7 Appliance options and accessories
7.6 ConvoGrill - grill model
The grill model includes a built-in grease removal filter
ConvoGrill is the grill model of Convotherm 4 combi steamers for preparing grilled dishes, and inclu‐
des automatic grease removal and a separate grease outlet.
Availability:
For all appliance sizes
■
Only for easyTouch
■
Can be combined with ConvoSmoke
■
Can be used in the stacking kit - in both appliances or just in one appliance
■
Principle of operation
The appliance detects grease in the drain box and switches on the built-in grease pump to pump
■
the separated grease into the grease collecting canister.
The grease collecting canister can be kept easily and safely beside the appliance.
■
The grease pump is only switched on when there is any grease in the drain box. This saves ener‐
■
gy while maximizing the separation of grease from the wastewater.
The following diagram shows how a grease collecting canister is connected to the outlet pipe:
Designer's Handbook
Item Name
Outlet pipe
1
Connecting tu‐
2
be
Hose clip
3
Canister screw-
4
cap
Grease collec‐
5
ting canister
Forked bracket
6
77
Function
Underneath at the back of
the appliance
Ducts away the grease
Secures the connecting tu‐
be
Closes the grease collec‐
ting canister
Collects the grease
For holding the canister
screw-cap
