Remote Monitoring Weather Station
1. Simple Easy Setup
Insert (in any order):
• 2-AA batteries into Thermo-hygro sensor
• 2-AA batteries into Rain sensor
• 2-C batteries into Wind speed sensor
• 2-AAA batteries into LTV-D1 bonus station
• 5 volt power cord (required) into C84228 station
3-AA batteries optional backup for time and date*
For detailed sensor setup and mounting instructions, see
page 6.
Note: Press and release the SENSOR button to confirm
sensor ID's on station match bar codes on your sensors.
*Batteries operation only will not update sensor or Wi-Fi
data. Power cord is required.
Professional Remote Monitoring Station
PROFESSIONAL
Instructional Manual
Models: C84428 & LTV-D1
DC: 060617
2. Select Your Station Use
Option 1: Connected with La Crosse View
• Benefits:
o Remotely monitor your home's data from
anywhere* at any time using this station's
built-in wireless Wi-Fi technology
o Automatically receive time, date, and NWS
forecast information
o Set mobile alerts to keep loved ones safe
o Easily share data with friends & family
o Unlock new Data Stream technology
o And so much more...
• Continue with La Crosse View instructions on
Page 3
Option 2: Standalone Station
• Benefits:
o View all local sensor data right on your
bright easy to read LCD display
o No phone or Wi-Fi needed
• Continue with these instructions on
*Anywhere you have an Internet connection
Page 13
Page | 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for La Crosse Technology C84428
Summary of Contents for La Crosse Technology C84428
- Page 1 PROFESSIONAL Remote Monitoring Weather Station Instructional Manual Models: C84428 & LTV-D1 DC: 060617 1. Simple Easy Setup 2. Select Your Station Use Insert (in any order): Option 1: Connected with La Crosse View • Benefits: o Remotely monitor your home’s data from •...
-
Page 2: Table Of Contents
Sensor Update Interval Sensor Search | Sensor ID Delete Sensor ID Add-on Sensors (sold separately) Settings Menu C84228 Factory Restart C84428 Your LTV-D1 Bonus Station Settings Menu LTV-D1 View Indoor or Outdoor Data LTV-D1 Search for Sensor LTV-D1 Restart LTV-D1 Help Us, Help You Let’s Be Social! -
Page 3: Easy Connection To La Crosse View
Easy Connection to La Crosse View Connecting You to Your Home Anytime, Anywhere. • Simply download your La Crosse View app and follow the on-screen instructions. Wi-Fi Network Requirements In order for your station to connect to your WiFi, it will need to meet the following requirements: •... -
Page 4: Benefits Of Your La Crosse View App
Benefits of Your La Crosse View NWS Expanded Forecasts Additional Icons: FORE CAST • Windy • Light Rain 1. NWS will show in front of the word forecast • Severe T-Storm • Light Snow 2. NWS chance of precipitation will be shown. •... -
Page 5: Your Station Has Status Messages
Your Station has Status Messages Your station has built in status messages. NWS FORECAST FEELS LIKE FORE CAST OUTDOOR • Press and release of the SET button to view. WIND SPEED Note: Only one relevant status message will display. SPEED “ALL OK CONNECTED”... -
Page 6: Detailed Sensor Setup And Mounting
Detailed Sensor Set Up and Mounting Wind Speed sensor LTV-W2 1. Turn the vented portion of your wind sensor counter clockwise. 2. Install fresh “C” batteries. 3. Carefully align and turn vented portion clockwise to tighten. 4. There is a blue LED light on the sensor that will flash when transmitting. Mounting: •... -
Page 7: Wind Speed Readings
C84428 1. Insert the power cord into the wall outlet then into your station. 2.Optional: insert 3 AA batteries into your station to maintain time/date in the event of a power outage. Mounting: 1. Place your station near an outlet. Power cord is required for operation. -
Page 8: Wind Speed History
Wind Speed History Your station records Wind History. Simply press and release the WIND button to view your wind history. Other readings will disappear temporarily WIND SPEED One Hour: past 60 minute period (default Top Speed record, always shown) SPEED 24 hour: Past 24 hour period, from last record 7 Days: Past 7-day period, from last record Month: Defined by Calendar Month i.e. -
Page 9: Reset Rainfall Readings
Reset Rainfall Readings 1. Press the RAIN button to view individual rain readings. 2. Hold the MINUS button for five seconds to reset the individual value. 3. Rainfall reading will reset to 0.00 HI | LO Temperature/Humidity Records Your station records HI and LO records with time and date of occurrence. OUTDOOR A new HI or LO record will replace the existing record. -
Page 10: Temperature | Humidity Trend Arrows
Temperature | Humidity Trend Arrows UP ARROW: Temperature/Humidity is rising Your temperature (2°F / 1°C) and humidity (3%) trend indicators (arrows) update every 15 minutes. The trend reflects changes over the past one hour period. RIGHT ARROW: Temperature/ Humidity is steady DOWN ARROW: Temperature/Humidity is falling Seasonal Changes in Trees The tree foliage will change seasonally on your weather station. -
Page 11: Sensor Update Interval
Sensor Update Interval Sensor: Change Required for Update Updates: No Change- Sensor Updates: Rain 0.007 inch (0.2mm) every 45 seconds every 3 minutes Wind 0.5 mph (0.8 km) every 31.5 seconds every 3 minutes Temp/Humidity 0.9F (0.5 C) every 50 seconds every 3 minutes. -
Page 12: Add-On Sensors (Sold Separately)
Add-on Sensors (sold separately) One benefit of your La Crosse View App is the ability to remote monitor multiple locations in your home by adding com- patible sensors. These add-on sensors will read directly to the app. You can conveniently name each sensor and have it read to the smart box on your station. -
Page 13: Settings Menu C84228
Settings Menu C84428 When operating as a stand alone station you can manually set your station. Note: When using the La Crosse View app, time and date will be set automatically. 1. Hold the SET button for 3 seconds to enter settings menu. -
Page 14: Your Ltv-D1 Bonus Station
Your LTV-D1 Bonus Station • As an added bonus, we have included a LTV-D1 to provide basic temperature and humidity in another room. • Your bonus station receives information from your professional Thermo-hygro sensor Settings Menu LTV-D1 Your Bonus Station does not connect to La Crosse View and will need 2 Hour 1. -
Page 15: Help Us, Help You
Help Us, Help You! If you have ideas for features or support solutions you’d like to see us make, please let us know! We truly want to make owning a La Crosse Technology product not only a practical experience, but also a fun one. So email us at:: store@lacrossetechnology.com Let’s Be Social! Follow us on our social media outlets for the latest promotions, product support, and awesome giveaways. - Page 16 Power 5.0 Volt 500mA power cord included (Required) C84428 Station: AC6 HX06-0500500-AU-1 Optional Battery Backup: 3-AA batteries included, backup for time and date LTV-TH2 Thermo-hygro Sensor: 2-AA batteries included 2-C batteries included LTV-W1 Wind Speed Sensor: 2-AA batteries included LTV-R2 Rain Sensor:...
-
Page 17: Care And Maintenance
• Promptly remove expired batteries. Warranty and Support La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product relating to manufacturing defects in materials & workmanship. Before returning a product, please contact our friendly customer support with questions or visit our online help:... -
Page 18: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
