs the functions of the L965E / HZ965E. The Proflame GTMFS is configured to control the on/off main burner operation, its flame levels and provides on/off and Smart thermostatic control of the appliance. The system controls a remotely actuated 120V/60Hz power outlet, fan speed through six (6) levels and has a constantly powered 120V/60Hz power outlet. WARNING THE TRANSMITTER AND RECEIVER ARE RADIO FREQUENCE DEVICES. PLACING THE RECEIVER IN OR NEAR METAL MAY SEVERELY REDUCE THE SIGNAL RANGE.
Page 55 operating instructions TRANSMITTER (Remote Control with LCD Display) The Proflame Transmitter uses a streamline design with a simple button layout and informative LCD display (Figure 99). The Transmitter is powered by three (3) AAA type batteries. A Mode Key is provided to Index between the features and a Ther- mostat Key is used to turn on/off or index through Thermostat functions (Figure 103 & 104). Figure 103: Proflame Transmitter. Split Flow Figure 104: Proflame Transmitter LCD Screen. RECEIVER The Proflame Receiver (Figure 101) connects directly to the gas valve, stepper motor, DFC, and Fan Control Module with a wiring harness. The Receiver is powered by 110 V and uses four (4) AA type batteries for backup. The Receiver accepts commands via radio frequency from the Transmitter to operate the appliance in accordance with the particular Proflame system configuration. The Receiver three (3) position slider switch can be set to one of three positions: ON (Manual Override), Remote (Remote control), or Off.
Page 56: Wall Mounting The Receiver
operating instructions WALL MOUNTING THE RECEIVER: The receiver can be placed inside a standard Junction type wall box either by itself or in combination with a light dimmer control. This installation can take place up to 8’ft (2.4m) from the appliance control valve. 1. Connect the wiring harness to the back of the Receiver. 2. I nstall the Receiver in the Junction box using the existing J box screws (Figure 59). 3. I nsert the four (4) AA type batteries in the battery compartment with the correct polarity. 4. Place the slider into the cover plate. 5. Put the Receiver switch in the “OFF” position. 6. M ake sure the Receiver and cover plate words “ON” and “UP” are on the same side. J-Box 7. A lign the slider with the switch on the Receiver and couple the switch into the slider. Slider Receiver Switch 8. Align the screw holes. 9. U sing the two (2) screws provided secure the cover plate to the Re- ceiver.
Page 57: Smart Thermostat (Transmitter Operation)
operating instructions SMART THERMOSTAT (TRANSMITTER OPERATION) Room Temperature The Smart Thermostat function adjusts the flame height in accordance to the difference between the set point temperature and the actual room temperatures. As the room temperature gets closer to the set point the Smart Function will modulate the flame down. To activate this function, press the Thermostat Key (until the word “SMART” appears to the right of the temperature bulb graphic (Figure 106). To adjust the set temperature, press the Up or Down Arrow Keys until the Thermostat ON desired set temperature is displayed on the LCD screen of the Transmitter. REMOTE FLAME CONTROL Set Temperature The Proflame GTMFS has six (6) flame levels. With the system on, and the flame level at the maximum in the appliance, pressing the Down Arrow Key once will reduce the flame height by one step until the flame is turned off. The Up Arrow Key will increase the flame height each time it is pressed. If the Up Arrow Key is pressed while the system is on but the flame is off, Figure 109: Remote Control Displays Set the flame will come on in the high position (refer to Figure 107). A single “beep” will confirm Temperature. reception of the command. REMOTE ACTUATED ACCENT LIGHTS The L965E is shipped with two (2) firebox accent lights. They are connected to the auxiliary power outlet of the Proflame Fan Control Module. The lights can be turned on or off using the Auxiliary function on your remote control. Press the Mode Key on the remote control until the Auxiliary Function icon is highlighted. Pressing the Up or Down arrow keys will turn the accent lights on or off. A single “beep” will confirm the reception of the command Flame Off...
Page 58: Key Lock
operating instructions KEY LOCK This function will lock the keys to avoid unsupervised operation. To activate this function, press the MODE and UP keys at the same time and the a lock will appear (see Figure 109). To de- activate this function, press the MODE and UP Keys at the same time. LOW BATTERY POWER DETECTION Transmitter: The life span of the remote control batteries depends on various factors: quality of the batteries used, the number of ignitions of the appliance, the number of Figure 112: Remote Control with Aux for Accent Lights.
Page 59: Air Shutter Adjustment
operating instructions AIR SHUTTER ADJUSTMENT: The L965E/ HZ965E is setup to work with two (2) gas orifices. The orifice on the left (looking from the front) feeds the front burner while the right feeds the rear burner, which can also be switched off using the remote control. Each orifice has its own Air Shutter. The Air Shutter is connected to an Adjustment Lever that is accessible from the front and bottom of the firebox. These Air Shutters can be adjusted during the operation of the fireplace. This Figure 68 shows the fireplace with the door and the burners removed. This is to better show the Air Shutters and the Adjustment Levers. The Door/Air Shutter Tool (see Figure 116) has a small slots on one end. These slots can be used to engage the vertical section of the adjustment lever to move the klever forward or rearward. Moving the Lever towards you opens the Air Shutter, while moving it rearward, closes the Air Shutter. Air shutters should be adjusted so that the gas flame burns with a blue base and a bright yellow upper section. Air shutters set to closed will lead to a dirty flame which may lead to soot gathering on the logs and/or glass panel. Properly set Air Shutters will result in a very blue flame for the first fifteen (15) minutes of operations with the flame becoming more yellow as the unit comes up to operating temperature. Table 2: Air Shutter Settings. Left Right Open Open Glass / Media Burner Open Open Open 1/8” (3mm) Open Log Set/ Ember Bed Burner Open ” (2mm) Open Figure 116: Air Shutter Adjustment. Ignition Information 1. The Proflame DFC Board will try two (2) times for ignition. 2. Each try for ignition will last 60 seconds.
Page 60: Wiring Harness
maintenance WIRING HARNESS Caution: Label all wires prior to disconnection when servicing controls, Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. 60 | HZ965/L965 Gas Fireplace...
Page 61: Lighting Instruction Label
maintenance LIGHTING INSTRUCTION LABEL: CAUTION: DO NOT REMOVE THIS LABEL / N'ENLEVEZ PAS CE Hot while operating. Do not touch. Severe burns may result. Keep children, clothing, furniture, gasoline or other flammable vapors away. DV48 CAUTION: Do not operate this fireplace with the glass removed, cracked or broken. Replacement of the panel(s) should be done by a licensed or qualified person! This appliance needs fresh air for safe operation and must be installed with provisions for VENTED GAS FIREPLACE HEATER ENVIRO MODEL:...
Page 62: Light Bulb Replacement
The glass in the fireplace is a high temperature ceramic. If the glass is damaged in any way, a factory replacement is required (see P arts omPonents Wear gloves when handling damaged glass door assembly to prevent personal injury. When the glass door assembly is being transported, it must be wrapped in newsprint and tape and/or a strong plastic bag. Do not operate with the glass front removed, cracked or broken. Removal and replacement of the glass from the door must be done by a licensed or qualified service person. The glass must be purchased from an authorized Regency dealer, part #50-2002. No substitute materials are allowed. BURNER & FIREBOX CLEANING: The flow of combustion and ventilation air not to be obstructed. Periodic maintenance should include cleaning of the firebox, burner and log effects. Refer to the sections on glass door removal, log and or burner installation to remove the glass door, log set (if equipped), burner trim pieces and burners. Using a vacuum with a soft brush attachment, clean out any dust, lint or debris from the floor of the firebox. Using a soft brush, gently remove any dirt or debris from the top surface of the burner. Using the same brush, gently brush away any carbon deposits that have built up on the surface of the logs. Re-install all of these...
Page 63: Troubleshooting
maintenance TROUBLESHOOTING Problem Possible Cause Solution The pilot flame has gone out · Turn it ON Thermostat does The On/Off switch is turn to OFF not work The thermostat is set too high · Set the thermostat to a lower temperature · Check pilot assembly wiring · C heck for broken or poor connection from the sparker to the electrode No spark Spark develops near the pilot assembly or generation could occur onboard · C heck for the spark shorting or arcing at other locations · Check for defective sparker and spark electrode No spark from the igniter · See “no spark generation” · I t takes a while for all the air to purge out of the pilot before gas can reach the pilot Air in the gas line and ignite Pilot gas pressure dropout upon main · Check gas mains supply and pressure burner gas valve opening No pilot flame · C heck gas valve wirings and connections to the board ignition · Check the pilot burner for obstruction No gas flow out of the pilot burner · C heck the wirings and connections between the pilot assembly and the board...
Page 64 maintenance TROUBLESHOOTING Problem Possible Cause Solution · T urn the system off by pressing the ON/OFF button on the transmitter · A fter approximately 2 seconds press the ON/OFF button on the transmitter again. · I n the manual flame control mode, use the down arrow button to reduce the flame to off, indicated by the word OFF displayed on the transmitter LCD screen. Locking Reset the Proflame DFC board conditions · W ait approximately 2 seconds and press the up arrow button, the ignition sequence will start. · W ith the transmitter off, move the slider switch on the receiver to the OFF position. · W ait approximately 2 seconds and move the receiver slider switch to the ON position. The pilot flame has gone out · See “Pilot will not remain lit” The remote control is not working correctly · Replace the batteries The thermostat is disconnected or set too · Set the thermostat to a lower temperature high Main burners will not start · Check gas line pressure...
Page 65: Appendix A - Optional Reduced Ceiling Height Installation
installation APPENDIX A - OPTIONAL REDUCED CEILING HEIGHT INSTALLATION The L965E/HZ965E can be installed with the reduced ceiling height as shown in this diagram. If you are limited by ceiling heights, particularly when installing a raised hearth, you can install the unit observing the clearances outline in this diagram. The main difference is the install depth is changed to 26½” (673mm) to compensate for the reduced vertical clearances. The width and framing dimensions remain unchanged to the regular installations shown earlier in this manual. 44-3/4" (1137mm) **52-5/16" (1329mm) HZ965/L965 Gas Fireplace |...
Page 66: Parts List
parts list 66 | HZ965/L965 Gas Fireplace...
Page 67: Parts List
911-085 Valve Only LP 706-060 #53 Burner orifice - LP 911-030 Fan Controller Module 706-061 #45 Burner orifice - NG 911-012 DFC (Digital Fireplace Control) 706-062 #41 Burner orfice - NG 911-016 Remote Receiver 946-693 Stepper Motor - NG 706-021 Transmitter 946-694 Stepper Motor - LP 911-032 Wire Harness - Receiver 911-013 Wire Harness - IPI 911-006 Pilot Assembly - NG 911-007 Pilot Assembly - LP 706-026 Vent Restrictor Set 706-921 Regency Heat Distribution Kit 706-922 Power Vent Kit 706-540 Safety Screen HZ965/L965 Gas Fireplace |...
Page 68 FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. Revision Date: December 2016 Regency Gas Products Warranty 68 | HZ965/L965 Gas Fireplace...
Page 69 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: December 2016 Regency Gas Products Warranty HZ965/L965 Gas Fireplace |...
Page 70 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
Page 71 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
Page 73 notes HZ965/L965 Gas Fireplace |...
Page 74 notes 74 | HZ965/L965 Gas Fireplace...
Page 76 Installer: Please complete the following information Dealer Name & Address: ___________________________________ ________________________________________________________ Installer: ________________________________________________ Phone #: ________________________________________________ Date Installed: ___________________________________________ Serial No.: _______________________________________________ Horizon HZI390E Liberty L965E Printed in Canada © Copyright 2017, FPI Fireplace Products International Ltd. All rights reserved.
