Page 4
7.4. Printer Style ..........................29 7.5. RS485 Networking ........................29 7.6. Ethernet Port Setup and Configuration ..................30 7.6.1. Setting the Static IP Address of the BT-620: ..............30 7.6.2. Installing the Virtual Serial Port Drivers: ................31 7.6.3. Configuring the Virtual Com Port for the BT-620: ............. 33 Maintenance ......................
Introduction The BT-620 is a portable airborne particle counter with a small stable footprint. This allows you to move it around and set it down rather than holding it in your hand while sampling. The large character backlit LCD display provides easy viewing from distances exceeding 3 meters.
1.2. Layout Figure 3 shows the layout of the BT-620 and the following table provides a description of the components. Carrying Handle Inlet Nozzle Temp/RH Connector Display Keyboard Printer USB Flash Drive BT-620 Manual Page 7 BT-620-9800 Rev B...
Page 9
Charger Jack Power Switch RS-232 USB I/O RS 485 Analog Out Ethernet Figure 3 – BT-620 Layout BT-620 Manual Page 8 BT-620-9800 Rev B...
RS-232 1.4. Initial Operation Before operating the BT-620 for the first time, it is recommended that the unit be fully charged. Information regarding battery charging is found in Section 6. Complete the following steps to verify proper operation. 1. Press the top of the power switch to turn on power.
3.1. Power Up The BT-620 power is controlled by a switch located on the back of the unit. To power up the unit move the switch to the on position (up). The first screen shown on power up is the Startup Screen (Figure 4). This screen displays the product type and company website for approximately 2 seconds before loading the Operate Screen.
Place a roll of paper in the printer bay with the free end up and coming from the back of the roll. Close the printer door and the green indicator light should light. Press the white button on printer to manually advance the paper. See Section 4.4.4 for Printer Operation. BT-620 Manual Page 11 BT-620-9800 Rev B...
(see Section 4.4). The Favorites setting configures the display and printer for two sizes however the BT-620 still counts and buffers all six particle sizes. Sample data for all six channels is available via the serial port (Section 7) or by viewing count history on the display (Section 3.3.4).
24C RH Figure 9 – Operate Screen (Sampling) 3.3.3. Sample Status The top line of the Operate Screen displays the status of the BT-620 while the unit is sampling. The following table shows the various status messages and their meaning: Status Description STARTING…...
Operate Screen or the main menu. 3.4.2. Real-Time Output BT-620 provides real-time output on the serial port at the end of each sample. The format of the output is controlled by the Serial Output setting (Section 4.4).
PRINTER FAVORITES SET SIZES CALIBRATE FLOW SET CLOCK SET CONTRAST ABOUT Figure 13 – BT-620 Main Menu Menu Item Description Press Enter to navigate to… View / change location number, auto / Single SAMPLE SETUP Sample Setup Screen mode, sample time and hold time.
Hold time is 60 seconds or less. The pump will stop after each sample, and start a few seconds before the next sample, if the Hold time is greater than 60 seconds. Hold times greater than 60 seconds will increase pump life. BT-620 Manual Page 16 BT-620-9800 Rev B...
Figure 15 – Settings Screen 4.3.1. Count Units The BT-620 supports total counts (TC), particles per liter (/L), particles per cubic foot (CF) and particles per cubic meter (M3). Particle count information updates while the unit is sampling. Concentration values (/L, CF, M3) are time dependent so these values may fluctuate early in the sample;...
300 – 38400. 4.4.3. Serial Output Mode The Serial Out setting controls the behavior of the BT-620 serial output. The modes are RS232, RS485, Printer or Network (see Section 6 for serial communication protocol). The following table lists the Serial Output settings and describes their meanings.
Figure 19 shows the analog output connector pin assignments. G pins are signal ground. 1 and 2 are Analog Output 1 and Analog Output 2 which are associated with Favorite 1 and Favorite 2 respectively (see Section 4.6.2). BT-620 Manual Page 19 BT-620-9800 Rev B...
4.7. Calibrate Flow Screen The BT-620 has a factory calibrated flow rate of 1 CFM (28.3 LPM). Under normal circumstances, the integrated flow control system will maintain flow within +/- 5% of this flow rate. Use the following procedure to calibrate the flow rate when a periodic flow rate check (Section 8.1.2) indicates a flow rate error greater than +/- 5%.
Press ▲ or ▼ to toggle between the two version numbers. The serial number is shown on the third line. BT-620 80203 R0.1.0 SN A10000 www.metone.com Figure 24 – About Screen BT-620 Manual Page 21 BT-620-9800 Rev B...
5.1. Copy to USB Drive Figure 26 shows the Copy Data Screen. The BT-620 will copy all data from the displayed date/time to current time. Initially, the date/time will be the first sample record so all records will be copied. To reduce transfer time, press Enter and change the date/time to a more recent date/time.
PRINTING...10 FINISHED! Figure 30 – Printing Status Screen Pressing the ESC button cancels the data printing and loads the menu. The format of the print is dependent upon the report setting (Section 4.2.4). BT-620 Manual Page 23 BT-620-9800 Rev B...
To charge the battery, connect the battery charger to an AC power outlet and the DC plug to the socket on the back of the BT-620. The battery charger is universal and will work with power line voltages of 100 to 240 volts, 50 to 60 Hz. The battery charger LED will be Red during charging Phase 1 (constant current).
You can purchase an optional battery charging cable and replacement battery pack to extend battery operating time. Use the charging cable with the included battery charger to charge the replacement battery while you operate the BT-620 under battery power. 6.1.1. To charge the replacement battery pack 1.
The following sections discuss the various serial communications. ATTENTION: The USB drivers must be installed before connecting the BT-620 USB port to your computer. If the supplied drivers are not installed first, Windows may install generic drivers that are not compatible with this product.
For additional information on networking commands and addressing refer to the BT- 620-9801 Networking Supplement. Figure 32 shows the RS485 connector location and pin assignments. Figure 33 shows a RS-485 network wiring diagram. BT-620 Manual Page 29 BT-620-9800 Rev B...
7.6. Ethernet Port Setup and Configuration The BT-620 Ethernet port must be configured with some drivers by the user: 7.6.1. Setting the Static IP Address of the BT-620: 1. You will need to obtain a Static IP Address from your network administrator.
8. Type in a Network Mask in the Network Mask window. 9. Set the baud rate to 38400. 10. Press the Set button to change the IP address of the BT-620. 11. Click the X close button. 7.6.2. Installing the Virtual Serial Port Drivers: 1.
Page 33
Next. The Installing screen will display that the software is installing the drivers. 2. When the Installation Complete screen is displayed, click the Finish button. You will need to restart your computer before the drivers will be ready to use. BT-620 Manual Page 32 BT-620-9800 Rev B...
2. The configuration window will appear as shown below. Click the New button. 3. Type in the IP address you assigned earlier to the BT-620 unit. Set the Device Port to 23 and chose a Com Port from the drop down window as shown below.
Page 35
This completes the virtual com port drivers. Remember this instrument will always be accessed by the Com Port you chose in step 3. Click the close button on the browser and the VirtualSerialPort program window. BT-620 Manual Page 34 BT-620-9800 Rev B...
Page 36
6. Click on the Serial link at the top of the page. You should be taken to a page like shown below. BT-620 Manual Page 35 BT-620-9800 Rev B...
7. Change the Baud Rate and Flow Control settings to match your BT-620. All other settings should remain as shown above. Press the Submit New Settings button to have these settings take effect. In some slower networks, characters may be dropped.
4. The flow rate can be adjusted using the front panel (see Section 4.7) 8.1.3. Annual Calibration The BT-620 should be sent back to Met One Instruments yearly for calibration and inspection. The annual calibration cannot be performed by the customer because this calibration requires specialized equipment and a skilled technician.
The BT-620 case should never be removed or opened for any reason. Opening or removing the case will void the warranty and may result in exposure to laser radiation, which can cause eye injury.
Warranty / Service Warranty The BT-620 is warranted against defects and workmanship for a period of two (2) years from the ship date. Any product found to be defective during the warranty period will, at the option of Met One Instruments, Inc., be replaced or repaired. In no case shall the liability of Met One Instruments, Inc.
