Regency Liberty L900 Gas Fireplace L900-LP1 Specifications

Regency Liberty L900 Gas Fireplace
Model L900-NG1
Fuel Type Natural Gas
Minimum Supply Pressure 5" W.C.(1.25 kPa)
Manifold Pressure - High 3.5" W.C. (0.87 kPa)
Manifold Pressure - Low 1.6" W.C. (0.40 kPa)
Orifi ce Size #30 DMS
Minimum Input
28,000 BTU/h (8.20 kW)
Altitude 0-4500 ft. (0-1372m)
Maximum Input
41,500 BTU/h (12.16 kW)
Altitude 0-4500 ft. (0-1372m)
Vent Sizing 5" Inner / 8" Outer
Approved Venting Systems
Flex Vent Systems:
Rigid Pipe Vent Systems:

Unit Dimensions:

Unit Dimensions Description
A Firebox Width w/ Standoff
B Rear Firebox Width
C Firebox Height
D Height w/ Standoff
E Unit Depth
F Height to Vent
G Fireplace Opening Height
H Fireplace Opening Width
I Height to Fireplace Opening
This manual is intended to be a Sales Reference Guide only.
Do NOT use for actual framing and installation of any unit.
Some specifi cations may change without notice.
You must use the actual manual for exact installation specifi cations.
WARNING
Failure to maintain required clearances is a major cause of chimney related fi res.
Installation of this fi replace must comply with these clearances
Please note: Due to ongoing product development, product appearance and specifi cations
are subject to change without notice.
L900-LP1
Propane
12" W.C. (3.00 kPa)
10" W.C. (2.49 kPa)
6.4" W.C. (1.59 kPa)
#49 DMS
31,000 BTU/h (9.08 kW)
38,500 BTU/h (11.28 kW)
5" Inner / 8" Outer
FPI AstroCap™ Flex Vent
Simpson Direct Vent Pro®
Selkirk Direct-Temp™
Metal-Fab® Sure Seal
L900-1
51-1/2" (1308mm)
40-5/8" (1032mm)
41-3/8" (1051mm)
50-3/8" (1270mm)
27" (686mm)
44-1/2" (1130mm)
32-1/16" (814mm)
33-5/8" (853mm)
3" (76mm)

Framing Dimensions:

Framing Dimensions Description
J Framing Width
*** ***
K Framing Height
L Framing Depth
M Minimum Height to Combustibles
N Corner Wall Length
O Corner Facing Wall Width
P Vent Centerline Height
Q Non-combustible facing height
R Gas Connection Opening Height
S Gas Connection Height
T Gas Connection Inset
U Gas Connection Opening Width
***
Important: Framing height requires consideration of the hearth
depth. Dimension K = K + the thickness of installed hearth.
Non-Combustible Requirements:
L900-1 Gas Fireplace
L900-1
52" (1321mm)
***
50-3/4" (1289mm) + Hearth
26-1/2" (673mm)
60" (1524mm)
63-15/16" (1624mm)
90-7/16" (2286mm)
53" (1346mm)
17-7/16" (443mm)
2" (51mm)
11-1/4" (286mm)
6" (152mm)
5" (127mm)
